CSE Universe FRN0.75F1?-2J Instruction Manual

Frenic-eco
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Designed for Fan and Pump Applications
Thank you for purchasing our FRENIC-Eco series of inverters.
• This product is designed to drive a three-phase induction motor. Read through this instruction manual and
be familiar with the handling procedure for correct use.
• Improper handling might result in incorrect operation, a short life, or even a failure of this product as well as
the motor.
• Deliver this manual to the end user of this product. Keep this manual in a safe place until this product is
discarded.
• For how to use an optional device, refer to the installation and instruction manuals for that optional device.
Fuji Electric Co., Ltd.
Instruction Manual
INR-SI47-0882b-E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRN0.75F1?-2J and is the answer not in the manual?

Questions and answers

Summary of Contents for CSE Universe FRN0.75F1?-2J

  • Page 1 Instruction Manual Designed for Fan and Pump Applications Thank you for purchasing our FRENIC-Eco series of inverters. • This product is designed to drive a three-phase induction motor. Read through this instruction manual and be familiar with the handling procedure for correct use. •...
  • Page 2 Copyright © 2004-2011 Fuji Electric Co., Ltd. All rights reserved. No part of this publication may be reproduced or copied without prior written permission from Fuji Electric Co., Ltd. All products and company names mentioned in this manual are trademarks or registered trademarks of their respective holders.

  • Page 3: Preface

    Preface Thank you for purchasing our FRENIC-Eco series of inverters. This product is designed to drive a three-phase induction motor for fan and pump applications. Read through this instruction manual and be familiar with proper handling and operation of this product. Improper handling might result in incorrect operation, a short life, or even a failure of this product as well as the motor.
  • Page 4 Application • FRENIC-Eco is designed to drive a three-phase induction motor. Do not use it for single-phase motors or for other purposes. Fire or an accident could occur. • FRENIC-Eco may not be used for a life-support system or other purposes directly related to the human safety.
  • Page 5 Wiring • When wiring the inverter to the power source, insert a recommended molded case circuit breaker (MCCB) or residual-current-operated protective device (RCD)/earth leakage circuit breaker (ELCB) (with overcurrent protection) in the path of power lines. Use the devices within the recommended current range.
  • Page 6 Operation • Be sure to install the terminal block cover and the front cover before turning the power ON. Do not remove the covers while power is applied. Otherwise electric shock could occur. • Do not operate switches with wet hands. Doing so could cause electric shock.

  • Page 7: General Precautions

    • Do not turn the main circuit power (circuit breaker) ON or OFF in order to start or stop inverter operation. Doing so could cause failure. • Do not touch the heat sink because they become very hot. Doing so could cause burns. •...
  • Page 8 Conformity with Low Voltage Directive in the EU If installed according to the guidelines given below, inverters marked with CE can be considered to be compliant with the Low Voltage Directive 73/23/EEC. 1. Be sure to earth the grounding terminal zG. Use an earth wire sized more than that of the power wires used in the power dispatch system.
  • Page 9 Conformity with Low Voltage Directive in the EU (continued) 8. Use the wires listed in EN60204 Appendix C. Recommended wire size (mm MCCB or Main power Control circuit RCD/ELCB input Rated current [L1/R, L2/S, L3/T] Inverter type Inverter’s Europe Screw grounding [zG] type terminal...
  • Page 10 Conformity with UL standards and CSA standards (cUL-listed for Canada) UL/cUL-listed inverters are subject to the regulations set forth by the UL standards and CSA standards (cUL-listed for Canada) by installation within precautions listed below. Integral solid state short circuit protection does not provide branch circuit protection. Branch circuit protection must be provided in accordance with the National Electrical Code and any additional local codes.
  • Page 11 Conformity with UL standards and CSA standards (cUL-listed for Canada) (continued) 7. Install UL-listed fuses or circuit breaker between the power supply and the inverter, referring to the table below. Required torque Wire size Ib-in (N·m) AWG (mm Aux. Control circuit Aux.

