Summary of Contents for Radiant Communications VL4522
-
Page 1: User Guide
Radiant Communications Corporation VL4500 ENCODER SERIES Installation and Operations Manual User Guide... -
Page 2: Installation And Operation Manual
V L 4 5 0 0 E N C O D E R S E R I E S Installation and Operation Manual Radiant Communications Corp. 2017 5001 Hadley Road South Plainfield, NJ 07080 Phone 908.757.7444 • Fax 908.757.8666... -
Page 3: Table Of Contents
T able of Contents Product Summary ..............1 Application ..................1 Features ..................2 Front Panel ..................3 Rear Panel ..................4 Encoding Profiles ................7 Output Interfaces ................7 Energy Specifications..............8 Installation ................9 Communication ..............11 Network Management ..............11 Configuration ................ -
Page 4: Product Summary
The SFP output interface allows the operator to use either existing duplex or single fiber or 1000B RJ45. PEG STUDIO FIBER DOCSIS VL4500 CATV HUB Radiant Communications Corporation 2016... -
Page 5: Features
H.264 AVC SD/HD • VBR and CBR Encoding • AC-3 Audio Encoding • EIA-708/608 Closed Caption Support • IP, ASI and QAM output Options • Video Scaling and Conversion • Low Power Consumption and Heat Dissipation Radiant Communications Corporation 2016... -
Page 6: Front Panel
• Right – Selects a menu item or will move the cursor to the right one digit • Plus – Increments a digit when entering values. • Minus – Decrements a digit when entering values. • Enter – Confirms a value or menu selection. Radiant Communications Corporation 2016... -
Page 7: Rear Panel
10/ 100/ 1000 10/ 100/ 1000 POWER ASI OUT SDI IN CVBS IN 1 2 3 4 5 TS OUT MGMT RS232 EARTH POWER Serial Port SDI IN CVBS IN AUDIO IN ASI OUT MGMT GND +12 V Radiant Communications Corporation 2016... - Page 8 HD/SDI IN ASI IN ASI OUT GND +12 V VL4522 10/100/1000 10/100/1000 SDI IN ASI IN ASI OUT POWER MGMT RJ45 EARTH TS OUT POWER ASI IN ASI OUT 2 x SDI IN MGMT GND +12 V Radiant Communications Corporation 2016...
- Page 9 • DVB ASI Output – Available only on VL4510 models. • QAM Output – Available only on VL4510Q model Ethernet Management Port • The Ethernet Management Port is used for monitoring, firmware upgrades, and command line interface to configure the unit. Radiant Communications Corporation 2016...
-
Page 10: Encoding Profiles
• Gigabit SFP Optical Module DVB ASI Output, 75Ohm BNC Connector with 54M max rate TS: MPEG2 TS, User Selectable Rate, Full PID Table including TS ID, Program ID, Video, Audio, PMT and PCR PIDs, ATSC and DVB modes. Radiant Communications Corporation 2016... -
Page 11: Energy Specifications
Total power consumption is 24W per 1080p and 480i dual stream at full 19M TS bitrate. The temperature inside and outside of the unit will not exceed 40⁰C. Cooling is provided by two fans located on the front left side of the unit. Radiant Communications Corporation 2016... -
Page 12: Installation
If both power sources are connected they will act as redundant power supplies. The POWER LED on the front-panel will light green and the LCD screen will turn on. The standard boot-up time is less than one minute, after successful boot-up the LCD screen will read “VL4500” Radiant Communications Corporation 2016... - Page 13 V L 4 5 0 0 U S E R M A N U A L R E V . 3 . 0 0 . 0 5 7 Radiant Communications Corporation 2016...
-
Page 14: Communication
8. Select the "Use the following IP address" option and enter the following addresses: IP address: 192.168.16.2 Subnet mask: 255.255.255.0 9. Click OK to close the dialog box. Now your computer is ready to communicate with the unit. Radiant Communications Corporation 2016... - Page 15 U S E R M A N U A L R E V . 3 . 0 0 . 0 5 7 10. Open an Internet Explorer web browser on your computer and enter the following URL http://192.168.16.252 Radiant Communications Corporation 2016...
