INSTALLATION / OPERATING MANUAL
IR Speed PTZ Camera
- Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
- The design and specifications are subject to be changed without prior notice to improve
product's quality.

Advertisement

Table of Contents
loading

Summary of Contents for 3D-Inc TPD-HD330NRW

  • Page 1 INSTALLATION / OPERATING MANUAL IR Speed PTZ Camera - Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. - The design and specifications are subject to be changed without prior notice to improve product’s quality.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. PRECAUTIONS 1. 1 Important Safety Instruction ................... 2. GETTING STARTED 2. 1 Unpacking ......................2. 2 Part name ....................... 2. 3 DIP Switch Setting ....................2. 4 Cable Connection ....................3. INSTALLATION 3. 1 Installation ......................4.

  • Page 3: Precautions

    1. PRECAUTIONS 1. 1 Important Safety Instruction • Read these instructions. • Pay attention on all the warnings. • Follow all instructions. • Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. • Do not dissemble or insert foreign objects. •...

  • Page 4: Getting Started

    2. GETTING STARTED 2. 1 Unpacking The following parts are supplied with the outdoor speed PTZ system. <Figure 1. package Components> Body Mount Analogue video cable SCREW(M4*8 SUS) SCREW (SET ANCHOR 1/4") Screw Screw Mount Bolt Mount joint Manual Power adaptor(Option) <Wall type>...

  • Page 5: Dip Switch Setting

    2. 3 DIP Switch Setting Before start up the camera, set the protocol and camera address and termination set with dip-switches and click-switches as shown in the below diagram. 1.Set the camera address (ID) Open the top cover of the product to set camera address. S1 : 1-digit number of address S3 : 10-digit number of address Address switch...

  • Page 6: Cable Connection

    2. 4 Cable connection 2. 4. 1 Power/Data communication cable connection ALM1 ALM5 Tx + / Tx - ALM2 ALM6 TRx+ TRx- ALM3 ALM7 ALM4 ALM8 CVBS R1-NC R2-NC R1-NO R2-NO HD-SDI AC24 POWER AC 24V R1-COM R2-COM AC24 NETWORK ALARM INPUT(I/O 1) ALARM INPUT(I/O 2) Coaxial cable...

  • Page 7: Installation

    3.Installation - The following steps of installation and connection work should be done by qualified service personnel or system installers and should conform to all local codes. - Be sure to switch the camera off before installation is completed. - Do not install the camera near the air outlet of an air conditioner. - Before installation, set the system with Dip switch on the back side of the mechanism part, and assemble the mechanism and housing according to the below instruction 3.
  • Page 8 Front Front After connecting the cable, set the mount in the proper position and fix the 2 screws (M4*8) safety loop OPEN CLOSE (Turn the body to clockwise) 1. Connect the safety loop on the body and mount back side. 2.