  • Page 12: Precautions For Use

    Precautions for use When driving a 400V general-purpose motor with an inverter using Driving a 400V extremely long wires, damage to the insulation of the motor may occur. general-purpose Use an output circuit filter (OFL) if necessary after checking with the motor motor manufacturer.
  • Page 13 Install a recommended molded case circuit breaker (MCCB) or Installing an residual-current-operated protective device (RCD)/earth leakage circuit MCCB or breaker (ELCB) (with overcurrent protection) in the primary circuit of the RCD/ELCB inverter to protect the wiring. Ensure that the circuit breaker rated current is equivalent to or lower than the recommended rated current.
  • Page 14 Select an inverter according to the applicable motor ratings listed in the standard specifications table for the inverter. Driving general-purpose When high starting torque is required or quick acceleration or deceleration Selecting motor is required, select an inverter with a capacity one size greater than the inverter standard.

  • Page 15: How This Manual Is Organized

    How this manual is organized This manual is made up of chapters 1 through 10. Chapter 1 BEFORE USING THE INVERTER This chapter describes acceptance inspection and precautions for transportation and storage of the inverter. Chapter 2 MOUNTING AND WIRING OF THE INVERTER This chapter provides operating environment, precautions for installing the inverter, wiring instructions for the motor and inverter.

  • Page 16: Table Of Contents

    Table of Contents Preface ..............i Chapter 5 FUNCTION CODES ........5-1 Safety precautions..............i 5.1 Function Code Tables ..........5-1 Precautions for use ............x 5.2 Overview of Function Codes........ 5-19 How this manual is organized ..........xiii Chapter 6 TROUBLESHOOTING ........6-1 Chapter 1 BEFORE USING THE INVERTER ....

  • Page 17: Chapter 1 Before Using The Inverter

    Chapter 1 BEFORE USING THE INVERTER 1.1 Acceptance Inspection Unpack the package and check the following: (1) An inverter and accessories below are contained in the package. • Cooling fan fixing screws (for inverters of 7.5 to 30 kW) • Keypad fixing screws (for inverters of 0.75 to 30 kW) •...

  • Page 18: External View And Terminal Blocks

    1.2 External View and Terminal Blocks (1) Outside and inside views (a) FRN15F1S-2J (b) FRN37F1S-2J (c) FRN220F1S-4J Figure 1.2 Outside and Inside Views of Inverters...
  • Page 19 (2) Warning plates and label Warning Plate Warning Plate Warning Label (a) FRN15F1S-2J (b) FRN37F1S-2J Figure 1.3 Warning Plates and Label (3) Terminal block location (a) FRN15F1S-2J (b) FRN37F1S-2J (c) FRN220F1S-4J Figure 1.4 Terminal Blocks and Keypad Enclosure Location...

  • Page 20: Transportation

    1.3 Transportation • When carrying an inverter, always support its bottom at the front and rear sides with both hands. Do not hold covers or individual parts only. You may drop the inverter or break it. • When hoisting an inverter with hoisting holes, hook or rope the 4 holes evenly. 1.4 Storage Environment 1.4.1 Temporary storage Store the inverter in an environment that satisfies the requirements listed in Table 1.1.

  • Page 21: Operating Environment

    Chapter 2 MOUNTING AND WIRING OF THE INVERTER 2.1 Operating Environment Install the inverter in an environment that satisfies the requirements listed in Table 2.1. Table 2.1 Environmental Requirements Table 2.2 Output Current Derating Factor in Relation to Altitude Item Specifications Output current Altitude...
  • Page 22 When mounting two or more inverters Horizontal layout is recommended when two or more inverters are to be installed in the same unit or enclosure. If it is necessary to mount the inverters vertically, install a partition plate or the like between the inverters so that any heat radiating from an inverter will not affect the one/s above.
  • Page 23 To utilize external cooling for inverters with a capacity of 37 kW or above, change the position of the top and bottom mounting bases from the edge to the center of the inverter as illustrated in Figure 2.3. Screws differ in size, length and count for each inverter. Be sure to refer to the table below. Table 2.3 Screw Count and Tightening Torque Power Base fixing screw...
  • Page 24 Figure A Figure B Figure 2.3 Relocating the Top and Bottom Mounting Bases When moving the top and bottom mounting bases, use only the specified screws. A fire or an accident may be caused.
  • Page 25 (3) Mounting direction Mount the inverter vertically to the mounting surface and fix it securely with four screws or bolts so that the logo "FRENIC-Eco" can be seen from the front. Do not mount the inverter upside down or horizontally. Doing so will reduce the heat dissipation efficiency of the inverter and cause the overheat protection function to operate, so the inverter will not run.

