Summary of Contents for Gravely 885015
- Page 1 44-Inch Power Brush Owner/Operator & Parts Manual Models 885015 - Power Brush 785023 - Two-Wheel Tractor Completing Kit 787014 - Four-Wheel Tractor Completing Kit 08416400G 9/06 Printed in USA...
-
Page 2: Table Of Contents
PRODUCT REGISTRATION normal operation and maintenance. The Gravely dealer must register the product at the time All reference to left, right, front, or rear are given from of purchase. Registering the product will help the... -
Page 3: Safety
4. Explain recommended lubrication and 5. Instruct customer on controls and operation of unit. maintenance. Advise customer on adjustments. Discuss and emphasize the Safety Precautions. Give customer Owner/Operator, Parts, and Engine Manuals. Advise customer to thoroughly read and understand them. SAFETY NOTATIONS WARNING: This machine is capable of... - Page 4 • Stop engine then disengage power take-off to NEVER allow anyone to operate this unit when their attachment before making adjustments or removing alertness or coordination is impaired. foreign objects. Wear adequate safety gear, protective gloves and • Keep all shields in place footwear.
- Page 5 If you strike an object, or if equipment vibrates This product is equipped with an internal combustion abnormally, stop engine at once, disengage PTO, wait for engine. DO NOT use on or near any unimproved, forest all moving parts to stop, and remove key. Check for any covered or brush covered land unless the exhaust damage or loose parts.
- Page 6 Always compress or extend springs slowly. Gravely does not recommend the use of a Sulky with this ALWAYS maintain unit in safe operating condition. unit. Damaged or worn out muffler can cause fire or explosion.
-
Page 7: Assembly
ASSEMBLY 78502300 - Gear Two-Wheel Tractor Completing WARNING: AVOID INJURY. Read and Kit (Figure 3) understand the entire Safety section before Item Description Qty Part Number proceeding. Bearing Assembly 039739 Package Contents: Bushing 019297 Check the contents of your kit for the parts listed. Knob 019295 NOTE: This manual covers the following three kits:... - Page 8 78701400 - Four-Wheel Tractor Completing Kit (Figure 5) Item Description Qty Part Number Plastic Grommet 011777 Knob 019295 Control Rod 040561 Control Rod Bracket Grommet 012325 1/4 x 3/4” Self Tapping Screw 07414200 Control Rod Bracket 040562 Flat Washer 06437300 Cotter Pin 06713500 1/2”...
-
Page 9: Plastic Grommet
INSTALLATION OF POWER BRUSH TO RAPID UNITS 3, 4, 5 & 6 Washer & 1. Install Rapid adapter kit number 78510700 to the Lynch Pin unit (figure 6). See kit 78510700 for installation instructions. Rapid Adapter Kit 78510700 Engage Attachment Locking Pin Rapid Adapter Kit 78510700 Hex Bolt, Spacer, Nut... -
Page 10: Nylon Locknut
4. Install the control rod bracket grommet (item 19) INSTALLATION OF POWER BRUSH TO into the hole in the control rod bracket (item 21). FOUR-WHEEL TRACTOR WARNING: Unintentional startup or contact with exposed components can cause severe personal injury. Stop the engine, wait for all parts to come to a complete stop, remove the key from the ignition switch, and disconnect the spark plug wire before performing any... - Page 11 7. Install control rod (item 18) to power brush (item 1) 3. Install grommet (item 12) in the control rod guide with flat washer (item 22) and cotter pin (item 23) (item 11). (figure 12). 4. Put the bushing (item 8) on the top right side attachment adapter stud.
