Summary of Contents for Shenzhen Winext Technology GW5000
- Page 1 Gateway Operation Guide GW5000Gateway Operation Guide V1.0 2017/06/09 Shenzhen Winext Technology Co. Ltd.
-
Page 2: Table Of Contents
4.1 The gateway cannot be bound ..................... 22 4.2 GPS Cannot be properly positioned ..................22 4.3 Node cannot access the network ..................22 4.4 Background cannot add / remove nodes ................22 Shenzhen Winext Technology Co. Ltd. -
Page 3: Chapter 1 Gateway Peripheral Port Connection
Chapter 1 Gateway Peripheral Port Connection 1.1 SIM Card install Refer to《GW5000 Installation Guide》，Gateway Shutdown Status Open the front cover of the gateway with a hexagon screwdriver (as shown) Will prepare the 4G SIM card (Unicom / Telecom / Mobile optional one) chip out, the gap inserted into the SIM card seat. -
Page 4: Gateway To Internet
The other end of the network cable needs to be connected to POE switch or POE power supply. 1.3 Gateway to internet The POE splitter wiring in the gateway is shown below： POE separators are separated into 12V power supply and network cable. Shenzhen Winext Technology Co. Ltd. -
Page 5: To The Internet
LAN port. In the computer input gateway IP, enter the gateway interface to set parameters. The switch cascade does not exceed five levels. 1.3.2 Routing way to the Internet Separator cable access WAN port,diagram is as follows: Shenzhen Winext Technology Co. Ltd. -
Page 6: Chapter 2 Configuration Gateway (Cloud Platform)
IP to the gateway. Then, in the gateway "Interface" interface, manually modify the assigned IP address. Chapter 2 Configuration Gateway (Cloud Platform) 2.1 Enter TTN website Using Google browser, enter https://www.thethingsnetwork.org/， as below： Shenzhen Winext Technology Co. Ltd. -
Page 7: Register Account
Click the “LOGIN” mark in the upper right corner as the above picture shows, input “account name” and “password” according to the tips, then click “Login”. LOGIN After successful registration, enter the login interface, as below: Shenzhen Winext Technology Co. Ltd. -
Page 8: Console
Gateway Operation Guide CONSOLE Click the mark “CONSOLE” (refer to the above picture), as the bellowing interface: Shenzhen Winext Technology Co. Ltd. -
Page 9: Register Gateway（E.g. 915Mhz
Gateway Operation Guide 2.5Register Gateway（e.g. 915MHZ） 1) Click the mark “GATEWAYS” (refer to the above picture), enter “register gateway” interface 2) Click “register gateway”, finish filling in the blanks as the arrow points show Shenzhen Winext Technology Co. Ltd. - Page 10 Gateway Operation Guide Shenzhen Winext Technology Co. Ltd.
- Page 11 Gateway Operation Guide Shenzhen Winext Technology Co. Ltd.
-
Page 12: Chapter 3Add Node Applications
Gateway Operation Guide Refer to “Gateway User Manual”, 192.168.3.1 modify IP to “router.eu.thethings.network”, show as below: Gateway get successful connection by TTN, show as below: Chapter 3Add Node Applications Add node Shenzhen Winext Technology Co. Ltd. - Page 13 Gateway Operation Guide Click the triangular arrow mark behind the user mark, choose “CONSOLE” and enter, show as below: Click “APPLICATIONS”，then enter the below interface: Shenzhen Winext Technology Co. Ltd.
- Page 14 Click the upper right corner “add application”, enter the interface of adding node, fill in the node information according to the red arrows show, click “add application” mark (red arrow shows) Adding applications succeed, show as below: Shenzhen Winext Technology Co. Ltd.
-
Page 15: Register Node
Gateway Operation Guide Register node Click the left mark of “registered devices”, enter the below interface: Shenzhen Winext Technology Co. Ltd. - Page 16 Gateway Operation Guide Click the mark “register device” (the upper right corner), enter the interface of registering device: Fill in the blank as the red arrows show, clink “Register”，enter to the below interface: Shenzhen Winext Technology Co. Ltd.
- Page 17 Gateway Operation Guide Click the left and right arrows behind “Device EUI” and “Application EUI”, shift to “lsb” Shenzhen Winext Technology Co. Ltd.
-
Page 18: Configuration Node (By Serial Ports Tools)
Gateway Operation Guide Configuration node(by serial ports tools) 3.3.1 By USB-to-TTL cable, connect the nodes as below: Node pin serial port cable positive negative UART1_TX sending end UART1_RX receiving end MODE_SET mode end Shenzhen Winext Technology Co. Ltd. - Page 19 Gateway Operation Guide 3.3.2 MODE_SET connect the high level，connect the nodes with PC by serial port cable, power on 3.3.3 Start the serial port tool “AN-CONFIG”, click “search”，choose the corresponding port and frequency band, then click “read”. Shenzhen Winext Technology Co. Ltd.
- Page 20 “Write” to save. Enter the page of translation. Shenzhen Winext Technology Co. Ltd.
- Page 21 Gateway Operation Guide Check the gateway forwarding data: Shenzhen Winext Technology Co. Ltd.
-
Page 22: Chapter 4 Common Problem
2.Check if the node has electricity 3.The node is powered on again 4.4 Background cannot add / remove nodes Check whether the gateway is online, only the gateway normal online circumstances, in the "gateway details" to add / remove nodes Shenzhen Winext Technology Co. Ltd. -
Page 23: Technical Parameters
Max current ：<48V/400mA Local storage Built-in 32GB memory card Operating Operating temperature-20℃ ~85℃ temperature Storage Storage temperature-40℃ ~ 125℃ environment Humidity10% -90%RH No condensation Size 110*202*204mm Structure Installation parameter Bracket screw fixed installation method Shenzhen Winext Technology Co. Ltd. - Page 24 WIFI 2.4GHz <1.5 Certification:FCC/CE male head antenna N-type ANT 3.5dB Power support:3V/5V Active 1575.42Mhz <2.0 male head Gain>28dB Certification:FCC/CE N-type Band2/4/5 2dBi <1.8 Certification:FCC/CE male head Band2/4/12 N-type LORA 902-928MhZ 1dBi Certification:FCC/CE male head Shenzhen Winext Technology Co. Ltd.
- Page 25 Gateway Operation Guide Example of product assembly Shenzhen Winext Technology Co. Ltd.
-
Page 26: Installation Diagram
Gateway Operation Guide Installation diagram FCC Caution Any Changes or modifications not expressly approved by the party responsible for compliance could void the userʹs authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Shenzhen Winext Technology Co. Ltd.
