Summary of Contents for RENY OPTIMA
-
Page 1: User Manual
INSTALLATION AND USER MANUAL OPTIMA FIREPLACE INSERT RENY KACHELS Ganzestaartsedijk 14 5525 KC Duizel T: +31497513125 F: +31497518111 E: info@reny.nl W: www.reny.nl... -
Page 2: Foreword
Foreword Congratulations on the purchase of your new RENY stove. Your choice proves that you care about qual- ity and a functional design. RENY was founded in 1975 and spent the first years specializing in the classic fireplaces. Since 1981 fireplace inserts and freestanding stoves have been manufactured. -
Page 3: Table Of Contents
Table of Contents FOREWORD TABLE OF CONTENTS DESCRIPTION Construction SGI-System LVB-System Heat transfer 1.4.1 Convection heat 1.4.2 Radiation heat Attention to the environment INSTALLATION Dimensions Chimney Installation 2.3.1 Installation in an existing chimney piece 2.3.2 Installation in a newly built chimney piece 2.3.3 Mounting the frames Firewood Ventilation... -
Page 4: Description
The RENY OPTIMA combines comfort and an efficient heat release. During development, very high qual- ity materials were used. It’s not for nothing that RENY offers no less than 5 years of warranty regarding her products. This is reflected in a solid and functional construction with sublime finishing. Simplicity, soundness and the appealing design are the foundation of the pure enjoyment of the extreme comfort associated with an ambient wood fire. -
Page 5: Radiation Heat
This air flow can pass in a natural way, but it can also be intensified using ventilators. These can be mounted in the stove as an optional extra. In addition the OPTIMA 80 can be equipped with a convection pack. This includes two extra convection connections, which blow hot air into the room from the top of the fireplace. -
Page 6: Installation
Connecting more than one device to one chimney is not allowed. 2.1 Dimensions The dimensions of the various types of OPTIMA hearths you will find in attachment 1 2.2 Chimney One of the main components of the hearth is the chimney. Together with the chimney, the hearth is one unit. -
Page 7: Installation In A Newly Built Chimney Piece
2.3.2 Installation in a newly built chimney piece • The OPTIMA 80 can optionally be equipped with a convection set. This extra convection set increases the convection air volume, which will increase the yield of the hearth. • Ventilate the chimney piece by applying ventilation grids at the upper and lower side. This will cool the chimney piece, which will decrease the risk of cracking. -
Page 8: Mounting The Frames
cavity is necessary. Placing an isolation of at least 100mm thick (class A1 DIN 4102) is enough. • Be sure not to put the hearth into use too soon after the installation. Let all materials dry and harden well. Always consult your installer about this. 2.3.3 Mounting the frames 3-sided frame: insert the two long side pieces into the left and right side of the hearth. -
Page 9: Use
3.1 Firewood The incineration system was developed for burning deciduous wood in the form of split logs. It is impor- tant to burn only purely wind dry wood (moisture level 12 - 15 %). Never use waste, other flammable materials and / or flammable liquids. This will seriously damage your stove and chimney. Below you will find the various wood types with their average drying time. -
Page 10: Stoking
When the wood is burning properly, the door can be closed. The fire should now be burning brightly and intensely. Let the hearth warm up properly and then adjust the burning. 3.5 Stoking As soon as the stove has warmed up (after about 15 minutes) the incineration can be controlled. The following points are important: •... -
Page 11: Firewood Consumption
Wood consumption per hour = 10,0 / 3,168 = 3,16 kg. 3.8 Safety With a RENY wood stove, you have purchased a comfortable and safe heat source. The fire safety starts with a proper installation and a correctly working chimney. In addition the following points are important when it comes to to safe heating: •... - Page 12 • Follow the directions of the local fire department. The stove can only be used if all national and local installation directives, directives of the local fire department and the necessary architectural provisions have been met. • If reparation should be necessary, only have an acknowledged dealer perform this with original RENY parts.
-
Page 13: Maintenance
Ventilate the stove and, if necessary, place moisture absorbers in the fireplace. 4.3 Convection channels The OPTIMA 80 can optionally be equipped with a supplementary convection pack. Clean these chan- nels every year, so a proper air circulation is guaranteed. 4.4 Rotating parts All rotating parts, such as the hinges and lock need to be mildly lubricated at least once a year. -
Page 14: Ventilators
4.11 Ventilators Clean the ventilators once every year. They can be reached through the front of the hearth. • Remove the frame, if there is one (see paragraph 2.3.3). • Remove the door. This can be lifted upwards from the hinges. •... -
Page 15: Attachment 1: Hearth Dimensions
Attachment 1: Hearth dimensions... - Page 18 113,5...
-
Page 19: Attachment 2: Dimensions Standard Frames
Attachment 2: Dimensions standard frames Name Dimensions wxh (mm) Optima 53 3-sided frame 600x523 Optima 53 4-sided frame 600x545 Optima 60 3-sided frame 660x523 Optima 60 4-sided frame 660x545 Optima 70 3-sided frame 760x573 Optima 70 4-sided frame 760x595 Optima 80 3-sided frame... -
Page 20: Attachment 3: Description
Attachment 3: Description... -
Page 21: Attachment 4: Technical Details
Bijlage 4: Technical details Thermal output 6,3 kW 7,5 kW 9,0 kW 10,0 kW Flue system Ø150 mm Ø150 mm Ø200 mm Ø200 mm Content incineration compartment 0,025 m³ 0,031 m³ 0,049 m³ 0,072 m³ Surface bottom incineration compartment 0,11 m² 0,12 m²... -
Page 22: Attachment 5: Warranty Certificate
Attachment 5: Warranty Certificate Stove / hearth Type: ……………………………………………………………………………………………………………………………… Serial number: ……………………………………………………………………………………………………………………………… Date of purchase: …………………………………………………………………………………………………………………………… Dealer Name: ……………………………………………………………………………………………………………………………… Street/No.: ……………………………………………………………………………………………………………………………… ZIP code: ……………………………………………………………………………………………………………………………… City: ……………………………………………………………………………………………………………………………… Country: ……………………………………………………………………………………………………………………………… Telephone: ……………………………………………………………………………………………………………………………… Fax: ……………………………………………………………………………………………………………………………… E-mail: ……………………………………………………………………………………………………………………………… Signature: ……………………………………………………………………………………………………………………………… User Name: ……………………………………………………………………………………………………………………………… Street/No.: ………………………………………………………………………………………………………………………………... -
Page 23: Warranty Provisions
Complaints can only be processed when they have been submitted through the dealer to RENY, together with the fully completed warranty certificate and the purchase receipt. We will handle your damage case with care and we will determine whether a warranty claim can be made. -
Page 24: Attachment 6: Eco Label
Attachment 6: ECO label Output Woodstove Capacity and CO-emission Reny Manufacturer: Optima Model: 6,3 - 10,0 kW Nominal capacity: Output classes High output ≥75% 70 - 75% 65 - 70% 60 - 65% 50 - 60% <50% Low output CO-emission...
