User Manual
OBM P Series
True Dual Monitoring Solutions
Operational Instructions
OBM-P180
OBM-P210
OBM-P240
OBM-P310
OBM-P420
OBM-P460
OBM-P550
06. 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OBM-P180 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Postium OBM-P180

  • Page 1 User Manual OBM P Series True Dual Monitoring Solutions Operational Instructions OBM-P180 OBM-P210 OBM-P240 OBM-P310 OBM-P420 OBM-P460 OBM-P550 06. 2017...
  • Page 2: Table Of Contents

    True Dual Monitoring Solutions OBM-P Series Picture By Picture Table of Contents 1. Precaution 2. Main Features 3. Location and Function of Parts and Controls Front Panel Rear Panel 4. Using the Menu 5. Adjustment Using the Menus 6. OSD Menu Operations Status Menu Color Temp/Color Space/Gamma Menu Zebra/Focus Menu...
  • Page 3: Precaution

    Protect the power cord from being walked on or pinched par cularly at plugs, convenience receptacles, and the point where they exit from the apparatus. When using other DC 12V(OBM-P180/P210/P240) or DC 24V(OBM-P310) adapters instead of the standard adapter provided by the manufacturer, please check the proper load capacity or current capacity and use an adapter with stable voltage.
  • Page 4 True Dual Monitoring Solutions OBM-P Series Picture By Picture Do not a empt to service the product yourself. Removing covers can expose you to high voltage and other dangerous condi ons. Request a qualified service person to perform servicing. When the product needs replacement parts, make sure that the service person uses replacement parts specified by the manufacturer, or those with the same characteris cs and performance as the original parts.
  • Page 5: Main Features

    True Dual Monitoring Solutions OBM-P Series Picture By Picture 2. Main Features The OBM P series incorporates the dual scaler, which enables to display the two different SDI signals on the screen. And, the OBM P series can display Waveform and Vector Scope on the two different SDI videos respec vely, which is very useful and convenient for dual monitoring.
  • Page 6: Location And Function Of Parts And Controls

    True Dual Monitoring Solutions OBM-P Series Picture By Picture 3. Location and Function of Parts and Controls Front Panel A : Input select Bu ons/Lamp Press to monitor the signal input to each connector. [SDI] Bu on/Lamp - Press the bu on to select SDI input. - The mode changes in the order of [3G SDI-1], [3G SDI-2] [ANALOG] Bu on/Lamp - Press the bu on to select Analog input.
  • Page 7 True Dual Monitoring Solutions OBM-P Series Picture By Picture [CHROMA] knob Press this knob to display the adjustment screen and adjust the color intensity. Press again to hide the adjustment screen. Turn the knob right to increase the color intensity and turn le to decrease it. [APERTURE] knob Press this knob to display the adjustment screen and adjust the picture sharpness.
  • Page 8: Rear Panel

    True Dual Monitoring Solutions OBM-P Series Picture By Picture Rear Panel Ethernet RS422 IN SDI-1 SDI-2 Y(CVBS1) AUDIO HDMI-IN REMOTE RS422 OUT A : SDI IN (SDI Input) connectors (BNC) Input connectors for SDI signals. For details, see “Connec ng the SDI Signals” (page 26). B : SDI OUT (SDI Output) connectors (BNC) Output connectors for SDI signals.
  • Page 9 Connects the DC power supply to the monitor. - OBM-P180 / 210 / 240 : 12V - OBM-P310: 24V Make sure to use DC 12V power supply for OBM-P180/210/240 and DC 24V power supply for OBM-P310. OBM-P180/210/240 OBM-P310 DC IN Socket...
  • Page 10: Using The Menu

    True Dual Monitoring Solutions OBM-P Series Picture By Picture 4. Using the Menu This monitor is equipped with an OSD menu to make various adjustments and se ngs such as picture control, input se ng, set se ng change, etc. 1.
  • Page 11: Adjustment Using The Menus

