ANSI Z21.97/CSA 2.41-2014
Outdoor Decorative Gas Appliances
Installer: Leave these instructions with consumer .
Consumer: Keep these instructions for further reference.
DANGER
If you smell gas:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance
and immediately call your gas supplier or fire
department.
WARNING
WARNING:
Improper installation, adjustment,
alteration, service or maintenance can cause injury or
property damage. Read the installation, operating, and
maintenance instructions thoroughly before installing
or servicing this equipment.
OUTDOOR GAS FIRE PIT WITH CERAMIC TILE TOP
®
C
US
®
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space
such as a camper, tent, car or home.
MODEL#: 88-533DBTE
WARNING: For Outdoor Use Only
WARNING:
Do not store or use gasoline or
other flammable vapors and liquids in the vicinity of
this or any other appliance. An LP-cylinder not
connected for use shall not be stored in the vicinity
of this or any other appliance. An LP-cylinder not
connected for use shall not be stored in the vicinity
of this or any other appliance.
Questions, Problems, Missing Parts
Please contact customer service at (800) 544-1108
Monday-Friday 8:00 AM - 5:00 PM EST for additional
warranty claim details and procedures.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 88-533DBTE and is the answer not in the manual?

Questions and answers

Summary of Contents for Cosco 88-533DBTE

  • Page 1 OUTDOOR GAS FIRE PIT WITH CERAMIC TILE TOP MODEL#: 88-533DBTE ® ® ® ANSI Z21.97/CSA 2.41-2014 Outdoor Decorative Gas Appliances Installer: Leave these instructions with consumer . WARNING: For Outdoor Use Only Consumer: Keep these instructions for further reference. DANGER...
  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION • The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA54;National Fuel Gas Code; Natural Gas and Propane Installation Code , CSA B149.1 ;or Propane Storage and handing Code, CSA B149.2, as applicable.
  • Page 3 IMPORTANT SAFETY INFORMATION ABOUT PROPANE(LP) GAS • The LP-gas supply cylinder to be used must be constructed and marked in accordance with the U.S. Department of Transportation(DOT)Specifications for LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubs for Transportation of Dangerous Goods and Commission, CAN/CSA-B339,as applicable. •...
  • Page 4: Specifications

    SPECIFICATIONS 40,000BTU/hr Rated Heat Input(Liquid Propane Natural Gas) Propane Regulator Pressure 11 inches water column Natural Gas inlet Pressure 7 inches water column Clearance to combustible surfaces Sides:24in.Top:72in. 1. Carefully unpack all parts from the box, compare parts with package content listed above, make sure all parts are present before beginning assembly of product.
  • Page 5 4. Open the door, place the gas cylinder into the cylinder holder, Figure 5 (see Figure 5). Connect the regulator, screw the black handle clockwise to tighten, turn the black handle counterclockwise to remove, (see Figure 6). The hose must point down. The knob on the control panel is turned all the way to the "OFF"...
  • Page 6: Leak Test

    BATTERY Make sure the control is in the "OFF" position. Unscrew the push button cap on the ignitor module located on the control panel to access the battery compartment. The ignitor module requires one AA size battery (not included) (see Figure 13).
  • Page 7: Lighting Instructions

    LIGHTING INSTRUCTIONS 1. Push in gas control knob slightly and turn to "OFF" (see Figure 18). 2. Turn gas control knob to the " ". 3. Push in gas control knob all the way and hold. Continue to press the ignition button for 15 seconds. 4.
  • Page 8: Illustrated Parts List

    ILLUSTRATED PARTS LIST 1 Handle 2 Burner cover 3 Ceramic tile 4 Ceramic tile 5 Table top rim 6 Burner 7 Electrode tip 8 Fire bowl 9 Pilot box 10 Orifice 11 Bellows 12 Heat shield 13 Thermocouple 14 Pulse ignition system 15 Gas control knob 16 Control panel 17 Hose assembly...
  • Page 9 FOYER DE PLEIN AIR À GAZ, AVEC DESSUS DE TABLE EN CARRELAGE MODÈLE n° : 88-533DBTE ® ® ® ANSI 221.97/CSA 2.41-2014 Appareils de plein air et décoratifs à gaz AVERTISSEMENT : Destiné à un Installateur : Laissez ce mode d’emploi au consommateur.
  • Page 10: Instructions Importantes Sur La Sécurité

    INSTRUCTIONS IMPORTANTES SUR LA SÉCURITÉ • L’installation doit être conforme aux codes locaux ou, en l’absence de codes locaux, au Code national sur le gaz et le fioul, ANSI Z223.1NFPA54, au Code national sur le gaz et le fioul, Installation au gaz et au propane, CSA 8149,1, ou au Code de manutention et stockage du propane, CSA 8149,2, le cas échéant.
  • Page 11 INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ À PROPOS DU PROPANE (GPL) • La bouteille d’arrivée de gaz GPL devant être utilisée, doit être fabriquée et marquée conformément aux indications de l’US Department of Transportation (DOT), relatives aux bouteilles de propane, ou à la norme pour les bouteilles, sphères et tubes pour le transport et la mise en service des marchandises dangereuses, CAN / CSA-8339, le cas échéant.
  • Page 12: Caractéristiques

