Summary of Contents for Data Video PD-2A
- Page 1 POWER CENTER PD-2A Instruction Manual...
-
Page 2: Table Of Contents
Table of Contents ATTENTION: ............................2 AVERTISSEMENT: ............................ 2 DANGER: ..............................2 SAFETY INSTRUCTIONS - RACK MOUNT ....................3 FCC COMPLIANCE STATEMENT ........................ 4 WARNINGS AND PRECAUTIONS ......................4 WARRANTY ............................5 ............................5 TANDARD ARRANTY ............................5 HREE ARRANTY DISPOSAL ............................... -
Page 3: Attention
ATTENTION: 1. Débranchez l'appareil de la prise secteur murale avant de le nettoyer . Ne pas utiliser de nettoyants liquides ou en aérosol. Utilisez un chiffon humide pour le nettoyage. 2. Ne pas utiliser cet appareil dans l'eau ou près de l’eau. 3. -
Page 4: Safety Instructions - Rack Mount
ou une surface similaire, car les ouvertures de ventilation sur le fond du boitier seront bloquées. Cette unité ne doit jamais être placée à proximité ou sur une source de chaleur ou un radiateur. Cet appareil ne doit pas être placé dans une installation intégrée à moins qu'une ventilation adéquate ne soit prévue. -
Page 5: Fcc Compliance Statement
pièce . Par conséquent , il faut envisager d'installer l'équipement dans un environnement compatible avec la température ambiante maximale ( Tam), spécifiée par le fabricant . B ) Débit d'air réduit – L’installation de l'équipement dans un rack doit être telle que la quantité de flux d'air nécessaire au bon fonctionnement de l'équipement ne soit pas compromise. -
Page 6: Warranty
12. Except as specifically explained elsewhere in this manual, do not attempt to service this product yourself. Opening or removing covers that are marked “Do Not Remove” may expose you to dangerous voltage points or other risks, and will void your warranty. Refer all service issues to qualified service personnel. -
Page 7: Disposal
Disposal For EU Customers only - WEEE Marking This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. -
Page 8: Features
Three cooling fans Input Select On / Off Switch Powers the PD-2A On / Off when using AC Power. Note: The On / Off Switch is not functional if the power input is DC. AC In with built-in fuse AC Inlet for connecting to suitable mains power outlet – 100-240VAC. The socket... - Page 9 DC the PD-2A will not regulate the power outlets. Please ensure that the 12V power source that you use is regulated. If you intend to run the PD-2A from a car or van power outlet, please make sure a suitable regulator is used on the power feed.
-
Page 10: Rear Panel
Datavideo Product Voltage Requirements This table is a guideline for Datavideo products, if you are using products from other manufacturers please check their voltage requirements carefully before connecting to the PD-2A. DC 12V 3A SE-500 / SE-600 / SE-2000 / DVK-300HD / ITC-100 / AM-100... -
Page 11: Specification
Specification Input AC input outlet One AC input AC input voltage 100 - 240VAC AC input current rating 100 – 240VAC MAX 6.3A AC frequency 50Hz or 60Hz DC input One DC 12V, supports non-regulated DC 12V output DC input watt 400W Output DC Output... -
Page 12: Service & Support
Tel: +65-6749 6866 Fax:+65-6749 3266 Fax:+33-1-60376732 Tel: +86 531-8607 8813 E-mail:info@datavideovirtualset.com E-mail:service@datavideo.cn E-mail:info@datavideo.fr Please visit our website for latest manual update. www.datavideo.com/product/PD-2A All the trademarks are the properties of their respective owners. Datavideo Technologies Co., Ltd. All rights reserved 2018 Jul-18.2017...
