2.4GHz Wireless,
Audio/Video/S-Video Sender
With Built-in Remote Control Extender
MODEL: TR-2470
OWNERS MANUAL
Made in China

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR-2470 and is the answer not in the manual?

Questions and answers

Summary of Contents for WAGNER TR-2470

  • Page 1 2.4GHz Wireless, Audio/Video/S-Video Sender With Built-in Remote Control Extender MODEL: TR-2470 OWNERS MANUAL Made in China...

  • Page 2: Table Of Contents

    ● ABOUT THE TR-2470 The TR-2470 is a powerful wireless A/V/S-Video signal sender and receiver system which can operate with satellite and cable receivers, camcorders, stereo systems, televisions , laser disc players and VCRs, and provide superior reception at distances of up to 250 feet (clear line of sight) from the transmitter..

  • Page 3: Location Of Controls And Accessories

    LOCATION OF CONTROLS The TR-2470 has been carefully engineered and manufactured to give you dependable operation. Read this manual before operating this unit to become familiar with its features and obtain the performance that will bring you enjoyment for many years.

  • Page 4: User Guide

    ( Tolerance never more than 5%, such as 120 VAC +/- 10 VAC ) 2. Only use the power adapter provided with the TR-2470. If you use your own adaptor, make sure the power output is 12V DC, 300 mA centre positive.

  • Page 5: Installation

    INSTALLATION TRANSMITTER (Tx-2470) a. By Composite Video(RCA) 1. Take a RCA to RCA cable(included),take one end connected to the AV In socket of Tx-2470.(see Pictures 1 ) 2. Connect the other end to the Audio / Video Out port of VCR, DVD, VCD, Satellite receiver .Etc.

  • Page 6: Trouble Shooting

    TROUBLE SHOOTING No picture or sound a) Check the power on/off switches on the Transmitter, Receiver and TV b) Make sure the power plug and signal cable are pushed all the way in. c) Check if the channel of transmitter & receiver are set to the same channel. d) Make sure that all cables are connected as per the user guide e) Check if there is any discontinuity inside the cable.
  • Page 7 1. Not Synchronised 2. Screen unlocked 3. Noisy line across the screen a) Adjust receiver antenna direction for optimal performance. (see Pictures 5, 6) b) Adjust transmitter antenna direction for optimal performance. (see Pictures 5, 6 ) c) Check if the supplied voltage matches the adapter specification. d) Select a different microwave channel by sliding the channel button on both transmitter and receiver.

  • Page 8: Referring Pictures

    Transmitter Pictures 1 Back View Satellite.R ON/OFF Switch Power Adaptor S-VIDEO CABLE RCA CABLE Back View of Video devices S-Video IN A/V IN Pictures 2 Back View Cable, Satellite.R/DVD/VCR/VCD IR OUT ON/OFF Switch Front View Power Adaptor Make sure you stick the mouse in front of the Infrared Receiving Sensor (Approx.
  • Page 9 Pictures 4 Transmitter Receiver Channel selection button (must be set to same channel on both transmitter & receiver) Pictures 5 Transmitter Receiver Side with dimples Turn the side with dimples face to face toobtain the best performance Pictures 6 Receiver Transmitter Turn the side with dimples face to face toobtain the best performance...
  • Page 10 Pictures 7 Receiver IR Receiver In order to obtain the best performance of IR receiving please be sure this unit is Side View a little forward to the TV OPERATING REMOTE CONTROL Pictures 8 Receiver IR sensor window Remote Control Pictures 9 Receiver 0.3M...

  • Page 11: Further Applications

    FURTHER APPLICATIONS FURTHER APPLICATIONS WITH VCR Connect the Transmitter to a VCR, which is connected to a TV. a. by composite Video (RCA) 1. Make sure the ON / OFF switch on both the transmitter and receiver is in the OFF position before making any connections.
  • Page 12 b. By S-Video Please note: S-Video connectors has a special orientation, when you want to use S-Video connection, you need to be carefully handled the connector, make sure the orientation is correct. Push it gently, otherwise, you will broke the connector and conector socket of device 1.Make sure the ON / OFF switch on both the transmitter and receiver is in the OFF position before making any connections.
  • Page 13 a. by composite Video (RCA) 1. Make sure the ON / OFF switch on both the transmitter and receiver is in the OFF position before making any connections. 2. Take a RCA to RCA cable(included) and connect one end to the A/V out of RX-2470 and the other end to the A/V in of VCR.

  • Page 14: Caution

    To prevent fire or shock hazard, do not submerge or expose these products to water ● ● To avoid electric shock, do not open these units. The TR-2470 contains no user serviceable parts. Doing so will void the warranty Use only the power adaptors provided with the TR-2470 ●...

  • Page 15: Specification

    SPECIFICATION TRANSMITTER Output level 0~10dBm microvolts/meter @ 3 meters (complies with fcc) Operating frequency 2.4GHz - 2.4835GHz Modulation FM (Video and Audio) Video input level 1.0 V p-p Audio input level 1 V rms S-Video Input Level Y:1Vpp+-30%, C:288mV +-20% Video input impedance 75 ohm Audio input impedance...