    CARACTÉRISTIQUES 40,000 BTU / h Arrivée de chaleur nominale (gaz propane liquide naturel) Colonne d’eau de 27,94 cm (11 pouces) Régulateur de pression du propane Colonne d’eau de 17,78 cm (7 pouces) Pression d’arrivée du gaz naturel Côtés : 60,96 cm (24in.) Dessus : 182,88 cm (72in.) Dégagement des surfaces combustibles 1.
  • Page 13 4. Ouvrez la porte, placez la bouteille de gaz dans le support à Figure 5 bouteille de gaz, connectez le régulateur, visser la poignée noire dans le sens des aiguilles d’une montre pour serrer, tournez la poignée noire dans le sens inverse des aiguilles d’une montre pour la retirer.
  • Page 14 BATTERIE Assurez-vous que le bouton de contrôle soit sur la position « OFF » (Arrêt). Dévissez le couvercle du bouton poussoir sur le module d’allumage situé sur le panneau de commande pour accéder au compartiment de la pile. Le module d’allumage fonctionne avec une pile de taille AA (non inclus) (voir Figure 13).
  • Page 15: Instructions Pour L'allumage

    INSTRUCTIONS POUR L’ALLUMAGE 1. Poussez sur le bouton de contrôle du gaz et tournez-le pour le placer sur la position « OFF » (voir Figure 18). 2. Tournez le bouton de contrôle du gaz vers « ». 3. Pousser sur le bouton de contrôle du gaz jusqu’au bout et maintenez-le. Continuez à appuyer sur le bouton d’allumage pendant 15 secondes.
  • Page 16 LISTE DES PIÈCES - ILLUSTRATION 1 Poignée 2 Couvercle du brûleur 3 Carrelage 4 Carrelage 5 Rebord de la table 6 Brûleur en céramique en céramique 7 Pointe de l´électrode 8 Réceptacle pour le feu 9 Boîte pilote 10 Orifice 11 Soufflets 12 Bouclier thermique 13 Thermocouple...
  • Page 17 BRASERO DE GAS PARA EXTERIORES CON ENCIMERA DE AZULEJOS DE CERÁMICA MODELO NO.: 88-533DBTE ® ® ® ANSI Z21.97/CSA 2.41-2014 Aparatos decorativos a gas para exteriores ADVERTENCIA: Instalador: deje estas instrucciones con el consumidor. Para uso exclusivo al aire libre Consumidor: conserve estas instrucciones para futuras consultas.
  • Page 18 INFORMACIÓN IMPORTANTE DE SEGURIDAD • La instalación debe cumplir con los códigos locales o, en ausencia de estos, con el "Código Nacional de gas combustible", ANSI Z223.1 NFPA54; el "Código de instalaciones de gas natural y de propano", B149.1 CSA; o el "Código de almacenamiento y manejo de propano", B149.2 CSA, según apliquen.
  • Page 19 INFORMACIÓN IMPORTANTE DE SEGURIDAD SOBRE EL GAS PROPANO • El cilindro de suministro de gas propano licuado a utilizarse debe estar construido y marcado de acuerdo con las "Especificaciones para cilindros de gas propano licuado" del Departamento de Transporte (DOT) de los EE.UU., o la "Norma para cilindros, esferas y tinas para el transporte de mercancías peligrosas", CAN/CSA-B339 de Canadá, según corresponda.
  • Page 20: Especificaciones

    ESPECIFICACIONES 40,000BTU/hr Alimentación nominal de calor (gas natural, propano licuado) Regulador de presión del propano 11 pulgadas de columna de agua Presión de entrada del gas natural 7 pulgadas de columna de agua Lados: 24 pulg. (60 cm), parte superior: 72 pulg. (180 cm) Separación de las superficies combustibles 1.
  • Page 21 4. Abra la puerta, coloque el cilindro de gas en el soporte Figure 5 del cilindro (véase la Figura 5). Conecte el regulador, atornille el asa negra en sentido horario para apretarla, gire el asa negra en sentido antihorario para sacarla (véase la Figura 6).
  • Page 22 BATERÍA Asegúrese de que el control esté en la posición "OFF" (cerrado). Desenrosque la tapa del botón en el módulo de encendido situado en el panel de control para acceder al compartimiento de la batería. El módulo del encendido requiere una batería de tamaño AA (no incluido) (véase la Figura 13). Figura 13 ADVERTENCIA: 1.
  • Page 23: Instrucciones De Encendido

    INSTRUCCIONES DE ENCENDIDO 1. Presione levemente la perilla de control de gas y gírela a la posición "OFF" (cerrada) (véase la Figura 18). 2. Gire la perilla de control de gas a la posición " " 3. Presione la perilla de control de gas hasta el fondo y manténgala presionada. Continúe presionando el botón de encendido durante 15 segundos.
  • Page 24 Tapa de plástico de perno (ST4.2*9.5) Tornillo (M4*5) Tornillo (M4*8) Tornillo (M4*15) Tornillo (M4*20) 2525 State Street Columbus, IN USA 47201-7494 See other great outdoor furniture by Cosco at www.coscoproducts.com 812.314.4575 • 1.888.818.5110 2/16 4358-6942 Made in China / Hecho en China...
