Network Video Server-NVS2004 Table of Contents Introduction 1.1 What Is a Network Video Server (NVS2004)? ------------ 1.2 Specifications ------------ Physical Connections 2.1 Front / Rear Panels ------------ 2.2 Connection Diagram ------------ Installation 3.1 Identifying Components ------------ 3.2 General Network Connection Procedures 3.2.1 Connecting NVS To a Local Area Network...
The S-Series NVS2004 is an IP-based surveillance system equipped with built-in web server, embedded operating system and H/W image compression chip. Users simply plug in analog cameras and an Ethernet cable to the Network Video Server (NVS2004) unit to transmit video images over TCP/IP network.
Network Video Server-NVS2004 PHYSICAL CONNECTIONS 2.1 FRONT / REAR PANELS Front Panel Power On (LED) Constantly green when powered on Network connected : constantly red LAN (LED) Data sending : blinks red Video Input (LED) Constantly green when video signals are received...
INSTALLATION .1 IDENTFYING COMPNENTS The S-Series NVS2004 comes with the items listed below. Identify the following com- ponents to make sure everything has been properly included with the product package provided. If any of the following items are missing, please contact your local distribu- tor.
3.2 GENERAL NETWORK CONNECTION PROCEDURES 1) Prepare a PC with Ethernet connection. Installation PC 2) Connect NVS2004 to your network using a Standard CAT5 Cable or to your PC di- rectly using the cross-over cable provided. Crossover Cable 3) Run the IP Master program (from the CD provided) on the PC and assign an IP Address to the NVS2004.
Network Video Server-NVS2004 3.2.1 CONNECTING THE NVS2004 TO A LOCAL AREA NETWORK The following procedure describes how to set up the S-Series NVS2004 when connecting to a local area network. Remote Client Router Network Hub NVS2004 1) Connect NVS2004 to your network hub with a standard CAT5 cable.
Page 10
Note: Factory default: Administrator ID: root 8) Connect the video cables from the cameras to the NVS2004 and use the Web Viewer to verify the images are transmitting properly. Note: Open your web browser and enter the URL (ex ; http://192.168.10.3) in the Address field.
Network Video Server-NVS2004 3.2.2 CONNECTING THE NVS2004 DIRECTLY TO A PC The following procedure describes how to set up the S-Series NVS2004 when connect- ing it directly to a PC. Cross-over Cable NVS2004 1) Connect NVS2004 to the PC prepared by connect cross-over cable.
Network Video Server-NVS2004 3.2.3 CONNECTING NVSDIRECTLY TO A xDSL Modem The following procedure describes how to set up the S-Series NVS2004 when connect- ing to an xDSL Modem. DDNS Server Remote Client XDSL Modem NVS2004 1) Connect NVS2004 to the xDSL Modem using a Network Cable.
Page 13
8) Remove the cross-over cable from NVS2004 and connect it directly to xDSL modem with standard CAT5 cable. And reboot the NVS2004. 9) Connect the video cables from the cameras to the NVS2004 and use the Web Viewer to verify the images are transmitting properly.
Network Video Server-NVS2004 3.2.4 CONNECTING NVS2004 THROUGH A NAT ROUTER The following procedure describes how to set up the NVS2004 when connecting to a NAT Router. DDNS Server xDSL Modem Remote Client NAT Router NVS2004 1) Connect xDSL modem to WAN port of NAT router.
Page 15
11) Forward web and video streaming port from NAT router. Note: Factory default web port: 80, video streaming port: 2000. 12) Connect the video cables from the cameras to the NVS2004 and use the Web Viewer to verify the images are transmitting properly.. Note: Open web browser and enter the URL (ex ;...
The Dynamic Domain Name Server (DDNS) will translate your dynamic IP address to a static domain name. This allows a NVS2004 with a Dynamic IP Address to be accessed using a static domain name If you connect the NVS2004 through dynamic IP or through a NAT router, you’ll need to use DDNS to track the IP Address of the...
Page 17
Network Video Server-NVS2004 3) Run IP Master. Or open Admin page from web browser. And input registered DDNS ID/ Password to your NVS2004. Note: If you have DDNS ID “abc” for example, the URL is http://godvr.net/abc. Note: E-mail address is used to reregister if the DDNS ID is forgotten.
Page 18
Network Video Server-NVS2004 Note: If you forget your DDNS ID, left click “Search” from main page. Enter the e- mail address and DDNS password. And left click “DDNS Search”. Then your DDNS ID will be displayed on the same page.
Network Video Server-NVS2004 CONFIGURING THE NVS2004 4.1 CONFIGURING THE NVS2004 You can configure the NVS2004 from web-based admin menu after installing NVS2004 on an IP Network. ID and Password with Administrator authority is required to access the admin menu. 1) Open web browser.