  • Page 26: Wiring

    Fixing the keypad (for models of 30 kW or below) Remove the terminal block (TB) cover and the front cover. (For the procedure, refer to Section 2.3.1 “Removing and mounting the terminal block (TB) cover and the front cover.”) To fix the front cover and keypad, hold the front cover and the keypad together and tighten the two attached screws (provided as accessories) from the back of the keypad.
  • Page 27 Mounting the covers Put the front cover to the inverter case while fitting the edge of the front cover between the both hinges provided on the inverter case. Slide it upward until the front cover latches. Fit the latches on the terminal block (TB) cover in the holes provided to the front cover and push it towards the inverter case.
  • Page 28 (2) For inverters with a capacity of 37 kW to 160 kW Removing and mounting the covers To remove the front cover, loosen the four fastening screws on it, hold it with both hands, and slide it upward. (Refer to Figure 2.8.) Put the front cover back in reverse order of the .
  • Page 29 (3) For inverters with a capacity of 200 kW to 220 kW Removing and mounting the covers To remove the lower front cover, loosen the five fastening screws on it, and hold it with both hands, and then slide it upward. You can do wiring works just removing the lower front cover.

  • Page 30: Removing And Mounting The Cable Guide Plate (For Models Of 0.75 Kw To 22 Kw)

    2.3.2 Removing and mounting the cable guide plate (for models of 0.75 kW to 22 kW) For inverters of 22 kW or below use the cable guide plate to secure IP20 protective structure. Follow the steps to work on it. Removing the cable guide plate Before to proceed, remove the terminal block cover in advance.

  • Page 31: Terminal Arrangement Diagram And Screw Specifications

    2.3.3 Terminal arrangement diagram and screw specifications The table below shows the main circuit screw sizes, tightening torque and terminal arrangements. Note that the terminal arrangements differ according to the inverter types. Two terminals designed for grounding shown as the symbol, in Figures A to J make no distinction between a power supply source (a primary circuit) and a motor (a secondary circuit).
  • Page 32 (2) The control circuit terminals (common to all models) Screw size: M3 Tightening torque: 0.7 (N·m) 2-12...

  • Page 33: Recommended Wire Sizes

    2.3.4 Recommended wire sizes Table 2.7 lists the recommended wire sizes. The recommended wire sizes for the main circuits are examples of using HIV single wire (for 75°C) at an ambient temperature of 50°C. Table 2.7 Recommended Wire Sizes Recommended wire size (mm ) *1 Main circuit Nominal...

