Related Manuals for TENSITRON ACM-100
Summary of Contents for TENSITRON ACM-100
- Page 1 Operating Instructions ACM-100 Aircraft Cable Tension Meter...
- Page 2 The ACM-100 is shipped calibrated and ready to use on 1/16", 3/32", 1/8" and 5/32" diameter aircraft cables. Before each use: Verify that the serial number on the instrument and the calibration chart match, as readings may vary among instruments.
- Page 3 Pointer does not reset at 0 with memory lock "off." b. Instrument has been dropped. c. For use on aircraft, the ACM-100 must be calibrated at intervals not to exceed 12 months. Check that the calibration and certification are current.
- Page 4 OPERATING INSTRUCTIONS FOR ACM-100 CABLE TENSION METER Reference Pivots 3/32 Rotating Riser Memory Lock Button Closure Bar Figure 1 ACM-100 Operating Instructions Page 3...
- Page 5 8. If tension value is considered “critical”, remove the cable from the aircraft and perform a dead weight calibration. Note: If calibration results differ greatly from the original calibration, or if minimum or maximum values cannot be indicated on the instrument dial, return to Tensitron for service. ACM-100 Serial No.