-
Page 16: Configuration
Settings can be saved to a desired preset; preset includes also the current state of the Encoder The encoder is being shipped with encoder factory preset. Saving on that preset is not possible. After the unit is configured, a new preset should be created and saved. Radiant Communications Corporation 2016... - Page 17 The top portion of the web based management screen provides information about part number, firmware version, uptime and unit name. Bottom portion provides control to Stop, Start, Restart (soft reboot) the encoder, as well as creating new presets, changing presets and saving them. Radiant Communications Corporation 2016...
-
Page 18: Video Settings
• 1080p at 24, 29.97, 30 and 59.94fps (H.264, 1 x 3G mode only) • 1080i at 24, 29.97 and 30 fps • 720p at 29.97, 30, 50, 59.94 and 60 fps • 480i at 29.97 and 30 fps Radiant Communications Corporation 2016... - Page 19 HD to SD with QBA support for old legacy STB, set the filed order to TFF for the SD encoder. H264 encoding is supported only in BFF field order. The VL4500 encoder supports the following bitrate ranges: Radiant Communications Corporation 2016...
- Page 20 (that don't need them) and giving them to frames that have more information to encode (and does need them). With CBR each frame uses the same number of bits regardless of whether it needs them or not. Radiant Communications Corporation 2016...
- Page 21 This is one of the reasons the GOP structure is repeated. It ensures a new I-frame to rebuild a perfect image, although the arrival of the I-frame might take some time. Radiant Communications Corporation 2016...
- Page 22 SPF mode will be used for sports content at high bit rates, at low bitrate that mode shows high number of artifacts. The bitrate in that mode can go to as low as 2M for HD with up to 4 B-frames and 240 I-frame intervals. Radiant Communications Corporation 2016...
- Page 23 • Auto Resize - automatically adjust scaling for HD down convert channels (HD to 480i) based on AFD value in the SDI input • User data - Inserts AFD codes 1 to 15 (0000 - 1111) Radiant Communications Corporation 2016...
- Page 24 3 . 0 0 . 0 5 7 Input Active Format 4:3 Output Format Resizing Description Input Picture Output Picture Method DVB: reserved; Letterbox ATSC: undefined reserved Letterbox DVB: 16:9 active picture (top aligned); ATSC: Letterbox "not recommended" Radiant Communications Corporation 2016...
- Page 25 5 -7 reserved Letterbox Full Frame image, same as Letterbox the frame (4:3 or 16:9). 4:3 Image: Full Frame in 4:3 Center frame, Pillarbox in 16:9 frame. Radiant Communications Corporation 2016...
- Page 26 16:9 with shoot and protect 14:9 center. Here, the areas to the right and left of Letterbox the central 14:9 region of the 16:9 active picture can be trimmed Radiant Communications Corporation 2016...
-
Page 27: Audio Settings
16:9 active picture can be trimmed without losing important detail. Audio Settings The Audio Settings tab allows you to set the audio input, codec, bitrate, audio gain (-20dB to +20dB), Dialnorm (AC3 only) and channel mode. Radiant Communications Corporation 2016... -
Page 28: Ts Settings
Note: The only supported mode for CATV applications is: Audio Codec: AC3 Audio Bitrate: 192k Channel: Mono/Stereo TS Settings Transport stream (TS) is a format that allows multiplexing of digital video and audio and synchronizes the output. Radiant Communications Corporation 2016... - Page 29 Suppose each channel consists of one video stream, one or two audio streams, and any necessary metadata. A receiver wishing to tune to a particular "channel" merely has to decode the payload of the PIDs associated with its program. It can discard the contents of all other PIDs. Radiant Communications Corporation 2016...
- Page 30 Please contact the local Cable Operator’s Headend to obtain the proper settings. You should never allow any PID to be set at the same value within one stream. The VL4500 Encoder supports both Unicast and Multicast IP delivery with user adjustable TTL. Radiant Communications Corporation 2016...
- Page 31 The TS rate for CATV installations must have a constant bit rate (CBR), for a transport over internet or point to point applications, transport stream bit rate control could be set to variable bit rate (VBR). Radiant Communications Corporation 2016...
