Crenova 6016A Operating Manual

Operating Manual of Crenova 6016A Clamp Digital Multimeter
I. Overview
Crenova 6016A is a battery-driven 3 1/2 digital clamp meter for automatic range conversion which is
characterized by stable performance and high reliability. This meter applies 16mm word height LCD with
distinct readings, and features maximum hold, data hold and automatic on-off function.
This clamp meter can be used for measuring parameters such as DC voltage, AC voltage, resistance,
diode and on-off test. The complete meter is cored by dual integral A/D conversion of large scale
integrated circuit and features automatic range conversion function. It is a high-performance meter well
received by lab, factory, radio amateur and family.
Warning: before using the clamp meter, please read through "Safety Precautions".
We have already sent an online manual to you, please check your email.You can reply us in the email
about any question. Thank you.
II. Open-case inspection
Open the packing case and check if the following items are missing or damaged.
One 6016A
One leather box
One certificate of inspection
One copy of operating manual
One pair of test leads
Two 1.5V AAA batteries
III. Safety precautions
Please note "warning sign
danger to user or cause damage to the clamp meter or device under test.
This meter is strictly in line with GB4793 Safety Requirements on Electronic Measuring Instrument,
IEC61010 and IEC1010-2-032 safety standard. It complies with safety standard for double insulation,
over-voltage CAT III 300V and pollution class 2.
Before use, please read through the operating manual.
1.When voltage above 30V, AC power line with inductive load is measured. When AC power line during
electric fluctuation is measured, please be cautious of electric shock.
2.Before measuring, check if the measurement function switch is at correct position. Check test leads for
reliable contact, correct connection and good insulation to avoid electric shock.
3.Clamp meter only meets safety standard when used with its supporting test leads. When test lead line is
damaged, please replace with lead line of the same model or the same electric specification.
4.Do not replace the battery inside with other non-confirmed or non-recognized one. Use battery of the
same model or electric specification only. Before replacing, the test lead must be away from the
measurement point and make sure the input end has no signal.
5.When do electrical measurements, human body should have no direct contact with earth. Do not touch
any metal terminal, output terminal or lead clamp which have exposed ground potential.
6.Do not store or use it in high temperature, high humidity, inflammable, explosive environment or high
magnetic field.
+ digital clamp meter
and warning words". It means cases or behavior which may pose