  • Page 9: On-Screen Display Program Menu

    4. ON-SCREEN DISPLAY PROGRAM MENU The initialize screen is shown up to check address, version, INITIALIZE protocol and video when the power on. PTZID : 001 FIRMWARE : X.XX V-FORMAT : 1080p30 You can not go into the menu in the IP mode. CVBS : NTSC PROTOCOL...
  • Page 10 (1) Select the Preset number P01 : Defined Preset number / 01 : Undefined Preset number Move : Select : NEAR PRESET MENU PRESET MENU PRESET SELECT : 001 P001 P002 P003 P004 P005 PRESET NO : 01 UNDEFINE LABEL : POSITION : XXX .
  • Page 11 (4) Select the focus mode for Preset Select the Focus menu Move and set the Focus Menu NEAR PRESET MENU PRESET NO : 01 DEFINE LABEL : POSITION : 000. 0 ,000. 0 FOCUS AUTO On focus menu, there are 3 modes : Auto, Manual, Onepush. Focus will be adjusted once after preset moving.
  • Page 12 4. 1. 2 Tour MAIN MENU Tour Quick Operating Guide MOTION DOME CAMERA Set Tour 71~78 + 3sec. PRESET CLEAR PTZ RESET Set Tour 3sec. TOUR BACK EXIT < NEAR / RIGHT ▷ PRESET > Go to Tour 71~78 + PRESET Go to Tour TOUR...
  • Page 13 (2) Set the Tour Label Move : Select : Delete : TELE WIDE JOYSTICK JOYSTICK It’s available to set the desired label, displayed on the executing screen of Tour. TOUR MENU TOUR LABEL EDIT ( 01 ) LABEL : TOUR 01 TOUR NO : 01 DEFINE 0 1 2 3 4 5 6 7 8 9 ( LABEL :...
  • Page 14 4. 2. 3 Group MAIN MENU Group Quick Operating Guide MOTION DOME CAMERA Set Group : 101~106+ 3sec. PRESET CLEAR PTZ RESET Go to Group : 101~106+ PRESET BACK EXIT < NEAR / RIGHT PRESET > MOTION MENU PRESET TOUR GROUP SCAN PATTERN...
  • Page 15 (2) Set the Group Label Move : Select : Delete : TELE WIDE JOYSTICK JOYSTICK It’s available to set the desired label, displayed on the executing screen of Group. GROUP MENU GROUP LABEL EDIT LABEL : GROUP NO : 01 0 1 2 3 4 5 6 7 8 9 ( LABEL : ) A B C D E F G H I J K...
  • Page 16 4. 1. 4 Scan MAIN MENU Scan Quick Operating Guide MOTION DOME CAMERA Set Scan 81~88 + 3sec. PRESET CLEAR PTZ RESET Set Scan 3sec. Scan BACK EXIT < NEAR / RIGHT PRESET > Go to Scan 81~88 + PRESET Go to Scan Scan MOTION MENU...
  • Page 17 (2) Set the Scan Label Move : Select : Delete : TELE WIDE JOYSTICK JOYSTICK It’s available to set the desired label, displayed on the executing screen of Scan. SCAN MENU SCAN LABEL EDIT ( 01 ) LABEL : SCAN 01 SCAN NO : 01 DEFINE 0 1 2 3 4 5 6 7 8 9 ( LABEL...
  • Page 18 (5) Set the Scan speed SCAN MENU Increase : TELE SCAN NO : 01 DEFINE JOYSTICK LABEL : SCAN 01 START POS : 000 . 0 , 000 . 0 END POS : 000 . 0 , --- SPEED : 60 Decrease : WIDE DWELL...
  • Page 19 4. 1. 5 Pattern MAIN MENU Pattern Quick Operating Guide MOTION DOME Set Pattern 91~94 + 3sec. CAMERA PRESET CLEAR PTZ RESET Set Pattern 3sec. Pattern BACK EXIT < NEAR / RIGHT PRESET > Go to Pattern : 91~94 + PRESET Go to Pattern : Pattern...
  • Page 20 (2) Set the Pattern Label Move : Select : Delete : TELE WIDE JOYSTICK JOYSTICK It’s available to set the desired label, displayed on the executing screen of Pattern. PATTERN MENU PATTERN LABEL EDIT ( 01 ) LABEL : PATTERN PATTERN NO : 01 DEFINE 0 1 2 3 4 5 6 7 8 9 ( LABEL :...
  • Page 21 (5) “Save” above setting Pattern data to the memory. PATTERN MENU (6) “CLR” means above setting Pattern data will not be PATTERN NO : 01 DEFINE LABEL : saved and be cleared. RECORD <08SEC> PLAY (7) “EXIT” means it goes out of MENU. SAVE EXIT <...
  • Page 22 4. 1. 6 Area MAIN MENU MOTION MENU PRESET MOTION TOUR DOME GROUP CAMERA SCAN CLEAR PATTERN PTZ RESET AREA ALARM PRIVACY BACK EXIT BACK EXIT < NEAR / RIGHT PRESET > < NEAR / RIGHT AREA > The Area function means that it displays the Area name between two programmed pan positions. Maximun 16 Area functions are toured in order.
  • Page 23 (3) Define the Start pan position Select the “Start Pan Pos” menu Move and set the position Set & Back NEAR NEAR AREA START PAN POSITION AREA MENU AREA NO : 01 DEFINE LABEL : START PAN POS.: 000 . 0 STOP PAN POS.: 000 .
  • Page 24 4. 1. 7 Alarm MOTION MENU MAIN MENU PRESET MOTION TOUR DOME GROUP CAMERA SCAN CLEAR PATTERN PTZ RESET AREA ALARM PRIVACY BACK EXIT BACK EXIT < NEAR / RIGHT ALARM > < NEAR / RIGHT PRESET > The Alarm function means that the camera moves to the programmed Preset position by the Alarm trigger. Maximum 8 Alarm functions are toured in order.
  • Page 25 (3) Define the Preset position with Alarm trigger Select the “Preset No” Move and set the position Set & Back NEAR NEAR ALARM MENU PRESET SELECT 002 003 004 005 006 ALARM NO : 01 DEFINE 007 008 009 010 011 012 LABEL : 013 014 015 016 017 018 PRESET NO.

  • Page 26: Privacy Zone Masking

    4. 1. 8 Privacy Zone Masking MOTION MENU MAIN MENU PRESET TOUR MOTION DOME GROUP CAMERA SCAN CLEAR PATTERN PTZ RESET AREA ALARM PRIVACY BACK EXIT BACK EXIT < NEAR / RIGHT PRIVACY > < NEAR / RIGHT PRESET > The Privacy Zone Masking function means that it sets the blocking territories to prevent camera functions for the privacy of personal reasons.
  • Page 27 (3) “Save” above settings of Privacy Zone data to the memory. PRIVACY MENU (4) “CLR” means above setting of Privacy Zone data will not PRIVACY NO : 01 UNDEFINE be saved and be cleared. POSITION : XXX . X , XXX . X (5) “BACK”...