  • Page 34: Wiring Precautions

    2.3.5 Wiring precautions Follow the rules below when performing wiring for the inverter. (1) Make sure that the source voltage is within the rated voltage range specified on the nameplate. (2) Be sure to connect the three-phase power wires to the main circuit power input terminals L1/R, L2/S and L3/T of the inverter.
  • Page 35 Follow the procedure below for wiring and configuration of the inverter. Figure 2.12 illustrates the wiring procedure with peripheral equipment. Wiring procedure Grounding terminals ( G) Inverter output terminals (U, V, W, and DC reactor connection terminals (P1 and P(+)) * Switching connectors * (For the models of 200 V series 45 kW or above, for 400 V series 55 kW or above.
  • Page 36 Grounding terminals ( G) Be sure to ground either of the two grounding terminals for safety and noise reduction. The inverter is designed to use with a safety grounding to avoid electric shock, fire and other disasters. Grounding terminals should be grounded as follows: 1) Ground the inverter in compliance with the national or local electric code.
  • Page 37 Driving 400 V series motor • If a thermal relay is installed in the path between the inverter and the motor to protect the motor from overheating, the thermal relay may malfunction even with a wiring length shorter than 50 m. In this situation, add an output circuit filter (option) or lower the carrier frequency (Function code F26).
  • Page 38 Fan power supply switching connectors (CN R) and (CN W) (for models of 45 kW or above (200 V series) or 55 kW or above (400 V series)) The standard FRENIC-Eco series of inverters also accept DC-linked power input in combination with a power regenerative PWM converter (RHC series).
  • Page 39 Setting up the jumpers for the connectors (CN UX), (CN R) and (CN W) These switching connectors are located on the power printed circuit board (power PCB) mounted at the right hand side of the control printed circuit board (control PCB) as shown below. Switching Connectors for Power Input (CN UX)
  • Page 40 Figure 2.16 shown below illustrates how the configuration jumpers of the connectors (CN UX), (CN R) and (CN W) are setup by factory defaults, and to change their settings for a new power configuration. Setting up the power switching connector (CN UX) (for the models of 400 V series 55 kW or above) (CN UX) (CN UX)
  • Page 41 DC link bus terminals, P (+) and N (-) These are provided for the DC link bus powered system. Connect these terminals with terminals P(+) and N (-) of other inverters. Consult your Fuji Electric representative if these terminals are to be used. Main circuit power input terminals, L1/R, L2/S, and L3/T (three-phase input) 1) For safety, make sure that the molded case circuit breaker (MCCB) or magnetic contactor (MC) is turned off before wiring the main circuit power input terminals.

  • Page 42: Wiring For Control Circuit Terminals

    2.3.7 Wiring for control circuit terminals In general, sheaths and covers of the control signal cables and wires are not specifically designed to withstand a high electric field (i.e., reinforced insulation is not applied). Therefore, if a control signal cable or wire comes into direct contact with a live conductor of the main circuit, the insulation of the sheath or the cover might break down, which would expose the signal wire to a high voltage of the main circuit.
  • Page 43 Table 2.10 Symbols, Names and Functions of the Control Circuit Terminals Symbol Name Functions [13] Potenti- Power supply (+10 VDC) for the potentiometer that gives the frequency command ometer (Potentiometer: 1 to 5kΩ) power Allowable output current: 10 mA supply [12] Voltage (1) The frequency is commanded according to the external analog input voltage.
  • Page 44 Table 2.10 Continued Symbol Name Functions - Since low level analog signals are handled, these signals are especially susceptible to the external noise effects. Route the wiring as short as possible (within 20 m) and use shielded wires. In principle, ground the shielded sheath of wires; if effects of external inductive noises are considerable, connection to terminal [11] may be effective.
  • Page 45 Table 2.10 Continued Symbol Name Functions [X1] Digital (1) The various signals such as coast-to-stop, alarm from external equipment, and input 1 multistep frequency commands can be assigned to terminals [X1] to [X5], [FWD] and [REV] by setting function codes E01 to E05, E98, and E99. For details, refer to [X2] Digital Chapter 5, Section 5.2 "Overview of Function Codes."...
  • Page 46 Table 2.10 Continued Symbol Name Functions Using a relay contact to turn [X1], [X2], [X3], [X4], [X5], [FWD], or [REV] ON or OFF Figure 2.21 shows two examples of a circuit that uses a relay contact to turn control signal input [X1], [X2], [X3], [X4], [X5], [FWD], or [REV] ON or OFF.
  • Page 47 Table 2.10 Continued Symbol Name Functions The monitor signal for analog DC voltage (0 to +10 V) or analog DC current (+4 to +20 [FMA] Analog mA) is output. You can select either one of the output switching the slide switch SW4 on monitor the control PCB (Refer to Section 2.3.8.), and changing data of the function code F29.
  • Page 48 Table 2.10 Continued Symbol Name Functions [Y1] Transistor (1) Various signals such as inverter running, speed/freq. arrival and overload early output 1 warning can be assigned to any terminals, [Y1] to [Y3] by setting function code E20, E21 and E22. Refer to Chapter 5, Section 5.2 "Overview of Function Codes" for details.
  • Page 49 Table 2.10 Continued Symbol Name Functions [Y5A/C] General (1) A general-purpose relay contact output usable as well as the function of the purpose transistor output terminal [Y1], [Y2] or [Y3]. Contact rating: 250 VAC 0.3 A, cos φ = 0.3, 48 VDC, 0.5 A relay output (2) Switching of the normal/negative logic output is applicable to the following two contact output modes: "Active ON"...
  • Page 50 Wiring control circuit terminals For models of FRN132F1S-4J to FRN220F1S-4J Route the control circuit cable in keeping with the left side panel of the inverter as shown in Figure 2.26. Fasten the control circuit cable to the cable tie support with a cable tie (insulation lock) as shown in Figure 2.26.