    True Dual Monitoring Solutions OBM-P Series Picture By Picture 5. Adjustment Using the Menus The OSD menu of this monitor consists of the following items. Status menu (To indicate the current se ngs) User Configura on menu Format User Preset Color Temp Func on Bu on Se ng F1 Bu on...
  • Page 12 True Dual Monitoring Solutions OBM-P Series Picture By Picture Remote menu Parallel Remote 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6 Pin 7 Pin 8 Pin Monitr ID In-Monitor Display Se ng IMD Type Transparency Text Color Le Tally Color Right Tally Color Security Se ng...
  • Page 13: Osd Menu

    True Dual Monitoring Solutions OBM-P Series Picture By Picture 6. OSD Menu Opera ons Status Menu The Status menu displays the current status of the Page 2/5 monitor. The following items are displayed. Page 1/5 When it is Single Mode, Status 1/5 is displayed as follows. User Preset RGB Range Back Light...
  • Page 14: Color Temp/Color Space/Gamma Menu

    True Dual Monitoring Solutions OBM-P Series Picture By Picture Color Temp/Color Space/Gamma Menu Opera ons Status Menu Page 4/5 These menus are used for adjus ng or se ng the color temperature, color space or gamma of the picture. Page 1/2 SDI Input SDI Payload ID Iden fier...
  • Page 15: User Configuration Menu

    True Dual Monitoring Solutions OBM-P Series Picture By Picture Color Temp/Color Space/Gamma Menu Camera Log Page 2/2 Selects a camera log for the input signal. [Off]: Sets off the camera log. [Default]: The log which is selected in [Default Log Sel.] menu is applied.
  • Page 16: Zebra/Focus Menu

    True Dual Monitoring Solutions OBM-P Series Picture By Picture User Configuration Menu Zebra/Focus Menu User Configura on consists of the adjustment menus such as [User Preset], [Func oon Bu on Se ng], [Input Se ng], [P&P Se ng], [Speaker Out / Audio Level Meter Se ng], [Marker Se ng], [WFM/Vector Se ng], [Closed Cap on Se ng], [Fast Mode Se ng], [System Se ng].
  • Page 17 True Dual Monitoring Solutions OBM-P Series Picture By Picture User Configuration Menu Page 2/7 Page 3/7 Speaker Out / Audio Level Meter Se ng Input Se ng - Selects the audio channel of the SDI & HDMI 3G Signal Format input signal.
  • Page 18 True Dual Monitoring Solutions OBM-P Series Picture By Picture User Configuration Menu Page 5/7 Page 4/7 WFM/Vector Marker - Sets to ac vate and deac vate Waveform - Selects On to display the marker, and Off to monitor and Vectorscope. deac vate it.
  • Page 19 True Dual Monitoring Solutions OBM-P Series Picture By Picture Page 7/7 Size Sets the size of Waveform and Vector Scope. [Large] and [Small] can be selected. * The size of Waveform and Vector Scope is fixed as Small in PBP Mode WFM&Throughout w/ Camera log The Waveform is displayed on the basis of the image, which the Camera log is applied to.
  • Page 20: Remote Menu

    True Dual Monitoring Solutions OBM-P Series Picture By Picture Remote Menu Monitor ID Sets the ID of the monitor to control the monitor Parallel Remote through Serial Remote or Network. Selects the Parallel Remote connector pins for which you want to change the func on. In-Monitor Display Se ng Various func ons can be assigned to pin 1 to 6.
  • Page 21: Security Menu

    True Dual Monitoring Solutions OBM-P Series Picture By Picture Security Menu Security Se ng Key Lock When Key Lock func on is set On, the change of the menu se ngs and func ons doesn’t work. ** The same func on as [Key Lock] bu on on the front panel.
  • Page 22: Pbp Mode