Network Video Server-NVS2004 4.2 BASIC SETTING Basic Settings are used to configure each cameras properties. 352x240 1) Video Server Name: enter any name that you desire to have. 2) Video / Bandwidth: a) Video Format: select NTSC or PAL. b) Resolution: select the video resolution.
2) Mac Address: every NVS2004 unit has unique Mac address. Its Mac address is displayed automatically in the field. 3) DDNS registration: when you use dynamic IP address or NVS2004 is behind NAT router, you should get DDNS ID and password after registration from www.gonvs.net.
Page 22
Factory default web port: 80, video streaming port: 2000. Note: You should forward these two ports from NAT router when NVS2004 is be- hind the router. 7) Enable UPnP: check on “Enable UPnP” to use UPnP (Universal Plug and Play) function provided from Windows XP.
Network Video Server-NVS2004 4.4 MOTION/COLOR SETTING 1) Video Channel: Select video channel to set motion properties and image color. 2) Motion Detection Setting: Draw multiple motion detection areas by drag & drop mouse. a) Sensitivity: Set motion sensitivity. 5 types of sensitivity can be selected (Lowest – Low – Medium – High – Highest) b) Select All Area: Sets whole area to motion detection.
Network Video Server-NVS2004 4.5 PAN/TILT SETTING 1) Video channel: select video channel to set PTZ properties. 2) PTZ Protocol: select the protocol type used with your PTZ unit. 3) PTZ Address: select the address identically to setting on each PTZ camera unit.
Network Video Server-NVS2004 4.6 DI/DO SETTING 1) Event setting: a) Sensor setting: select Sensor type “Normal Close” or “Normal Open” depending on the type used. b) Alarm alert time: select alarm device activation time (1 ~ 5 seconds) after event occur.
Check on “Ask ID/Password when connecting” to ask ID/Password when remote users access the NVS2004. 3) Time setting: a) Check on “Synchronized with this computer” to set the time of NVS2004 identi- cally with the computer connected. b) Check on “Manual setting” to enter the time manually.
Network Video Server-NVS2004 4.8 SYSTEM SETTING 1) Upload operating S/W: you can upgrade the operating system of NVS2004 by firmware upgrade. Download firmware upgrade file and load from this menu. 2) Upload PTZ Protocol file: you can load additional PTZ driver file from this menu.
Network Video Server-NVS2004 VIEWING THROUGH THE WEB BROWSER 5.1 STARTING WEB VIEWING THROUGH WEB BROWSER 1) Open web browser. 2) Type the URL (ex ; http://192.168.10.3) in the Address field. If you have DDNS ID, type http://godvr.net/DDNS ID (ex ; http://godvr.net/nvs) in the Address field.
Network Video Server-NVS2004 5.2 WEB VIEWER FUNCTIONS Image Viewing Window PTZ Control Button Screen Division Selection Snapshot Save snapshot of the camera selected (BMP) Admin Menu Access admin menu to configure Network Video Sound On/Off Alarm Activation Left click the No. to activate the alarm Camera Selection Left click the No.
You can view, record and search video images from multiple NVS2004s (up to 9) by the Multi-Client software provided. You can install using program CD coming with NVS2004. Simply run Setup.exe from installation program folder (ex ; MultiClient-2006-00-00). After installation, the below program shortcut will be created in Windows desktop.
Network Video Server-NVS2004 6.2 FUNCTIONS ON LIVE MODE GUI Connect Disconnect Image Viewing all servers all servers Window Server List PTZ Control Button Event Manager Cascadia Video Products Version 1.0.1 Rev 9.27.07 (888) 421-0050...
IP address. 5) Enter the video streaming port no. as set in Network setting of Admin menu (factory default :2000). The port should be forwarded if NVS2004 is behind router or firewall. 6) Enter Login ID/Password as in User setting of Admin menu.
Page 33
Network Video Server-NVS2004 9) Right-mouse click on site name on server list and select “Connect”. Then the site will be connected. 10) Click each channel no. to view video. Or right-mouse click on site name and se- lect “View All Channel”.
Network Video Server-NVS2004 6.4 RECORDING IMAGES 1) Left click “Client Setup Menu But- ton”. 2) Select “Record Schedule Tab”. 3) And select the channel no. under each site. Select day/time to set recording by drag & drop on the time table.
Network Video Server-NVS2004 6.5 SEARCHING THE IMAGES Left click “Search Button” to enter search menu. Then the below search menu shows up. Playback Channel Selection Playback Channel On/Off Playback Control Brightness Sharpness Volume Search Mode Print Image Screen Division Selection...
Page 36
Network Video Server-NVS2004 Cascadia Video Products Version 1.0.1 Rev 9.27.07 (888) 421-0050...
