Tsuruga 442B User Manual

Micro printer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL 442B
Micro Printer
Users Manual
TSURUGA ELECTRIC CORPORATION
I-01805

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 442B and is the answer not in the manual?

Questions and answers

Summary of Contents for Tsuruga 442B

  • Page 1 MODEL 442B Micro Printer Users Manual TSURUGA ELECTRIC CORPORATION I-01805...

  • Page 2: Table Of Contents

    Contents General ······················································· 1 5.3.8 BCD A-F ······································ 17 5.3.9 POL logic switching ························ 18 1. For Safety ················································· 2 5.3.10 Interval operation ························· 18 1.1 Safety operation ···································· 2 5.3.11 Interval time ································ 19 5.3.12 Blank line ··································· 19 2.

  • Page 3: General

    Perchlorate Material – special handling may apply,See http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Please confirm each product incorporates the following accessories. (1) 442B Main body (2) Connector with 2m flat cable/without no connector on top (3) Chart paper (one roll) (4) Users manual TSURUGA ELECTRIC CORPORATION...

  • Page 4: For Safety

    MODEL 442B 1. For Safety 1.1 Safety operation For safety operation, please follow the instruction herein under. There are two symbols marks for safety in this manual.  WARNING Operation error might be caused of human death or serious wound.

  • Page 5: Installation

    MODEL 442B 2. Installation 2.1 Main body Insert a main body to front side of panel, and fix it with screws at both sides from back. +0.8 +0.8 Panel cutout : 92 × 92 REAR Panel thickness: 1 to 6 mm Note) 1.5mm or more thickness is...
  • Page 6 MODEL 442B (1) Method of opening and shutting roll paper cover ●How to open a roll chart cover ●How to close a roll chart cover Press Open/Close button for a roll chart cover. Press both side of a roll chart cover.

  • Page 7: Dimensions

    MODEL 442B 2.3 Dimensions 20.5 MAX25 unit: mm 3. Description of parts 3.1 Front panel Display ①MODE Key ④POWER LED ②SHIFT Key ③UP Key ⑤FEED Key ⑥Open/Close button for chart roll cover. ① MODE Key Switching Setting Mode during operation.

  • Page 8: Rear Panel

    MODEL 442B 3.2 Rear panel DATA ⑦Power terminal ⑧ BCD connector 100V-240V 50/60Hz 17VA At 24V DC power 0.7A ⑦ Power terminal For power supply ⑧ BCD connector 40 pins connector each for A and B line. Input is TTL level, and output Transistor.

  • Page 9: Wiring

    MODEL 442B 4. Wiring  WARNNING  After turn Power Off, do wiring works. Otherwise, electric shock might be assumed.  Don’t do wiring works with wet hands or under high humid environment. Otherwise, electric shock might be assumed.  Do not touch power terminals while powered. Otherwise, electric shock might be assumed.

  • Page 10: Connecter

    MODEL 442B 4.2 Connecter ●Pin arrangement Function A line B line Function DATA DATA DATA DATA DATA DATA DATA DATA UNIT 0 UNIT 1 ――――― UNIT 2 ――――― UNIT 3 ――――― ――――― UNIT 4 UNIT 5 ――――― UNIT 6 ―――――...
  • Page 11 MODEL 442B ●Input/Output signal ――― Data input: DATA, UNIT, POL, DP , CH No., and MSG -1mA, “L”= 0 to 1.5V, “H”=3.5 to 5V ≦ DATA: 8 digits BCD input At positive logic input: L level = “0”, H level = “1”...

  • Page 12: Timing Chart

    MODEL 442B ● Timing chart ―――――――― PRINT or Time-Up ――――――― SYNC BCD data ｔ BUSY Printing after rising L of SYNC. A: Min. 10ms B: Max. 5ms Input time of data. C: Max. 200ms Note) In the case of blank line setting, approx.150ms blank line is added.

  • Page 13: Function And Setting

    MODEL 442B 5. Function and setting 5.1 Summary of function Code Function Display Description Factory set № Display setting  0: Hours/Minutes/Second, 1: OFF  Clock setting Hours/Minutes Note 1) Date setting  Tear/Month/Date Note 1) Index No.,  0: No printing Calendar clock, 1: Index No.

  • Page 14: Explanation Of Function

    MODEL 442B 5.2 Explanation of function Code No.01: Display setting Switching Hour/Minute/Second display and OFF display. Code No.02: Time setting Adjusting Hour of calendar clock. 24 hour (0 to 23) adjustable. Second unit setting is unavailable. (00 sec. only) Code No.03: Date setting Adjusting Year/Month/Date of calendar clock.
  • Page 15 MODEL 442B Code No.08: BCD A-F setting Switching to SP (space) printing at BCD data input A to F code. ◆BCD data and printing BCD number setting 8421 0000 Printing example at positive logic of BCD data. 0001 0010 0011...

