UTY-VSGXZ1
AMP Air Conditioning
INSTALLATION MANUAL
For authorized service personnel only.
INSTALLATIONSANLEITUNG
Nur für autorisiertes Fachpersonal.
MANUEL D'INSTALLATION
AMPLIFICATEUR DE SIGNAL
Pour le personnel agréé uniquement.
MANUAL DE INSTALACIÓN
AMPLIFICADOR DE SEÑALES
Únicamente para personal de servicio autorizado.
MANUALE DI INSTALLAZIONE
AMPLIFICATORE DI SEGNALE
A uso esclusivo del personale tecnico autorizzato.
ΕΓΧΕΙΡΙΔΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ
Μόνο για εξουσιοδοτημένο τεχνικό προσωπικό.
MANUAL DE INSTALAçãO
AMPLIFICADOR DE SINAL
Apenas para técnicos autorizados.
РУКОВОДСТВО ПО УСТАНОВКЕ
Только для авторизованного обслуживающего персонала.
MONTAJ KILAVUZU
SİNYAL AMPLİFİKATÖRÜ
Yalnızca yetkili servis personeli için.
仅针对授权的专业维修人员。
www.ampair.co.uk | sales@ampair.co.uk
SIGNAL AMPLIFIER
SIGNALVERSTÄRKER
ΕΝΙΣΧΥΤΗΣ ΣΗΜΑΤΟΣ
УСИЛИТЕЛЬ СИГНАЛА
安装说明书
信号放大器
PART NO. 9377898043
Advertisement
Summary of Contents for AirStage UTY-VSGXZ1
- Page 1 Pour le personnel agréé uniquement. MANUAL DE INSTALACIÓN AMPLIFICADOR DE SEÑALES Únicamente para personal de servicio autorizado. MANUALE DI INSTALLAZIONE AMPLIFICATORE DI SEGNALE UTY-VSGXZ1 A uso esclusivo del personale tecnico autorizzato. ΕΓΧΕΙΡΙΔΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ ΕΝΙΣΧΥΤΗΣ ΣΗΜΑΤΟΣ Μόνο για εξουσιοδοτημένο τεχνικό προσωπικό. MANUAL DE INSTALAçãO AMPLIFICADOR DE SINAL Apenas para técnicos autorizados.
-
Page 2: Table Of Contents
This mark indicates procedures which, if improp- INSTALLATION MANUAL CAUTION erly performed, might possibly result in personal PART NO. 9377898043 harm to the user or damage to property. Pay abundant care when transporting this unit because it is a precision SIGNAL AMPLIFIER device. -
Page 3: Selecting An Installation Location
When performing wiring work, be careful not to damage the cable or SELECTING AN INSTALLATION LOCATION injure yourself. Also, connect the connectors securely. Loose connec- tors will cause trouble, heating, fire, or electric shock. Dimensions 41 11 Install the indoor and outdoor units, power supply cable, transmission cable and remote controller cable 1 m (40 in.) away from television and The signal amplifier is comprised of a body and cover. -
Page 4: Installing The Signal Amplifier
61 11 Connecting the power supply cable VR-II Series Signal amplifier (Filter mode : OFF) for U1S1A1 and Canada 1Ø 50/60Hz Remove the 4 screws (M4 × 6 mm), and then remove the cover. FUSE 208-240V (3A) Install the conduit. Terminal Fix the conduit with lock nut. -
Page 5: Installing The Terminal Resistor
TURNING ON POWER Dust proof bushing CAUTION Check that the power supply voltage is within the specified range. If the power supply voltage outside the specification is input, it will cause trouble. Recheck the wiring. Incorrect wiring will cause trouble. Transmission cable Check the signal amplifier wiring. -
Page 6: Error Code
ERROR CODE Example 1) When A1 is set Press SW4 (the set button) to display the current address. The address is set to A1 at Error code Contents the factory. Address setting error Example 2) When A12 is set Main PCB error D9 LED lit or flashing Communication error B D14 LED lit or flashing...
