Summary of Contents for Gospell 8902BG
- Page 1 2.4GHz Wireless Car Rearview Camera and Receiver Model: 890 2BG 8902MJ...
-
Page 2: Table Of Contents
CONTENTS 1. Foreword 2. Packing List 3. Structure 4. Installation 5. Specifications 6. FCC Information Back Cover * 89 02BG means 890 + G 406 + T 013 8902MJ means GL8902 GT4065 Gb6904... -
Page 3: Foreword
1. FOREWORD car rearview CONGRATULATIONS. The Wireless Camera, when used as described, w ill give you years of dependable service in your car, truck, RV, or mini-van. We have taken numerous measures in quality control to ensure that your product arrives in top condition, and will perform to your satisfaction. -
Page 4: Structure
3. STRUCTURE Camera Car Rearview Gl8902 Connector Wire to Gt4065 Gt4065 Wireless Transmission Box Power Wire Connector to Gl8902... -
Page 5: Installation
4. INSTALLATION These installation instructions do not apply to all vehicles. They are meant as only as a general guide due to common vehicle makes & models. For specific questions, contact your vehicle's manufacturer. Consult your local motor vehicle laws on the use of this product. 4-1 CAMERA INSTALLATION You may mount the camera near the license plate's top with screws. - Page 6 Note: * Some vehicle's may have a hole available to pass the wire through, if not, you need to drill a hole close to the location of camera for the connector wire, and two holes for the screws of camera installation. * Before you drill those holes, you must check out and make sure no other components too close to your aiguille.
- Page 7 To locate the reverse light's 12/24VDC wire it will be necessary to gain access to the rear of the vehicle's tail light. For help locating the vehicle's reverse light circuit contact your vehicle's manufacturer for vehicle specific wiring diagrams. (F ig6) 7.Once you have located the reverse light circuit you will have to route the GT4062 Camera's...
- Page 8 10. Following the In-Line Wire Connector Instructions section, splice the Red wire using the supplied In-Line Wire Connector to the reverse light's positive(+) wire. Use a set of slip joint pliers to squeeze the TAP and insure good connection. 11. Next splice the black wire of the transmission box GT4062 power wire to the reverse light's negative(-) wire or ground.
- Page 9 In-Line Wire Connector Instructions Insert the existing Insert the wire to Crimp tap then wire to be tapped. be attached. close lock You do not need to use the In-Line Wire Connectors. GT4062 wired directly to the reverse light circuit by stripping the reverse light wires then twisting GT4062 wires to the exposed reverse light wires.
-
Page 10: Specifications
5. SPECIFICATIONS GL8902+GT4065 4 (NTSC) 5 6(PAL) Horizontal View Angle 80 degree ISM 2,400-2,483MHz 2mW/FCC,10wm/CE <0. Lux Minimum Illumination IR Night Range +12 DC (Max.) 150mA Modulation ISM 2,400-2,483MHz 12V 24V DC Input voltage Output current 1 5A Output Voltage Received Sensitivity ≤-85 dBm Consumption Current (Max.) -
Page 11: Fcc Information
FCC INFORMATION This device complies with part15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. - Page 12 GOSPELL Smarthome Electronic CO.,LTD. 4-5Floor/Block 2, Vision (SZ) Park, Hi-Tech Industrial Park, Shenzhen, P.R.China...