  • Page 28: Dome Setting

    4. 2 Dome Setting MAIN MENU MOTION DOME CAMERA CLEAR PTZ RESET BACK EXIT < NEAR / RIGHT PRESET > Pan, Tilt, Zoom motion is adjustable in the “Dome Setting” Menu. 4. 2. 1 Set the Dome camera title Move : Select : Delete : TELE...

  • Page 29: Set The Power Up Action

    4. 2. 3 Set the Power Up Action When this function is ON, the camera memorizes the latest action and restores, it from sudden power failure. Select : Set ON : Set OFF : NEAR NEAR DOME MENU TITLE VIDEO FORMAT POWER UP ACTION : ON PARK ACTION DISPLAY ON/OFF...
  • Page 30 (4) “BACK” means it goes back to the previous PARK MENU menu. TIME : OFF FUNCTION : NONE NUMBER : XX BACK < NEAR / RIGHT DWELL > 4. 2. 5 Display ON/OFF Set You can select the OSD ON to shown on the screen or clear by selecting OFF in this function. Select : Set ON : Set OFF :...
  • Page 31 4. 2. 6 DOME SUB MENU DOME MENU TITLE VIDEO FORMAT POWER UP ACTION : ON PARK ACTION DISPLAY ON/OFF DOME SUB MENU TEMP SET FACTORY SET SAVE BACK EXIT < NEAR / RIGHT TITLE SET > (1) DATA BACK/LOAD DOME MENU Backup or load the Motion, Camera and PTZ Setting Data DATA BACK/LOAD...
  • Page 32 - IR SYNC MODE DOME MENU ALS SYNC : Synchronized in visible light. IR SYNC MODE : ALS SYNC ALL ON : IR always on. IR ILLUMINATE : HIGHEST ICR CHG LUX : 2 LUX ALL OFF : IR always off. IR CONT.
  • Page 33 - IR OFFSET DOME MENU Set the IR sensitivity. (-4~4) IR SYNC MODE : ALS SYNC IR ILLUMINATE : HIGHEST Factory default is 0 ICR CHG LUX : 2 LUX IR CONT. TYPE : AUTO IR OFFSET Select : Set ON : NEAR Set OFF : NEAR...
  • Page 34 DOME MENU - WIPER INTERVAL TIME WIPER MODE : OFF 1 MIN / 2 MIN / 4 MIN / 6 MIN / 8 MIN / 10 MIN WIPER POS. : BOTTOM When WIPER MODE is INTERVAL, WIPER TIME function is WIPER TIME : XXXX available.
  • Page 35 4. 2. 7 TEMP . SET Setting inside of PTZ DOME MENU Current Temp: Check Temp of inside of PTZ. TITLE See the below in detail. VIDEO FORMAT ※ Default is keep optimized temp POWER UP ACTION : ON PARK ACTION DISPLAY ON/OFF DOME SUB MENU TEMP.

  • Page 36: Factory Set

    (4) FAN ON TEMP DOME MENU Set the operating temperature of the Fan. (0~70 ) HEATER ON TEMP : 15 C HEATER ON TIME : 30 MIN HEATER OFF TEMP : 20 C Select : Set ON : FAN ON TEMP : 40 C NEAR FAN OFF TEMP...

  • Page 37: Clear Setting

    4. 3 Clear Setting Clears the PTZ position and function value. MAIN MENU CLEAR MENU MOTION PRESET YES NO DOME TOUR GROUP CAMERA SCAN CLEAR PATTERN PTZ RESET AREA ALARM PRIVACY EXIT PRESET CLEAR: < NEAR / RIGHT CLEAR > <...

  • Page 38: Specification

    5. SPECIFICATION 5. 1 Mechanism Specification 5. 1. 1 MECHANICAL - Pan : 360°Continuous Pan, 0.1° to 120°/sec (proportional to zoom) - Pan Preset Speed : 250°/sec, ± 0.1° Accuracy - Tilt : -8°(352°) to 188° movement, 0.8°~80°/sec (proportional to zoom) - Tilt Preset Speed : 250°/sec, ±...

  • Page 39: Dimension

    6. DIMENSION 6. 1 DIMENSION 1-1/2inch PF TAP 157,9 Ø231...
  • Page 40 4-Ø8.5 Ø231...
  • Page 41 157,9 Ø231...

  • Page 42: Configuration

    7. CONFIGURATION 7. 1 Connecting to Keyboard with DVR ....
  • Page 43 P/N : 388067625 PRINTED IN KOREA Distributed by...
