Sensation 2.0 Sensor Phone

User Manual

Please read this manual thoroughly before using the device.

Table of Contents

Summary of Contents for One Media Sensation 2.0

Page 1: User Manual
Sensation 2.0 Sensor Phone User Manual Please read this manual thoroughly before using the device.
Page 2: For Your Safety
For your safety Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information. Do not use the device as a therapeutic or diagnostic device. Do not use the device where blasting is in progress.
Page 3: Table Of Contents
Contents General Information......... . . 1 Getting started .
Page 4: General Information
General information About your device： The wireless device described in this guide is approved for use on GSM/EDGE 850, 900, 1800 and 1900 MHz networks. Contact your service provider for more information about networks. When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.
Page 5 General information Practical rules about accessories: ● Keep the Sensation accessories and cables, etc. out of the reach of small children. ● When you disconnect the power cord of any accessory, grasp and pull the plug, not the cord. Items in packaging: After opening the package, please check the following components.
Page 6 Getting Started Keys and parts （9）（10）（3）（1）（6）（8）（7）（14）（5）（2）（4）（12）（13） 1. Return Button 8. USB Port 2. Power Button 9. Watchband Groove 3. Microphone 10. Certification Icon 4. Speaker 11. SIM Card Slot 5.
Page 7 Getting Started Icons Menu Image DESCR Image DESCR Heart Rate Emotion Test Pedometer Settings Phonebook Temperature Tool Box Dial Humidity Call History...
Page 8: Getting Started
Getting Started Indicator Icons Icon DESCR Icon DESCR Network Bad signal signal Calling Missed call Unread Battery power message display Confirm Return Delete Flight mode Setting Stop watch...
Page 9 Getting Started Buttons - The Sensation has 4 Side buttons. Image Description Home Button: (Lower Right Hand Side) Press the button to call the home number you set for an instant phone call. Power Button：(Lower Left Hand Side) Hold the button for 3 seconds to power On/Off. Press the button to return to the clock interface.
Page 10 Getting Started Installing your SIM card A normal size SIM card For availability and information on using SIM card services, contact your SIM card vendor. This may be the telecom service provider or another vendor. The SIM card and its contacts can be easily damaged by scratches or bending.
Page 11: Charging The Battery
Getting Started Charging the Battery Various charging methods are available. Use the USB charger that has been provided to you to charge the Sensation. Your battery has been partially charged at the factory. You should recharge the battery before you switch the Sensation "ON" for the first time. Make sure you use a compatible USB charger to charge your Sensation.
Page 12 Getting Started It usually takes 1.5 hours to fully charge Sensation from a wall outlet. It can take up to 2.5 hours to charge from a PC because the voltage is less. Take good care of your battery, it is the life force of your watch.
Page 13 Getting Started Antenna Your device has an internal antenna. Please note: As with any other radio transmitting device, do not touch the antenna unnecessarily when the device is powered on. Contact with the antenna affects call quality. To optimize antenna performance and battery life, avoid contact with the antenna area when operating the device.
Page 14 Getting Started 1. Switch the Device On/Off As shown in the picture display, please hold the Power button until Sensation switches on or off. 2. Clock Interface Sensation has two possible modes: Digital clock and Analog clock. While the Clock window is open, hold the ‘Return’...
Page 15 Getting Started 3. Locking / Unlocking the Clock Interface As shown in the diagram below, push the ‘Power’ button to either lock or unlock the clock interface. 4. Flight mode Use the Flight Mode in radio sensitive environments, onboard aircraft, or in hospitals in order to deactivate all radio frequency functions.
Page 16 Getting Started 5. APN Setting - Data Account Window (Under Settings Section) The Sensation requires a SIM card to access the internet and transmit data. Only use services that you trust and that offer adequate security and protection against harmful software. For the availability of these services, pricing, and instructions, contact your service provider.
Page 17 Getting Started 7. Function Menu In Standby Mode, simply swipe left or right to enter the function menu. Swipe right to enter the first page menu, and swipe again to enter the second page menu. Swipe left to enter the third page menu. The first page menu：...