-
Page 32: Network Settings
3 . 0 0 . 0 5 7 Network Settings The Network Settings tab is used to set the network configuration and address for the Management and TS Ethernet ports. The user can add VLAN ID on each port. As shown below. Radiant Communications Corporation 2016... - Page 33 In cases where either one or both Ethernet ports of the encoder are being connected to public network/internet place the device behind hardware firewall in order to protect the encoder from malicious interference, or at minimum disable the telnet port from the System setup tab. Radiant Communications Corporation 2016...
-
Page 34: System Setup
Remote system logging can be enabled. In that mode the encoder will send log entries to a remote syslog server. System Setup System Setup menus control the Management and Transport Stream network settings, remote authorization system (local & Radius) and upgrade of the unit. Radiant Communications Corporation 2016... - Page 35 MPEG2 HD and one h.264 HD encoders. • VL4522. Available modes are 1xHD, 2xHD, 2xHD+1xSD (third encoder is for HD to SD down convert program of one of the HD inputs) and 2xHD+2xSD (two HD and down converted SD programs) •...
- Page 36 ASI Input allows to multiplex MPEG programs coming on ASI input to the output TS. Ensure that there are no PID duplicates! Legacy STB support enables Quad-Byte-Alignment for older legacy set top boxes. The setting consists of No Empty Adaptation Filed under TS setting and QBA setting for Video Encoder Radiant Communications Corporation 2016...
- Page 37 Radius server security the access is granted only to the web management, the console and LCD/keypad interfaces are still protected with 4-digit password. The settings page allows you to rename the unit, enable or disable. Management port, LCD screen/keypad (reboot required), telnet, ssh, vlan and SNMP. Radiant Communications Corporation 2016...
-
Page 38: Firmware Upgrade
1. Obtain the latest FW release from http://support.rccny.com/VL4500/ 2. If running STOP the Encoder 3. Click “Update Device Firmware” button 4. Browse to the update.img file 5. Click “Upload and Update” button. Note: do not power down the unit during the upgrade process. Radiant Communications Corporation 2016... -
Page 39: User Presets
3 . 0 0 . 0 5 7 User Presets The User Presets window will allow you to delete, export and import user presets. Presets can be changed or created only when the unit is in STOPED mode (not encoding). Radiant Communications Corporation 2016... -
Page 40: Encoder Default Settings
SD TS PIDs, Both streams share the Audio and PCR PIDs PMT PID 135 SD Video Bit Rate 3500 Video Bitrate in kbits. Management 192.168.16.252 Front Panel Management port address Address TS GigE Address 192.168.1.253 Transport Stream GigE address Radiant Communications Corporation 2016... -
Page 41: Front Panel Interface
3. Password – sets/change/disable password. Password for screen and web should be the same 4. Start/Restart encoder 5. Save Encoder 6. Stop Encoder 7. Reboot Encoder 8. Info – Shows IP addresses and MAC, VLAN IDs (if set), encoder status and SDI inputs Radiant Communications Corporation 2016... -
Page 42: Revisions
Web interface Java Script incapability with older browsers. 1.00.034 VL4522 with different resolution input on each SDI and Closed Captions enabled on either or both encoders, exposes a bug in the video detection routine, causing the encoder to lose lock on inputs on a constant time base. - Page 43 (4522, 4521, 4528) in MPTS mode, doesn’t work. work around is to set TS mode to SPTS, switch to manual rate and adjust the rates, the switch to MPTS. Password/Radius doesn’t work from either front panel or web user interfaces. Unicast streaming doesn’t work. SNMP doesn’t work Radiant Communications Corporation 2016...
- Page 44 Known Issues: 3.00.043 With VL4522 there is a visible video stutter when we encode two 480p SD streams alongside of the HD ones. Closed caption issues with 720p signals, 720p to 480i signals Major progressive to interlaced video quality improvement. 1080P to 1080i conversion.
- Page 45 Auto Resize - automatically adjust scaling for HD down convert channels (HD to 480i) 3.00.057 based on AFD value in the SDI input. User data - Inserts AFD codes 1 to 15 (0000 - 1111). Improvement for video scaling (letterbox, center cut). Radiant Communications Corporation 2016...