  • Page 51: Setting Up Slide Switches And Handling Control Circuit Terminal Symbol Plate

    2.3.8 Setting up slide switches and handling control circuit terminal symbol plate Before changing the switches or touching the control circuit terminal symbol plate, turn OFF the power and wait more than five minutes for models of 30 kW or below, or ten minutes for models of 37 kW or above. Make sure that the LED monitor and charging lamp (on models of 37 kW or above) are turned OFF.
  • Page 52 Opening and closing the control circuit terminal symbol plate The symbolic names of the control circuit terminals are marked on the control circuit terminal symbol plate provided on the top of the terminal block. The plate can be opened or closed as necessary. Follow the procedures illustrated below to open or close the plate.

  • Page 53: Mounting And Connecting A Keypad

    Figure 2.29 shows the location of slide switches for the input/output terminal configuration. Switching example SINK SOURCE RS485 comm. port terminator Figure 2.29 Location of the Slide Switches 2.4 Mounting and Connecting a Keypad 2.4.1 Mounting style and parts needed for connection (1) Mounting style You can mount a keypad in any style described below.

  • Page 54: Mounting/Installing Steps

    (2) Parts needed for connection To mount/install a keypad on a place other than an inverter, parts listed below are needed. Parts name Model Remarks 3 cables available in length of 5m, 3m, and 1m. Extension cable (Note 1) CB-5S, CB-3S and CB-1S M3 ×...
  • Page 55 Make a cut-out on the enclosure wall. For details, refer to Chapter 8, Section 8.5.3 “Keypad.” To mount the keypad on the enclosure wall, fix it firmly using a pair of M3 screws put through the taps shown below. (Figure 2.34.) (Tightening torque: 0.7N･m) Figure 2.34 Mounting a Keypad on the Enclosure Wall Connect an extension cable (CB-5S, CB-3S or CB-1S) or off-the-shelf straight LAN cable to RJ-45...

  • Page 56: Cautions Relating To Harmonic Component, Noise, And Leakage Current

    2.5 Cautions Relating to Harmonic Component, Noise, and Leakage Current (1) Harmonic component Input current to an inverter includes a harmonic component, which may affect other loads and power factor correcting capacitors that are connected to the same power source as the inverter. If the harmonic component causes any problems, connect a DC reactor (option) to the inverter.

  • Page 57: Chapter 3 Operation Using The Keypad

    Chapter 3 OPERATION USING THE KEYPAD 3.1 LED Monitor, Keys and LED Indicators on the Keypad 7-segment As shown at the right, the keypad consists of LED monitor a four-digit LED monitor, six keys, and five LED indicators. indicators The keypad allows you to run and stop the motor, monitor running status, and switch to the menu mode.

  • Page 58: Overview Of Operation Modes

    Simultaneous keying Simultaneous keying means pressing two keys at the same time. The FRENIC-Eco supports simultaneous keying as listed below. The simultaneous keying operation is expressed by a "+" letter between the keys throughout this manual. (For example, the expression " keys"...
  • Page 59 (*1) In speed monitor, you can have any of the following displayed according to the setting of function code E48: Output frequency (Hz), Motor speed (r/min), Load shaft speed (r/min), and Speed (%). (*2) Applicable only when PID control is active. (J01 = 1 or 2) (*3) Applicable only when the analog signal input monitor is assigned to any terminals [12], [C1], or [V2] by E61, E62 or E63 (= 20).

