- Page 1 16.june.2014...
- Page 3 A Word from Marco De Virgiliis Thank you for choosing the DV AC 101 combo. When I began to develop the concept of the Acoustic line in Italy several years ago, I had one objective in mind: to produce top quality acoustic amps that would meet the needs of professional musicians everywhere.
-
Page 4: Front Panel
FRONT PANEL 1) INPUT CH1 Connect your acoustic instrument to this input using a standard ¼” shielded instrument cable. 2) CH1 GAIN This controls how much signal is passed through the CH1 preamp stage of the unit, which includes equalization and the effects loop. - Page 5 DV Mark amps and combos are manufactured to be used in the country where they have been sold, and are factory preset to that country’s voltage.
-
Page 6: Rear Panel
So make sure you’re sending the correct voltage to your amp before you connect it to AC power. 24-25) SPEAKER OUTS The DV AC 101 combo head features two speaker outputs, the high-quality SPEAKON COMBO output is connected by default to the internal speaker, may you like to use a SPEAKON speaker cable to connect an 8ohm extension cabinet you can disconnect the cable from internal speaker from the SPEAKON COMBO output and connect it to the JACK output. - Page 7 PULL FOR GAIN HIGH EFFECT MIX PHANTOM CLIP CLIP MIX 31) LINE OUT The balanced XLR output allows you to connect your amplifier directly to a mixing console (either in live situations or in a INPUT INPUT GAIN HIGH EFFECT MIX ANTIFEEDBACK Chorus 1 Revb1...
-
Page 8: Technical Specs
TECHNICAL SPECS Effects Description 1) Chorus + Reverb INPUTS:CHANNEL 1 Imp. 500 Kohm / max Vpp: 10 2) Hall – Reverb time Medium High CHANNEL 2 Imp. 500 Kohm / max Vpp: 10 3) Hall – Reverb time Medium BALANCED CH2 Imp. 500 Kohm / max Vpp: 20 4) Room –... -
Page 9: Block Diagram
BLOCK DIAGRAM CHANNEL 1 ELECTRIC GUITAR TONE Input 1 GAIN Balanced Direct Direct EFFECTS Post Anti- feedback Master Send EFFECTS Power Ampli Power Return Output Micro TONE GAIN Input 2 CHANNEL 2 NOTES... - Page 10 Product specifications are subject to change without notice www.markbass.it Italy - 66020 San Giovanni Teatino CH - Via Po, 52 Tel: +39 0854407764 / 0854465705 - Fax: +39 0854407764 / 0854407399 - www.dvmark.it - info@dvmark.it...
