Feniex Product Copyrights This price List and the mentioned Feniex products include or describe copyrighted Feniex material. Laws in the
United States and other countries preserve for Feniex Industries and its licensors certain exclusive rights for copyrighted material, including the
exclusive right to copy, reproduce in any form, distribute and make derivative works of the copyrighted material. Accordingly, any copyrighted
material of Feniex and its licensors contained herein or in the Feniex products described in this Price List may not be copied, reproduced,
distributed, merged or modified,transmitted, transcribed, stored in retrieval system or translated into any language or computer language, in any
form or by any means, without prior written permission of Feniex Industries, Inc.. Feniex and the stylized Feniex logo are registered in the U.S.
Patent & Trademark Office.
Fen iex S ma r t Mir ror I nstr uc tion Ma nu al
Feniex Smart Mirror
C-1111
1. 800 .615 .83 50 / fen iex.com
Advertisement
Table of Contents
Summary of Contents for Feniex C-1111
- Page 1 Feniex Industries, Inc.. Feniex and the stylized Feniex logo are registered in the U.S.
-
Page 2: Table Of Contents
Safety Regulations & Warranty Service after Expiration Copyright Feniex Product Copyright Limitation of Liability Equipment Dimensions Box Contents System Specifications Mounting Instructions Wiring Diagram Product Information Applications Pairing Up Feniex Indu stries , Inc. 1 .800. 615 .8350 / feni ex.com... -
Page 3: Safety Regulations & Warranty
Warranty The products described in this document Feniex Industries, Inc. warrants to the original are the property of Feniex Industries, Inc. It is purchaser that the product shall be free furnished by express license agreement only from defects in material and workmanship... -
Page 4: Limitation Of Liability
Limitation of Liability Please Read! Feniex Industries assumes no liability for the use of the Smart Mirror. Please read more... Warning: The entire risk as to the results and performance of the product is assumed by you. We shall not have any liability to you or... -
Page 5: Equipment Dimensions
Equipment Dimensions 4.63" 1.13" 3.19" 9.75" Feniex Indu stries , Inc. 1 .800. 615 .8350 / feni ex.com... -
Page 6: Box Contents
Box Contents Product: Quantity Smart Mirror Mount Bracket Screws Base Bracket Screws Mirror Feniex Indu stries , Inc. 1 .800. 615 .8350 / feni ex.com... -
Page 7: System Specifications
Feniex Smart Mirror Specification: Input Voltage: 12.88V Working Temperature: -13F to 176F Temperature Range: Storage Temperature:L -31F to 203F Main Fuse: 2amp Housing: Plastic Bracket Metal Memory Storage: 8GB SD Card Feniex Indu stries , Inc. 1 .800. 615 .8350 / feni ex.com... -
Page 8: Mounting Instructions
Keep the base plate from the mirror attached to the window. 5.) Slide the base of the mirror (attached to mirror) onto the the plate on the window. Feniex Indu stries , Inc. 1 .800. 615 .8350 / feni ex.com... -
Page 9: Wiring Diagram
ACC (+12VDC) Connects to red terminal of the battery BACK (+12VDC) Wire to connect optional back-up camera VIDEO IN Wire to the rear camera video feed Feniex Indu stries , Inc. 1 .800. 615 .8350 / feni ex.com... -
Page 10: Product Information
Product Information Mini USB Time Micro SD Card Back Home Volume Microphone Camera Power Feed Camera Fen iex Indu s tries, Inc. 1 .8 00. 615 . 8350 / feni ex.com... -
Page 11: Applications
Applications Feniex 4200 Controller - Controller interface for the 4200. Connects to the relay via bluetooth module. To adjust the controller settings, download the software on Feniex.com. Settings - Control your wifi, bluetooth, data usage settings. Adjust your display, sound & notifications, storage and apps. Set your location, security language &... -
Page 12: Pairing Up
Bluetooth The Feniex 4200 has the option of being controlled by the Smart Mirror. To enable this feature you will require the Feniex in-line Bluetooth module. Follow the installation instructions below to pair the 4200 with a Smart Mirror: 1.) Turn the Smart Mirror and 4200 systems "on"...
