AutoDab FM Installation & User Manual

Table of Contents

Download this manual

What's in the pack?

Remote Key:

1 - Menu

2 - Add/Delete

3 - Pre-set Up

• On first install, the AutoDAB controller will default to transmitting on 87.5MHz. Tune the car radio to this frequency.

• The car radio will display 'AutoDAB' and the audio message 'Scanning AutoDAB, please wait' will be heard.

• The audio message repeats every 5 seconds.

• Choose a preset on the car radio and store the AutoDAB frequency to it.

4 - Station Left

5 - OK

6 - Station Right

7 - Pre-set Down

8 - Scan

9 - On/Off

INSTALLATION

& USER GUIDE

Table of Contents

Need help?

Do you have a question about the FM and is the answer not in the manual?

Page 1 Getting Started - Initial Setup of Head Unit • On first install, the AutoDAB controller will default to transmitting on 87.5MHz. Tune the car radio to this frequency. • The car radio will display ‘AutoDAB’ and the audio message ‘Scanning AutoDAB, please wait’ will be heard.
Page 2: Scanning For Stations
Absolute Browsing through Pre-set Stations • Your AutoDAB will come with pre-sets already loaded. To browse through your pre-sets, simply use the ‘Pre-set Up / Down’ Scanning for Stations • To update the available station in your current location, press ‘Scan’ and the audio message ‘Scanning will repeat twice.
Page 3: Menu Tree
A to Z or in Ensemble mode (all stations listed by ensemble i.e. Set Browse a group of stations that are transmitted together). Allows user to adjust the FM freq. which the AutoDAB broadcasts on. The Set Frequency default is 87.5MHz.
Page 4 FIG 1 • Plug the cigarette lighter charger into the nearest 12v supply to where you want to locate the AutoDAB box – the red light should illuminate. • Plug the 3.5mm Jack into the cars aux-in socket. (if required) •...