  • Page 16: Setting

    Press MODE key for 1 sec. or more during operation to get setting mode (Display:  In operation MODE POWER SHIFT MICRO PRINTER MODEL 442B FEED Back to Cod.00 by code No. to be set. MODE 1 sec Memorized by Code 01...

  • Page 17: Date

    Press MODE key for 1 sec. or more during operation to get setting mode (Display:  In operation MODE POWER SHIFT MICRO PRINTER MODEL 442B FEED Back to Cod.00 by code No. to be set. MODE 1 sec Code 03 Completed by...

  • Page 18: Printing Direction

    Press MODE key for 1 sec. or more during operation to get setting mode (Display:  In operation MODE POWER SHIFT MICRO PRINTER MODEL 442B FEED Back to Cod.00 by code No. to be set. MODE 1 sec Memorized by Code 05...

  • Page 19: Bcd Digit

    Press MODE key for 1 sec. or more during operation to get setting mode (Display:  In operation MODE POWER SHIFT MICRO PRINTER MODEL 442B FEED Back to Cod.00 by code No. to be set. MODE 1 sec Memorized by Code 07...

  • Page 20: Pol Logic Switching

    Press MODE key for 1 sec. or more during operation to get setting mode (Display:  In operation MODE POWER SHIFT MICRO PRINTER MODEL 442B FEED Back to Cod.00 by code No. to be set. MODE 1 sec Memorized by Code 09...

  • Page 21: Interval Time

    Press MODE key for 1 sec. or more during operation to get setting mode (Display:  In operation MODE POWER SHIFT MICRO PRINTER MODEL 442B FEED Back to Cod.00 by code No. to be set. MODE 1 sec Memorized by Code 11...

  • Page 22: Unit

    Press MODE key for 1 sec. or more during operation to get setting mode (Display:  In operation MODE POWER SHIFT MICRO PRINTER MODEL 442B FEED Back to Cod.00 by code No. to be set. MODE 1 sec Memorized by Code 13...

  • Page 23: Message

    Press MODE key for 1 sec. or more during operation to get setting mode (Display:  In operation MODE POWER SHIFT MICRO PRINTER MODEL 442B FEED Back to Cod.00 by code No. to be set. MODE 1 sec Memorized by Code 14...

  • Page 24: Reset To Factory Setting

    MODE POWER Turn power on while pressing both FEED and MODE key for SHIFT MICRO PRINTER MODEL 442B FEED test rinting. Keep on pressing MODE key till test printing is completed. After the test printing is completed, the message “FACTORY SETTING”...

  • Page 25: Printing And Function

    MODEL 442B 6．Printing and function 6.1 Interval ● Interval OFF ―――――――― By inputting PRINT signal, BCD data is collected and printed. ―――――― By inputting TIME signal, the setting information for Index No., Calendar clock ,and Elapsed ―――――――― ―――――― time are printed. If PRINT...

  • Page 26: Upright/Inverted Printing

    MODEL 442B ● Message printing The message to be printed is selected by MSG Input (MSG8, MSG4, MSG2, and MSG1 signal). The registered message can be printed, as well. MSG8 MSG4 MSG2 MSG1 Type of message OVER HIGH GOOD H NG L NG ＊...

  • Page 27: Test Printing

    MODEL 442B Printing sample 6.2.3 Test printing Test printing starts by supplying power while pressing FEED Key. After Test printing is completed, the product backs to normal operation condition. Test printing prints Test Pattern and Setting status. 6.2.4 Character code and unit table ■...
  • Page 28 MODEL 442B ■ Unit table The following is Unit to be set by UNIT 0 to 7 UNIT UNIT UNIT UNIT Unit Unit Unit Unit 76543210 76543210 76543210 76543210 00000000 00100000 01000000 01100000 kl/h 00000001 00100001 01000001 feet 01100001 Pa･s...

  • Page 29: Error

    MODEL 442B 6.3 Error 6.3.1 Paper end detection Paper end detection sensor is incorporated to detect paper end. PE output (“H”) is provided at no paper, and in this case the printing is unavailable. POWER LED is blinking. The previous one cycle data just before paper end is printed out after resetting paper end.

  • Page 30: Specification

    MODEL 442B 7. Specification 7.1 Model 442B－□ [ 1 ] Power supply Code Power Supply 100 to 240V AC Power supply 24V DC 7.2 Performance Power supply: 100 to 240V AC 50/60Hz, 24V DC. Power range: 90 to 250V AC, 21.6 to 26.4V DC.

  • Page 31: Printer

    ±3 sec. per day. (at 25℃) A leap year adjustment: Automatic adjustment till 2099. Power failure measure: Calendar clock works. (Battery life approx. 10 years.) Contact Information Name : Tsuruga Electric Corporation Address : 1-3-23 Minami-Sumiyoshi, Sumiyoshi-ku, Osaka-shi 558-0041 Japan TSURUGA ELECTRIC CORPORATION...
