PA103 / PA104
Power Amplifier
Installation Guide
Help you to set the outdoor power
amplifier correctly and quickly.
Version 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PA103 and is the answer not in the manual?

Questions and answers

Summary of Contents for Azuretec PA103

  • Page 1 PA103 / PA104 Power Amplifier Installation Guide Help you to set the outdoor power amplifier correctly and quickly. Version 2.0...
  • Page 2: About This Manual

    Copyright Copyright © 2003 all rights reserved. No part of this publication may be reproduced, adapted, stored in a retrieval system, translated into any language, or transmitted in any form or by any means without the written permission of the supplier. About This Manual The purpose of this manual is for the setup of Amplifier &...
  • Page 3: Table Of Contents

    Table of Contents Introduction ..................3 1-1 Product Kit ..................... 3 1-2 Features and Benefits ................ 4 1-3 Specifications ..................5 1-4 Calculate Transmit Power..............7 1-5 Installing the Amplifier Kit ............... 8 Appendix A: Channels and Cable Attenuations ......10 Appendix B: Troubleshooting ..............
  • Page 4: Introduction

    Introduction This Amplifier, operating on the 2.4GHz ISM band, is a high performance two-way amplifier using Time Division Duplex (TDD) technology. It is used outdoor to extend the range of wireless radio communication. The DC injector functions as a provider of DC power to the outdoor amplifier or transponder through the feed cable without an additional power cord.
  • Page 5: Features And Benefits

    1-2 Features and Benefits 2400~2500 MHz unlicensed ISM Band Provides DC Power to the amplifier without an additional Power cord Amplifier has 2W/4W output power levels. 20dB receive gain for the amplifier Bi-directional TDD technology Transmitter and receiver LED indicator Weather-proof housing Compatible with IEEE 802.11b Extending transmission distance...
  • Page 6: Specifications

    1-3 Specifications Specifications for DC Injector Operating Frequency Range 2400~2500MHz Bias Current / DC Voltage 3.0A (max.) / 15V (max.) Insertion Loss Connector / DC Jack N type female for both sides / φ 6 mm, center pin φ 2.0 mm Dimensions / Weight 99.1(H)x53.5(W)x21.2(H)mm / 165g Specifications for Amplifier...
  • Page 7 < 4 dB Switch Time < 2 µs Connector N-type Female (50Ω); Operating Temperature -30~60℃ Power Consumption 2W, 1.3A @ 12VDC 4W, 1.8A @ 12VDC LED Indication Transmit: Green; Receive: Red Dimensions 198(L) x 88(W) x 29(H) mm Weight 500g...
  • Page 8: Calculate Transmit Power

    1-4 Calculate Transmit Power In order to obtain the best performance of amplifier and system, user must calculate the transmission power to meet the amplifier technical requirement and FCC regulations. It is advised that the user follows the calculation below: Converter power of the access point from mW to dBm.
  • Page 9: Installing The Amplifier Kit

    1-5 Installing the Amplifier Kit Once input signal level is determined to be in conjunction with the technical requirement of amplifier, please proceed to install the amplifier kit with following procedures: Connect the amplifier RF output (To Antenna) directly to the antenna with appropriate cable.
  • Page 10: Amplifier Installation

    To 2.4GHz Antenna RF Output interface of Access Point Amplifier RG-6U Cable To Omni-directional, DC Injector or Grid or Panel Antennas N-female to N-female adapter to attach to the N-male on cable 110/220 VAC Main Power Amplifier Installation...
  • Page 11: Appendix A: Channels And Cable Attenuations

    Appendix A: Channels and Cable Attenuations Table A – Conversion Table 802.11b Channel Frequency(MHz) 2412 2417 2422 2427 2432 2437 2442 2447 2452 2457 2462 Table B – Authorized Cables with Minimum Length Cable Type Minimum Length Maximum Recommended Length RG6/U 35 feet 75 feet...
  • Page 12: Appendix B: Troubleshooting

    Verify if the transmit power which calculated before is correct. If none of the above measures could solve troubleshooting, please contact the supplier for further support. Tel: +886-2-29101997 Fax:+886-2-29103996 Email:sales@azuretec.com www.azuretec.com / www.azuretec.com.tw...
