- Page 1 Refs. 563832 QUICK TWIN HDMI/YPbPr MPEG2/4 ENCODER/MODULATOR - QAM/COFDM INSTALLATION GUIDE w w w . t e l e v e s . c o m...
-
Page 2: Safety Instructions
OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. DECLARACIÓN DE CONFORMIDAD DECLARATION OF CONFORMITY DECLARAÇÃO DE CONFORMIDADE DECLARATION DE CONFORMITE DICHIARAZIONE DI CONFORMITÀ DEKLARACJA www.televes.com ZGODNOŚCI KONFORMITÄTSERKLÄRUNG ΠΙΣΤΟΠΟΙΗΤΙΚΟ ΣΥΜΜΟΡΦΩΣΗΣ FÖRSÄKRAN OM ÖVERENSSTÄMMELSE ДЕКЛАРАЦИЯ СООТВЕТСТВИЯ... -
Page 3: Description Of Connectors
Description of connectors Front view Rear view 1.- Power connectors 1.- YPbPr component input. Channel 1 2.- Ethernet connector 2.- CVBS input. Channel 1 3.- Ethernet connector 3.- Analog (L/R) audio input. Channel 1 4.- Programmer connector 4.- HDMI input. Channel 1 5.- RF loop through input 5.- SPDIF digital optical audio input. -
Page 4: Installation
Installation Connect the programmer to each unit and set a unique number in Install all units in the rack and connect them as shown in Figure 1. the “# ID” field according to the order of installation of the units in the rack. - Page 5 The Status > Summary page should appear as the first page. This provides a summary of all the units installed in the network and the units will be sorted by the number entered in Step 5. The “Change Password” option only changes the password of the encoder currently logged in to.
-
Page 6: Menu Flow Chart
Menu flow chart For programming Unit operation Enable edit mode / Position cursor FW VERSION>> SELECT - OUT MODE - MODULE REF (in edit mode) / A/V INPUT COFDM Disable edit mode. 563822 INPUT 1 FW VERSION>> - INPUT OUTPUT Change section / SELECT OUT FPGA SW/HW... -
Page 7: Technical Specifications
Technical specifications Reference 563832 2 sets - 3x RCA for Video (Y, Pb, Pr) VIDEO Connectors 2 sets - 1x RCA for CVBS Video 2 sets - 2x RCA for Analog Audio (L, R) INPUTS AUDIO Connectors 2 sets - 1x RCA for Digital Audio 2 sets - 1x Toslink for Digital Audio (Optical) VIDEO + AUDIO Connectors... - Page 8 televes.com...
