EV Solutions EVSE-RS Installation Manual

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

I N S TALL ATI ON GU I D E
EVSE-RS Plug-in Charging Station
IT IS RECOMMEND THAT A LICENSED ELECTRICIAN INSTALL
THE ELECTRICAL SERVICE AND THE CHARGING STATION.
Model Plug-in EVSE-RS not for outdoor installation
NOTICE TO ELECTRICIAN: Leave this Installation Guide with the EVSE-RS Plug-in customer for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVSE-RS and is the answer not in the manual?

Questions and answers

Summary of Contents for EV Solutions EVSE-RS

  • Page 1 EVSE-RS Plug-in Charging Station IT IS RECOMMEND THAT A LICENSED ELECTRICIAN INSTALL THE ELECTRICAL SERVICE AND THE CHARGING STATION. Model Plug-in EVSE-RS not for outdoor installation NOTICE TO ELECTRICIAN: Leave this Installation Guide with the EVSE-RS Plug-in customer for future reference.
  • Page 2 INSTALLATION STEPS wall stud 45 in. (114.3 cm) to floor 45 in. to floor Use Stud Finder to locate wall stud. Measure and mark a point on the wall stud 45 inches from the floor. Mark the center point of the wall stud. CHARGER MOUNTING DRILL .234 DIA X 2.00 DEEP...
  • Page 3 STUD CENTERLINE CHARGER MOUNTING Drill holes for Mounting Plate using a inch 3.345 INCHES drill bit. in 2 places on centerline of stud 45 INCHES TO FLOOR Drill holes for Cable Hanger using inch drill bit in 2 places Using Socket Wrench, tighten Mounting Plate lag bolts and washers.
  • Page 4 PACK AG I NG CO NTE NT S CHARGING STATION QUICK START GUIDE INSTALLATION GUIDE HARDWARE KIT HARDWARE KIT CONTENTS CABLE HANGER 1 - Mounting Plate inch x 2½ inch Lag Bolts inch Flat Washers INSTALLATION TEMPLATE 2 - #8 x 2½ inch Painted Head Wood Screws TOO L S (not included) Electronic Stud Finder...