Page 18: Functions-Call
Getting Started 8. Battery Saving. The Sensation screen will power down automatically after 10 seconds when not in use in order to save power. To relight the Sensation, press any button or wave your arm up and down. Calling and Setting 1.
Page 19: Functions-Messaging
Functions-Messaging 1. Text messages You can read, write, send, receive, edit and save text messages. You can write text messages using the keyboard. Or, use the handwriting recognition function using your finger to write letters or characters. On the upper left hand you can select the language you desire. Text messaging services can only be used if they are supported by your network or service provider.
Page 20: Emergency Call
Calling and setting 2. Answer or end a call To answer an incoming call, press the call key. To end the call, press the End key. To reject an incoming call, press the End key. To change the volume or mode of ringing tone, select Settings >...
Page 21 Functions-Messaging 2. Create a text message 1. Select Messaging > Write message, as shown in the following picture: 2. Write your message in the message field. 3. Enter one or more phone numbers in the message recipient field: To retrieve a phone number from the Phonebook click ‘√’...
Page 22: Functions-Contact List
PHONEBOOK-Contact List You can save names with several phone numbers as contacts in the PHONEBOOK and the SIM card memory. They can be used to make a phone call or text a message. There are two ways to access the Phone Book. From the dial pad hold the phone icon.
Page 23: Functions-Call Log
Call History To view the Call History, click the icon below： ● Missed calls--- Shows call you received and did not answer. ● Dialed calls--- Show calls you dialed. ● Received calls--- Shows calls you received and answered. ● Delete call logs--- Select to delete the call history.
Page 24: Heart Rate Measurement
Heart Rate Measurement Use the Sensation to monitor heart rate. Click the icon below： The Sensation starts automatic measurement of heart beat rate or pulse. The bottom of the Sensation where the heart rate sensor is located must be placed flush against the skin.
Page 25: Body Temperature Measurement
SKIN TEMPERATURE Measurement Use the Sensation to measure skin temperature. Select Temperature on the first page of the function menu. The temperature shows both the real skin temperature and the change (or delta) of temperature since the last change As shown in the following icon： The Sensation shows the skin temperature and the amount of the last changes in temperature.
Page 26: Humidity Measurement
SKIN MOISTURE Measurement Select SKIN MOISTURE As shown in the following window： The Sensation starts automatically measures wrist surface moisture. Attention: The Sensation will only display values captured while that window is set.. Attention: It is a normal phenomenon of moisture levels of the skin surface area to increase during exercise and rainy conditions.
Page 27: Pedometer Measurement
Pedometer Measurement The pedometer measurement starts automatically when the Sensation is turned on. Measure the total amount of calories consumed performing various basic activities. You can easily measure the calories consumed doing various activities including walking movement, housework, aerobics, etc. To view the current sports data in pedometer measurement, select the Pedometer icon below：...
Page 28 Stop Watch (Chronometer) Window • On the PEDOMETER window there are 3 icon buttons located on the bottom. The white, lower center icon portrays a running woman with a stop watch. Click the lower running woman icon with with the stop watch to begin the that function.
Page 29: Web Portal
Web portal Users and Administrators can select settings to upload a variety of data regularly to the web portal from the Sensation including Heart Rate, Skin Temperature, Humidity, GPS, Pedometer, Emotion Status data, “Power On” status, Low Battery Alert, and a designated range of notifications available via email or Skype.
Page 30: Emotional States
Emotion states Use the Sensation to upload information on your emotional states to the web portal. Select EMOTION as shown in the window below： Upload emotional states data to the web portal: anytime and anywhere. There are three emotional options listed for users to select.
Page 31: Gps Positioning
GPS Positioning The key features of GPS: 1. The GPS function works in any weather conditions, anywhere in the world, 24 hours per day. The GPS displays shows longitude, latitude, altitude, and speed of the User if he is moving. It provides Users with continuous and real-time three - dimensional positioning and velocity.