  • Page 60: Running Mode

    3.3 Running Mode When the inverter is turned on, it automatically enters Running mode. In this mode, you can: (1) Monitor the running status (e.g., output frequency, output current), (2) Set up the frequency command and others, and (3) Run/stop the motor. 3.3.1 Monitoring the running status In Running mode, the eleven items listed below can be monitored.

  • Page 61: Setting Up Frequency And Pid Process Commands

    3.3.2 Setting up frequency and PID process commands You can set up the desired frequency and PID process commands by using the keys on the keypad. It is also possible to set up the frequency command as load shaft speed, motor speed or speed (%) by setting function code E48.
  • Page 62 Make setting under PID control To enable PID control, you need to set function code J01 to 1 or 2. Under the PID control, the items that can be set or checked with the keys are different from those under regular frequency control, depending upon the current LED monitor setting. If the LED monitor is set to the speed monitor (E43 = 0), you can access manual speed commands (Frequency command) with the keys;...
  • Page 63 Setting up the frequency command with the keys under PID control When function code F01 is set to "0: Enable keys on keypad" and frequency command 1 is selected as a manual speed command (that is, disabling the frequency setting command via communications link and multistep frequency command), switching the LED monitor to the speed monitor in Running mode enables you to modify the frequency command with the keys.

  • Page 64: Running/Stopping The Motor

    3.3.3 Running/stopping the motor By factory default, pressing the key starts running the motor in the forward direction and pressing the key decelerates the motor to stop. The key is enabled only in Running mode. The motor rotational direction can be selected by changing the setting of function code F02.
  • Page 65 Remote and local modes The inverter can be operated either in remote or local mode. In remote mode that applies to ordinary operation, the inverter is driven under the control of the data settings stored in the inverter, whereas in local mode that applies to maintenance operation, it is separated from the control system and is driven manually under the control of the keypad.

  • Page 66: Programming Mode

    3.4 Programming Mode The Programming mode provides you with these functions--setting and checking function code data, monitoring maintenance information and checking input/output (I/O) signal status. The functions can be easily selected with the menu-driven system. Table 3.8 lists menus available in Programming mode. The leftmost digit (numerals) of each letter string on the LED monitor indicates the corresponding menu number and the remaining three digits indicate the menu contents.
  • Page 67 Figure 3.3 illustrates the menu-driven function code system in Programming mode. Figure 3.3 Menu Transition in the Programming Mode Limiting menus to be displayed The menu-driven system has a limiter function (specified by function code E52) that limits menus to be displayed for the purpose of simple operation.

  • Page 68: Setting Up Basic Function Codes Quickly - Menu #0 "Quick Setup

    3.4.1 Setting up basic function codes quickly – Menu #0 "Quick Setup" Menu #0 "Quick Setup" in Programming mode allows you to quickly display and set up a basic set of function codes specified in Chapter 5, Section 5.1, "Function Code Tables." To use Menu #0 "Quick Setup,"...
  • Page 69 Figure 3.4 shows the menu transition in Menu #1 "Quick Setup." Figure 3.4 Menu Transition in Menu #0 "Quick Setup" Through a multi-function keypad, you can add or delete function codes that are subject to Quick Setup. For details, refer to the "Multi-function Keypad Instruction Manual" (INR-SI47-0890-E). Once you have added or deleted function codes for Quick Setup through a multi-function keypad, they will remain valid even after you switch to a standard keypad.

  • Page 70: Setting Up Function Codes - Menu #1 "Data Setting

    Basic key operation This section gives a description of the basic key operation, following the example of the function code data changing procedure shown in Figure 3.5. This example shows you how to change function code F01 data from the factory default "0: Enable keys on keypad"...
  • Page 71 Figure 3.6 shows the menu transition in Menu #1 "Data Setting." Figure 3.6 Menu Transition in Menu #1 "Data Setting" Basic key operation For details of the basic key operation, refer to Menu #0 "Quick Setup" in Section 3.4.1. 3-15...

  • Page 72: Checking Changed Function Codes - Menu #2 "Data Checking

    3.4.3 Checking changed function codes – Menu #2 "Data Checking" Menu #2 "Data Checking" in Programming mode allows you to check function codes that have been changed. Only the function codes whose data has been changed from the factory defaults are displayed on the LED monitor. You can refer to the function code data and change it again if necessary.

