- Page 1 User Manual TPUH412 HDBaseT Extender All Rights Reserved Version: TPUH412_2016V1.1 www.digichain.nl...
-
Page 2: Fcc Statement
Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Digichain Electronics www.digichain.nl... -
Page 3: Safety Precautions
Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Digichain Electronics www.digichain.nl... -
Page 4: Table Of Contents
1.2 Features ......................1 1.3 Package Contents ..................... 1 2. Panel Description ......................2 2.1 TPUH412T ......................2 2.2 TPUH412R ......................3 3. System Connection ..................... 4 3.1 Usage Precautions .................... 4 3.2 System Diagram ....................4 3.3 Connection Procedure ..................4 3.4 Application ...................... -
Page 5: Introduction
1. Introduction 1.1 Introduction to TPUH412 TPUH412 is a mini-size extender set consists of (TPUH412T) and receiver (TPUH412R). HDBaseT technology is used to transmit high-resolution 1080p/ 4k signal from transmitter to the receiver via a CAT5e/CAT6a cable at a distance of up to 70/40m.Moreover, TPUH412 support CEC, bi-directional RS232&IR control, and... -
Page 6: Panel Description
IR OUT far-end IR IN port ⑦ HDMI IN Connect with HDMI source Connect to the HDBT IN socket on TPUH412R via CAT5e/ CAT6a ⑧ HDBT OUT cable, support bi-directional PoH. Connect with power supply (Not necessary if TPUH412R connects ⑨... -
Page 7: Tpuh412R
TPUH412 4K HDMI HDBaseT Extender 2.2 TPUH412R Name Description HDBT Link status indicator: OFF: No Link ① LINK GREEN:Link Successful Blinking GREEN: Link abnormal HDCP compliant indicator OFF: No HDMI traffic (no picture) ② HDCP ... -
Page 8: System Connection
Step1. Connect HDMI source (such as Blue-ray DVD) to HDMI IN port of TPUH412T with HDMI cable. Step2. Connect HDBT OUT port of TPUH412T and HDBT IN port of TPUH412R, with single CAT5e/CAT6a cable. Step3. Connect HDMI displayer (such as HDTV) to HDMI OUT port of TPUH412R with HDMI cable. -
Page 9: Application
TPUH412 4K HDMI HDBaseT Extender Step4. Both TPUH412T and TPUH412R have IR IN and OUT. When one end is used as an IR receiver, the signal sent from the end can only be transmitted via the other end. For example: When “IR IN” of TPUH412T connects with an IR receiver, the IR emitter must connect to IR OUT of TPUH412R. -
Page 10: Specification
TPUH412 4K HDMI HDBaseT Extender 4. Specification Model TPUH412T TPUH412R Spec Input Input Signal 1 HDMI,1 IR & 1 RS232 1 IR, 1 RJ-45 & 1 RS232 HDMI female, 3.5mm mini 3.5mm mini jack, RJ-45, 3p Input Connector jack, 3p captive screw... - Page 11 60Hz 1920x1200 60Hz 1680x1050 60Hz 16:10 1360x768 60Hz 1280x800 60Hz 1600x1200 60/65/70/75/85Hz 1280x1024 60/75/85/96Hz 1024x768 60/70/75/85Hz 800x600 56/60/72/75/85Hz 640x480 60/72/75Hz Note: TPUH412 supports 4k HDMI signal, please adopt quality HDMI cables compliant with HDMI2.0 for reliable transmission. Digichain Electronics www.digichain.nl...
-
Page 12: Panel Drawing
5. Panel Drawing LINK HDCP RS232 IR IN IR OUT HDMI IN HDBT OUT DC 24V 115 mm 5-1 TPUH412T LINK HDCP RS232 IR IN IR OUT HDMI OUT HDBT IN DC 24V 115 mm 5-2 TPUH412R Digichain Electronics www.digichain.nl... -
Page 13: Troubleshooting & Maintenance
Check the grounding and make sure all the components are properly grounded to a common ground. Improper grounding may cause damage to the receiver. If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support. Digichain Electronics www.digichain.nl... -
Page 14: After-Sales Service
Any transport costs are borne by the users during the warranty. Product Limited Warranty: Digichain warrants that its products will be free from defects in materials and workmanship for three years, which starts from the first day the product leaves warehouse (check the SN mark on the product). - Page 15 Digichain Electronics Tel: +31 (0)85 2019688 Email: info@digichain.nl Website: www.digichain.nl...
