On Que Lighting Designs CNF DMX RGBW Operation Manual

Crash 'N Flash DMX Stage Lighting/Effects Systems

Technical information/operation manual

The CNF DMX RGBW Stage Lighting/Effects System consists of a CNF crash cymbal
trigger interfacing with the CNF DMX RGBW Lighting Control Module through its
four COLOR CODED 1/4" CNF TRIGGER INPUT jacks. Accepting up to 4 (8 with
The CNF DMX RGBW stomp box Stage Lighting/Effects Module is a DMX
master/controller device, sending out an industry standard DMX data command and
connects to DMX slaves through its 3-pin XLR connector.
The CNF DMX RGBW Stage Lighting/ Effects Module has a blackout switch (stomp
button) which toggles between a blackout state and an operational state. On board
LED mode indicators signify operational state (GREEN-system active) or (RED-
blackout, power/standby). In blackout state, all connected DMX devices are
The CNF DMX RGBW Lighting/Effects Module may be operated in 'stand alone'
mode as well without the use of CNF cymbal triggers for certain Stage Effects such as
foggers, lasers, DJ applications, etc. This mode requires a separate DMX interface
input module inserted into one (1) or more of the 4 color coded CNF trigger input
jacks. DMX output is then controlled solely through the footswitch stomp button
engaging 'system active' and 'blackout, power/standby'.
RGB (multi-color) LED fixture addressing:
Set your LED fixture(s) to channel
With master fixture and all concurrent fixtures set to this mode and address;
#1- CNF 'RED' input will cause up to 32 daisy chained fixtures to turn RED
#2- CNF 'GREEN' input will cause up to 32 daisy chained fixtures to turn GREEN.
#3- CNF 'BLUE' input will cause up to 32 daisy chained fixtures to turn BLUE.
#4- CNF 'WHITE' input will cause up to 32 daisy chained fixtures to turn a COMBINATION
standard 'Y' cables' ) CNF crash cymbal triggers.
commanded to go to off.
IMPORTANT!
of RED, GREEN, and BLUE resulting in a WHITISH hue.
(CNF)
3
mode with a DMX address of
1
.