  • Page 73: Monitoring The Running Status - Menu #3 "Drive Monitoring

    3.4.4 Monitoring the running status – Menu #3 "Drive Monitoring" Menu #3 "Drive Monitoring" is used to monitor the running status during maintenance and trial running. The display items for "Drive Monitoring" are listed in Table 3.11. Figure 3.8 shows the menu transition in Menu #3 "Drive Monitoring."...
  • Page 74 Table 3.11 Drive Monitor Display Items monitor Item Unit Description shows: Output frequency Output frequency 3_00 Output current Output current 3_02 Output voltage Output voltage 3_03 Calculated Calculated output torque of the loaded motor in % 3_04 torque Reference Frequency specified by a frequency command 3_05 frequency Rotational...
  • Page 75 Displaying running status To display the running status in hexadecimal format, each state has been assigned to bits 0 to 15 as listed in Table 3.12. Table 3.13 shows the relationship between each of the status assignments and the LED monitor display. Table 3.14 gives the conversion table from 4-bit binary to hexadecimal.

  • Page 76: Checking I/O Signal Status - Menu #4 "I/O Checking

    3.4.5 Checking I/O signal status – Menu #4 "I/O Checking" Using Menu #4 "I/O Checking" displays the I/O status of external signals including digital and analog I/O signals without using a measuring instrument. Table 3.15 lists check items available. The menu transition in Menu #4 "I/O Checking"...
  • Page 77 Basic key operation To check the status of the I/O signals, set function code E52 to "2: Full-menu mode" beforehand. (1) Turn the inverter on. It automatically enters Running mode. In that mode, press the key to switch to Programming mode. The function selection menu appears. $i_o (2) Use the keys to display "I/O Checking"...
  • Page 78 Displaying control I/O signal terminals The status of control I/O signal terminal may be displayed with ON/OFF of the LED segment or in hexadecimal display. • Display I/O signal status with ON/OFF of each LED segment As shown in Table 3.16 and the figure below, each of segments "a" to "g" on LED1 lights when the corresponding (*1) digital input terminal circuit ([FWD], [REV], [X1], [X2], [X3], [X4] or [X5]) is closed;...
  • Page 79 • Displaying I/O signal status in hexadecimal format Each I/O terminal is assigned to bit 15 through bit 0 as shown in Table 3.17. An unassigned bit is interpreted as "0." Allocated bit data is displayed on the LED monitor in 4 hexadecimal digits ( each).

  • Page 80: Reading Maintenance Information - Menu #5 "Maintenance Information

    3.4.6 Reading maintenance information – Menu #5 "Maintenance Information" Menu #5 "Maintenance Information" contains information necessary for performing maintenance on the inverter. Table 3.18 lists the maintenance information display items and Figure 3.10 shows the menu transition in Menu #5 "Maintenance information."...
  • Page 81 Table 3.18 Display Items for Maintenance Information LED Monitor Item Description shows: Cumulative run Shows the content of the cumulative power-ON time counter of the inverter. time Unit: thousands of hours. (Display range: 0.001 to 9.999, 10.00 to 65.53) 5_00 When the total ON-time is less than 10000 hours (display: 0.001 to 9.999), data is shown in units of one hour (0.001).
  • Page 82 Table 3.18 Continued LED Monitor Item Description shows: No. of RS485 Shows the total number of errors that have occurred in standard RS485 commu- errors (stan- nication (via the RJ-45 connector as standard) since the power is turned on. 5_11 dard) Once the number of errors exceeds 9999, the count returns to 0.

  • Page 83: Reading Alarm Information - Menu #6 "Alarm Information

    3.4.7 Reading alarm information – Menu #6 "Alarm Information" Menu #6 "Alarm Information" shows the causes of the past 4 alarms in alarm code. Further, it is also possible to display alarm information that indicates the status of the inverter when the alarm occurred. Figure 3.11 shows the menu transition in Menu #6 "Alarm Information"...
  • Page 84 Basic key operation To view the alarm information, set function code E52 to "2: Full-menu mode" beforehand. (1) Turn the inverter on. It automatically enters Running mode. In that mode, press the key to switch to Programming mode. The function selection menu appears. &al (2) Use the keys to display "Alarm Information"...

