- Page 1 User guide Verizon Digital Signage LTE Media Player Whatever your industry, Verizon Digital Signage can help you build your brand and deliver great customer experiences.
- Page 2 User guide Contents Review your hardware........................................3 Connect the parts..........................................4 Mount the Media Player........................................6 Confirm Media Player setup......................................7...
-
Page 3: Review Your Hardware
User guide Box contents Ports and connections Required parts: 1. Reset key, microSD slot and Micro USB connector Review your 1. LTE Media Player with embedded 4G LTE SIM 2. HDMI cable 2. RJ45 port, USB-C and HDMI connector 3. USB-C power adapter with cable hardware. -
Page 4: Connect The Parts
User guide HDMI cable Antenna setup 1. Insert the HDMI cable into the Media Player. Connect 1. Screw the first white antenna into the LTE port. 2. Insert the HDMI cable into the HDMI port on the display.* 2. Screw the second white antenna into the DIV port. the parts. - Page 5 User guide Power 1. Plug the USB-C cable into the Media Player. Connect 2. Plug the USB-C cable into the power adapter. the parts. 3. Plug the USB-C adapter into a power outlet.
-
Page 6: Mount The Media Player
User guide Choose from two options to mount the Media Player to the display. Mount the 1. Use two M3 or .1181" screws or smaller to attach Media Player. the Media Player. Brackets are included, screws are not included.* Attach the Media Player at the 2. -
Page 7: Confirm Media Player Setup
User guide On-Player status Confirm Media The Media Player status light will light up, indicating status. Status indicator: Player setup. - Page 8 For the Media Player to work properly, 4G LTE wireless connectivity is required. Please refer to 4G LTE Coverage on vzw.com for more information. If you experience and setup issues, contact support at 1.800.525.0481. Network details & coverage maps at vzw.com. © 2017 Verizon. UG1420817...
