Summary of Contents for RESQTEC Pow'rench 625-50
- Page 1 USER MANUAL POW’RENCH ENGLISH ORIGINAL RESQTEC USER MANUAL WWW.RESQTEC.COM...
-
Page 2: Table Of Contents
Regular maintenance 6.2.1 Regular Maintenance 6.2.2 Regular lubricatio 6.3. Annual maintenance 6.4. Lubrication charts 6.5. Recommended storage 6.6. Decommissioning & recycling 7. WARNINGS & LIMITATIONS 7.1. General instruction 8. TROUBLESHOOTING 9. WARRANTY 10. DISCLOSURE 11. CONTACT RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 3: Introduction: Safety First
USER MANUAL POW’RENCH 1. INTORDUCTION: SAFETY FIRST! 1.1. SAFETY MESSAGES RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 4: Safety Information
USER MANUAL POW’RENCH 1.3. SAFETY INFORMATION POW’RENCH With serial number: Distributor/Supplier information: ARTICLE NUMBER ITEM DESCRIPTION 9310.0010 Pow’rench 625-50 9310.0020 Pow’rench 750 9310.0030 Pow’rench 1000 RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 5: Product Summary
USER MANUAL POW’RENCH 2. PRODUCT SUMMARY 2.1. INTRODUCTION INFORMATION LABEL CARRYING HANDLE SOCKET RETAINING PINS SET SCREW HEAD POWER CONTROL RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 6: Product Range
3.1. PRODUCTS & ACCESSORIES ARTICLE NUMBER ITEM DESCRIPTION USAGE & RESTRICTIONS 9310.0010 Pow’rench 625-50 See chapter 4 – 8. 9310.0020 Pow’rench 750 See chapter 4 – 8. 9310.0030 Pow’rench 1000 See chapter 4 – 8. RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 7: General Operating Instructions
4.1. INITIAL USE • Check the product's exterior. Do not use if it exhibits major damage • See chapter 6 for further information. and/or does not function as intended. • Check the bolt. It must be firmly fixed. • See chapter 6 for further information. RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 8: Dis)Connecting Square Drives
4.4. (DIS)CONNECTING SQUARE DRIVES Select the required square drive. Connect the offset to the Pow’rench by aligning the socket retaining pins with the offset’s sockets. To disconnect, hold the attached square drive and pull until it comes off. RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 9: Operating The Product
Rotate clockwise, or reciprocate it like a ratchet wrench. Continue until the nut or bolt is fastened at the desired. The arrow on the label should point to the right, indicating the clockwise direction. The nut or bolt is now fastened. RESQTEC Manual POW’RENCH Series (DM072K04) - Page 10 Rotate anticlockwise, or reciprocate it like a ratchet wrench until you feel no morere- sistance. The arrow on the label should point to the left, indicating the anticlockwise direction. The nut or bolt can now be removed by hand. RESQTEC Manual POW’RENCH Series (DM072K04)
-
Page 11: Adjusting The Power
Place the set screw wrench on the set screw head, recessed in the end of the handle. Turn the set screw head with the set screw wrench. Adjust the position of the set screw head to the required setting. RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 12: Precise Tightening
With a precision torque measuring device, check the tightness of the bolt to ascertain if the correct value was attained. Repeat this procedure until the precise torque value is attained by adding or omitting impacts. RESQTEC Manual POW’RENCH Series (DM072K04) - Page 13 USER MANUAL POW’RENCH Once the number of impacts to obtain torque is ascertained, repeat the process three times for assurance. RESQTEC Manual POW’RENCH Series (DM072K04)
-
Page 14: Specifications
10.4 kg Dimensions 677 x 128 x 145 mm (±10 mm) Size of square drive 25.4 mm Head radius 63.5 mm Head width 66.7 mm Handle length 609 mm Max pull on handle 34 kg RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 15: Imperial System Data
Weight 23 lbs Dimensions 26 5/8” x 5” x 5 3/4" (± 3/8”) Size of square drive 1" Head radius 2 1/2" Head width 2 5/8” Handle length 24” Max pull on handle 75 lbs RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 16: Technical Drawings
USER MANUAL POW’RENCH 5.2. TECHNICAL DRAWINGS RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 17: Maintenance & Storage
• Mild soapy water can be used if necessary. Dry thoroughly after using water. If the product is not functioning Check product functioning after cleaning. • Fasten and unfasten at least three (3) properly, contact your Resqtec times. distributor/supplier. RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 18: Regular Maintenance
• Lubricate with 10-20-30 wt. oil weekly. Do not use any other means of lubrication, as some products might Model 1000 • Check chapter 6.4 for further details. have a negative effect on the equipment. RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 19: Annual Maintenance
USER MANUAL POW’RENCH 6.3. ANNUAL MAINTENANCE RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 20: Lubrication Charts
USER MANUAL POW’RENCH 6.4. LUBRICATION CHARTS RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 21: Recommended Storage
USER MANUAL POW’RENCH 6.5. RECOMMENDED STORAGE Recommended storage temperature range 10 °C – 30 °C / 50 °F – 86 °F Recommended storage relative humidity 0 – 60% RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 22: Warnings & Limitations
USER MANUAL POW’RENCH 7. WARNINGS & LIMITATIONS 7.1. GENERAL INSTRUCTIONS RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 23: Troubleshooting
- Make sure the rotor is not burred. For further details, please see chapter 6. - Make sure all teeth on the ratchet are intact. The product fails to impact. No ratchet action. - Make sure all pawl springs are intact. RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 24: Warranty
USER MANUAL POW’RENCH 9. WARRANTY RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 25: Disclosure
USER MANUAL POW’RENCH 10. DISCLOSURE RESQTEC Manual POW’RENCH Series (DM072K04) -
Page 26: Contact
USER MANUAL POW’RENCH 11. CONTACT RESQTEC Manual POW’RENCH Series (DM072K04) - Page 27 USER MANUAL POW’RENCH RESQTEC Zumro B.V. Meer en Duin 82 2163 HC Lisse, the Netherlands +31 (0)252 419002 +31 (0)252 411794 info@resqtec.com WWW.RESQTEC.COM...
