• For optimum safety, always give the hand control to the patient before starting the system. • Explosion hazard: KINETEC Maestra is not designed for use in the presence of flammable anesthetics. • Check that the electrical socket is in good condition and is suitable for the splint power supply cord. The latter complies with current standards and has a grounding socket. -
Page 3: Definition
Definition The KINETEC Maestra is used for passive mobilization of the hand and wrist and permits a wide range of possible joint movements for: The forearm The wrist The thumb The long fingers • Indications • Flexor and extensor tenolysis. -
Page 4: Description
Description The KINETEC Maestra is a portable machine, single unit device that can be used on a table. It consists of the following components: 1 • Casing encloses the motor and the power PCB. 2 • Forearm support. 3 • Transport handle. -
Page 5: Safety
KINETEC Maestra is not designed for use in the presence of flammable anaesthetics. In case of electromagnetic interference with other devices move the device. KINETEC Maestra is in compliance with standards in force (IEC 601.1.2), electromagnetic compatibility standard for medical devices. -
Page 6: Use Of The Hand Control
We recommend that you lock the hand control when you give it to the patient. Comment: The hand control is unlocked when you switch the unit ON/OFF. START/STOP/REVERSE function As with all KINETEC systems, KINETEC Maestra is equipped with a START/STOP/REVERSE function. When the unit is running, the display reads RUN Press the key of the hand control. -
Page 7: Quick Start
Set up the patient and proceed as below: Beginning Keys to press Display Remarks Switch the unit ON KINETEC Maestra V01.0 Check if the hand control is not locked Please wait (See page 5). Prona/supination STOP The display shows the new movement selected... -
Page 8: How To Adjust The Basic Parameters Of The Movement
To validate the new value press another key ext/fle or wait more than 3 seconds. The display shows the The unit is ready to start with the new STOP selected mode. parameters. Comments: • The values shown in the ‘Display’ column are examples. Maestra 7/21... -
Page 9: How To Modify Programs Program Mode
Display Remarks To switch off the unit KINETEC Press the two keys at the same time and switch the unit Welcome text during 3 seconds. maestra V01.0 Program Then The program number blinks. EMPTY Program To change the program if necessary EMPTY The new program number blinks. - Page 10 Use of the hand control Comments: Program • When a program has been deleted, the display shows EMPTY Program table: Maestra 9/21...
-
Page 11: Using Programs
Use of the hand control Using Programs The KINETEC Maestra allows you to store up to 16 programs, including the type of movement, ROM, speed, load, pauses and timer. The original parameter values of the program are empty. These values can be modified and recorded at any time (see ‘How to enter a program’ page 10). -
Page 12: How To Define The Upper And Lower Movement Limits
The MANUAL MODE is a way to set within the tolerance of a patient at the beginning of a session. Set up the patient and proceed as below: Beginning Keys to press Display Remarks KINETEC maestra V01.0 Check if the hand control is not locked Switch the unit on (See page 5). Please wait Prona/supination STOP... -
Page 13: Start Up
Make sure that when the driving mechanism is inserted on the motor axis, the cable (4) is ABOVE the groove of the cam (5). The driving mechanism should then be locked in place by tightening the screw (6) with the Allen key included in the accessory case. Maestra 12/21... -
Page 14: Adjusting The Length Finger
To better fit individual hand lengths and polar radii depending on the fingers or thumb to be mobilized the guide will be oriented as follows by unscrewing the nut (8) and lifting the guide (7), in position (A) or in position (B). Guide in position A Guide in position B Maestra 13/21... -
Page 15: Possible Movements
Possible movements Pronation / Supination The KINETEC Maestra provides a motion from 90° of pronation to 90° of supination • Choice of the Pronation / Supination movement: - Press and adjust your parameters (see page 7). - Or select a program (see page 10). -
Page 16: Extension / Flexion Of The Wrist And The Mp Joints Of The Fingers
Possible movements Extension / Flexion of the wrist and the MP joints of the fingers The KINETEC Maestra provides a motion from -50° to 140°. • Choice of the 2 movement of the wrist: - Press 2 times and adjust your parameters (see page 7). -
Page 17: Thumb Opposition
Possible movements Thumb opposition The Kinetec Maestra provides a motion from 0° to 180°. - Select the accessories - Set up the guide disc for the thumb movement - Make sure that the opening (A) is correctly positioned. - Screw the guide with the screw (1). -
Page 18: Complete Fist
Possible movements Complete fist The KINETEC Maestra provides a motion from -30° to 225°. • Choice of the complete fist movement: - Press and adjust your parameters (see page 7). - Or select a program (see page 10). Intrinsic + The KINETEC Maestra provides a motion from 0°... -
Page 19: Intrinsic
Possible movements Intrinsic - The KINETEC Maestra provides a motion from 0° to 180°. • Choice of the intrinsic - movement: - Press 2 times and adjust your parameters (see page 7). - Or select a program (see page 10). -
Page 20: Product Information
The need for maintenance is indicated by display of the message SERV. MOTOR when the system is switched on. Despite that warning, you can continue to use your KINETEC Maestra by pressing START, but you should contact your nearest KINETEC technician to have the maintenance operations conducted as soon as possible. -
Page 21: Symbols Used
The warranty will also be considered null and void in the event of deterioration or an accident due to negligence, inappropriate surveillance or inappropriate maintenance, or due to transformation of the equipment or an attempt to repair the equipment. Maestra 20/21... -
Page 22: Maintenance Sheet