Page 32: Tool Box
Tool Box Enter Tool Box Menu , By clicking "EXTRAS" Users can access the Calculator, Calendar, Alarm, FM Rradio, Bluetooth, Authorization Number, Home Number, SOS Number .and Server Config as shown in the window below: 1. Calculator Select Tool Box > Calculator, as shown in the following picture: 2.
Page 33: Alarm Function
Tool Box 3. Alarm function Select Tool Box > Alarm Clock. As shown in the following graph: Enter alarm function, click “ON/OFF” button to set the alarm on , click the time to set the alarm time. Click 'Once' to set the alarm type, alarms can be set as once only, everyday and workday.
Page 34 Tool Box Click the FM radio function. Click to start listening， Click to return to the last channel. Click change to the next channel. To fine tune, click . This will move the tracker plus or minus 0.1Hz to find the station that you desire. Enter ‘Options’...
Page 35: Settings
Settings 1. Time/date setting Select Setting > Set Date/ Set Time, as shown in the windows below: 2. Priority input method Select Setting > Pref.Input Method, as shown in the window below : Priority input methods can be selected based on individual usage habits.
Page 36 Settings 4. Authorization Number setting Select Tool Box > Authorization Number setting as shown in the window below: The Sensation can be controlled by SMS messages from two separate authorization phone numbers. Set up the two authorization numbers, each with full authorization to check the information and control the watch.
Page 37 Settings To turn off the function of receiving Heart Rate data regularly type: Pulse0 Receive Pedometer data now: pedo Receive all data now (Includes Heart Rate, GPS, Skin Moisture and Pedometer Measurement): status Receive all data once every 10 minutes: status 10 (Values range between 5 to 1440) To turn off the function of receiving all data regularly type: status 0...
Page 38: Other Settings
Settings 6. Other Settings • Sound setting: Set the Sensation to either Mute, Low Volume or High Volume. Or you can set the Sensation to Vibrate mode. • GPS setting: Set up the GPS network service and automatic time calibration. •...
Page 39: Battery Information
Battery information • Set the desired LCD backlight brightness in the LCD backlight section in the Sensation setting. Click "LCD Backlight." Adjust the desired brightness of the screen by scrolling left or right. Charging and discharging Your device is powered by a rechargeable battery. The battery can be charged and discharged hundreds of times, but it will eventually wear out.
Page 40 Battery information Use the battery only for its intended purpose. Never use any charger or battery that is damaged. Leaving the device in hot or cold places, such as in a closed car in summer or winter conditions, will reduce the capacity and lifetime of the battery.
Page 41: Care And Maintenance
Care and maintenance Your device is a product of superior design and craftsmanship. It should be treated with care. The following suggestions will help you protect your warranty coverage. ● Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that will corrode electronic circuits.
Page 42 Care and maintenance ● Simply use a damp cloth, to lightly clean the screen. Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the device. ● Do not paint the device. Paint can clog the moving parts and prevent proper operation.
Page 43: Additional Safety Information
Additional safety information Small children Your device and its enhancements may contain small parts. Keep them out of the reach of small children. Operating environment This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 2.2 centimeters (7/8 inches) away from the body.
Page 44: Potentially Explosive Environments
Additional safety information Potentially explosive environments Switch off your device when in any area with a potentially explosive atmosphere. Obey all signs and instructions. Potentially explosive atmospheres include areas where you would normally be advised to turn off your vehicle engine.
Page 45: Certification Information
Certification information Hereby, OneMedia declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
Page 46: Product Specifications
Product Specification Operational Specifications 1. Size: 53*48*14.5mm 2. Weight: 70g 3. PCBA size: 43.6*41.6*0.8 mm 4. Touch screen: Capacitive 5. OLED size: 1.8inch 6. Transmission mode: GSM/GPRS 7. USB interface: 12PIN Micro USB interface 8. Earphone jack: 12PIN Micro earphone 9.
Page 47 One Media Partners Inc. 608 S Washington Street, Suite 207 Naperville, IL 60540 +1 (312) 685-1822 info@onemediapartners.com www.onemediapartners.com...