    True Dual Monitoring Solutions OBM-P Series Picture By Picture 7. PBP Mode Displays the two different input signals on the screen at the same me. Side-By-Side, Wipe, Blend mode can be selected. This func on is very useful when you adjust the color se ngs to either of the two images and compare the two images.
  • Page 23 True Dual Monitoring Solutions OBM-P Series Picture By Picture Dual Waveform Monitor & Vector Scope The OBM P series can display Waveform, Vector Scope on the two different SDI videos respec vely, which is very useful and convenient for dual monitoring. WIPE The area of the two pictures to be displayed is selected using a ver cal WIPE pa ern.
  • Page 24: Other Functions

    True Dual Monitoring Solutions OBM-P Series Picture By Picture 8. Other Functions Focus Assist Zebra This func on controls the aperture level of a video This func on displays the Luma(Y') level of the input signal, and displays images on screen with sharpened image in zebra pa ern.
  • Page 25 True Dual Monitoring Solutions OBM-P Series Picture By Picture In-Monitor Display(IMD) Func on The image source names and tally informa on can be displayed on the screen, with an external remote func on via Ethernet. The TSL system protocol is supported. The color of the source name and tally color can be selectable among White, Red, Green, Blue, Yellow, Cyan, Magenta.
  • Page 26: Available Signal Formats

    True Dual Monitoring Solutions OBM-P Series Picture By Picture 9. Available Signal Formats This monitor is applicable to the following signal formats HD-SDI Signal System Signal Format 1920x1080 / 4:2:2 YCbCr 10bit 23.98, 24, 25, 29.97, 30p/Psf, 50, 59.94, 60i 2048 x 1080 / 4:2:2 YCbCr 10bit 23.98, 24, 25, 29.97, 30p/Psf...
  • Page 27 True Dual Monitoring Solutions OBM-P Series Picture By Picture HDMI Signal System Signal Format 640 x 480p@59.94 / 60 720 x 480p@59.94 / 60 720 x 576p@50 4:4:4 RGB 8 / 10 / 12bit 4:4:4 YCbCr 8 / 10 / 12bit 1280 x 720p@50 / 59.94 / 60 4:2:2 YCbCr 12bit 1920 x 1080i@50 / 59.94 / 60...
  • Page 28: Product Specifications

    True Dual Monitoring Solutions OBM-P Series Picture By Picture 10. Product Specifications OBM-P180 / P210 / P240 OBM-P210 OBM-P240 ITEM OBM-P180 2 x BNC 3G/HD/SD-SDI-1/2 1 x HDMI HDMI 1.3a Input 3 x BNC (YPbPr) Analog(YPbPr) 1 x BNC (CVBS)
  • Page 29 True Dual Monitoring Solutions OBM-P Series Picture By Picture OBM-P310 / P420 ITEM OBM-P420 OBM-P310 2 x BNC 3G/HD/SD-SDI-1/2 1 x HDMI HDMI 1.3a Input 3 x BNC (YPbPr) Analog(YPbPr) 1 x BNC (CVBS) Composite Output 2 x BNC 3G/HD/SD-SDI-1/2 SMPTE ST 425-AB 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF) / 1080i (60/59.94/50) SMPTE ST 274...
  • Page 30 True Dual Monitoring Solutions OBM-P Series Picture By Picture OBM-P460 / P550 OBM-P460 OBM-P550 ITEM 2 x BNC 3G/HD/SD-SDI-1/2 1 x HDMI HDMI 1.3a Input 3 x BNC (YPbPr) Analog(YPbPr) 1 x BNC (CVBS) Composite Output 2 x BNC 3G/HD/SD-SDI-1/2 SMPTE ST 425-AB 1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF) / 1080i (60/59.94/50) SMPTE ST 274...
  • Page 31 True Dual Monitoring Solutions OBM-P Series Picture By Picture 208, Building A, Samsong Techno Valley, 140, Tongil-ro, Deogyang-gu, Goyang-si, Gyeonggi-do, Korea, 10594 Tel : +82.2.354.6055 / Fax : +82.2.354.6056 E-mail : sales@postium.com www.postium.com...
  • Page 32 True Dual Monitoring Solutions OBM-P Series Picture By Picture...