-
Page 12: Figure
INSTALLATION OF POWER BRUSH TO THE GEAR TWO-WHEEL TRACTOR Latch Washer & Pivot Release Lynch Pin WARNING: Unintentional startup or contact with exposed components can cause severe personal injury. Stop the engine, wait for all parts to come to a complete stop, remove the key from the ignition switch, and disconnect the spark plug wire before performing any maintenance, installation, removal, or... -
Page 13: Removal
REMOVAL WARNING: AVOID INJURY. Read and Rapid Adapter Kit 78510700 understand the entire Safety section before proceeding. REMOVAL OF POWER BRUSH FROM RAPID UNITS 1. Remove washer and lynch pin from Rapid adapter kit (figure 17). 2. Remove power brush (item 1) from Rapid adapter kit and double universal joint (item 2). -
Page 14: Figure
7. Separate the power brush from the tractor. Put the 1. Lower the stand on the tractor to keep the rear of universal joint on the drive shaft of the power brush. the tractor from falling to the ground when the (figure 10). -
Page 15: Operation
OPERATION 6. Place the brush the angle needed and sweep a WARNING: AVOID INJURY. Read and distance of 10 feet (3 m). Place the key switch in understand the entire Safety section before the off position, wait for all moving parts to come to proceeding. -
Page 16: Maintenance
MAINTENANCE WARNING: AVOID INJURY. Read and understand the entire Safety section before proceeding. Gravely Dealers will provide any service or adjustments which may be required to keep your unit operating at peak efficiency. Interval Task Action After 4 Adjust the chain. -
Page 17: Service And Adjustments
SERVICE AND ADJUSTMENTS BRUSH ANGLE ADJUSTMENT WARNING: AVOID INJURY. Read and To adjust the brush angle: understand the entire Safety section before proceeding. 1. Start the engine. Wait until the engine is running smoothly before operating. NOTE: Perform steps 2 through 7 for Gear Two-Wheel WARNING: Unintentional startup or contact with Tractors and Four-Wheel Tractors.Perform steps 8 exposed components can cause severe... - Page 18 CHAIN ADJUSTMENT 5. Remove the bolts from the flangette bearing on each end of the brush. See figure 24. To adjust the power brush drive chain: 6. Remove the brush from the support frame. IMPORTANT: Adjust the chain after the first four hours of 7.
-
Page 19: Storage
STORAGE Clean plastic surfaces with sponge and mild detergent. WARNING: AVOID INJURY. Read and Dry with a soft cloth. understand the entire Safety section before Remove all dirt, grease, leaves, etc. from unit. proceeding. Store in a clean, dry area. IMPORTANT: NEVER spray unit with high-pressure Ensure all fasteners are properly tightened. -
Page 20: Parts List
PARTS LIST CONTROLS... - Page 21 CONTROLS (CONTINUED) Item Part No. Qty. Description 05962900 Bolt-Hex .38-16 x 2.25 Grade 5 06436200 Washer-Flat-Steel .406 x .812 x .065 019261 Weldment-Bracket 06437300 Washer-Flat-Steel .281 x .62 x .065 (Two- & Four-Wheel Tractors Only) 06707300 Pin-Cotter.125 x.750 (Two- & Four-Wheel Tractors Only) 05957900 Bolt-Hex.38-16 x 1.50 Grade 5 06529800...
- Page 22 FRAME, GUARDS, AND WHEELS...
- Page 23 Part No. Qty. Description 05947900 Bolt-Hex .25-20 x .50 Grade 5 019479 Decal-Caution 019290 Hood 02460800 Decal-Gravely Logo 19291 Plate-Side 05947000 Bolt-Hex .31-18 x .75 Grade 5 06437200 Washer-Flat-Steel .344 x .688 x .065 06530200 Nut-Locking-Center .31-18 022166 Weldment, Power Brush Pivot 05962000 Bolt-Hex .50-13 x 1.50 Grade 5...
- Page 24 DRIVE AND BRUSH...
- Page 25 DRIVE AND BRUSH (CONTINUED) Item Part No. Qty. Description 022115 Brush-44" 022117 Spacer-Square 1.010 x 2.000 x .125 06713100 Pin-Cotter .25 x 2.00 022116 Shaft-Power Brush 019275 Shaft 019287 Sprocket 019288 Chain-Roller 019282 Sprocket 06601200 Key-Woodruff .25 x .750 x .313 SAE 91 019272 Coupling 1.6 x 1.37 014637...
- Page 26 TWO-WHEEL & FOUR-WHEEL TRACTOR COMPLETING KITS...
- Page 27 TWO-WHEEL & FOUR-WHEEL TRACTOR KITS (CONTINUED) Item Part No. Qty. Description 78701400 Kit, Power Brush for 4-Wheel Tractor (Includes Items 2-20) 012134 Kit, Universal Joint Repair 040561 Rod, Control 013518 Universal Joint-Female End 019866 Weldment, Adapter 019871 Universal Joint-Male 040562 Bracket 05967100 Bolt-Hex .25-20 x 2.00 Grade 5...
-
Page 28: Warranty
1000 hours of use, whichever comes first. An upon examination by the Ariens Company to be defective or authorized Gravely dealer will repair any defect in material or worn out. Replacements will be supplied free of charge. - Page 29 • Warranty service must be performed by a respective Ariens or Gravely authorized service representative. • Parts that are not genuine Ariens or Gravely brand service parts are not covered by this warranty. • To find an Ariens or Gravely authorized service representative, contact Ariens at: •...
- Page 30 GRAVELY A Division of Ariens Company 655 West Ryan Street P.O. Box 157 Brillion, WI 54110-0157 920-756-2141 Fax 920-756-2407 www.gravely.com...