  • Page 85: Data Copying Information - Menu #7 "Data Copying

    Table 3.19 Continued LED monitor shows: Item displayed Description (item No.) Terminal I/O signal status (displayed with the 6_12 ON/OFF of LED seg- ments) Shows the ON/OFF status of the digital I/O terminals. Refer to Terminal input signal " Displaying control I/O signal terminals" in Section 3.4.5 "Checking 6_13 status (in hexadecimal I/O signal status "...
  • Page 86 (2) If cper is blinking, any of the following problems has arisen: • The function codes stored in the keypad and ones registered in the inverter are not compatible with each other. (Either of the two may have been revised or upgraded in a non-standard or incompatible manner. Contact your Fuji Electric representative.) Figure 3.12 shows the menu transition in Menu #7 "Data Copying."...
  • Page 87 Data protection You can protect data saved in the keypad from unexpected modifications. Enabling the data protection that was read proT disabled changes the display on the Data copying function list to , and disables to read data from the inverter.

  • Page 88: Alarm Mode

    Table 3.20 List of Data Copying Functions Display on Function Description LED Monitor read Read data Reads the function code data out of the inverter’s memory and stores it into the keypad memory. Pressing the key during a read operation ( read blinking) immediately aborts the operation and displays...
  • Page 89 Displaying the status of inverter at the time of alarm When the alarm code is displayed, you may check various running status information (output frequency and output current, etc.) by pressing the key. The item number and data for each running information will be displayed alternately.

  • Page 90: Chapter 4 Running The Motor

    Chapter 4 RUNNING THE MOTOR 4.1 Running the Motor for a Test 4.1.1 Inspection and preparation prior to powering on Check the following prior to starting powering on. (1) Check if connection is correct. Especially check if the power wires are connected to the inverter input terminals L1/R, L2/S and L3/T, and output terminals U, V and W respectively and that the grounding wires are connected to the ground electrodes correctly.

  • Page 91: Tuning Procedure

    Table 4.1 Settings of Function Code Data before Driving the Motor for a Test Function code Name Function code data Factory setting f 04 Base frequency 60.0 (Hz) 0 (V) Rated voltage f 05 (Output voltage interlocked with the (at base frequency) input voltage) Motor ratings (printed on the Motor parameter...

  • Page 92: Errors During Tuning

    3) Preparation of Machine System Perform appropriate preparations on the motor and its load, such as disengaging the coupling and deactivating the safety device. 4) Perform tuning Set function code P04 to "1" or "2" and press the key. (The blinking of on the LED monitor will slow down.) Enter a Run command for the rotation direction you have chosen.

  • Page 93: Test Run

    4.1.4 Test run If the user set the function codes wrongly or without completely understanding this Instruction Manual and the FRENIC-Eco User's Manual (MEH456), the motor may rotate with a torque or at a speed not permitted for the machine. Accident or injury may result.

  • Page 94: Chapter 5 Function Codes

    Chapter 5 FUNCTION CODES 5.1 Function Code Tables Function codes enable the FRENIC-Eco series of inverters to be set up to match your system requirements. Each function code consists of a 3-letter alphanumeric string. The first letter is an alphabet that identifies its group and the following two letters are numerals that identify each individual code in the group.
  • Page 95 Using negative logic for programmable I/O terminals The negative logic signaling system can be used for the digital input and output terminals by setting the function code data specifying the properties for those terminals. Negative logic refers to the inverted ON/OFF (logical value 1 (true)/0 (false)) state of input or output signal.
  • Page 96 F codes: Fundamental Functions The shaded function codes ( ) are applicable to the quick setup. Torque boost per motor capacity by factory defaults (F09) Motor rating (kW) Torque boost (%) Motor rating (kW) Torque boost (%) 0.75 18.5 30 to 220...
  • Page 97 (F code continued) The shaded function codes ( ) are applicable to the quick setup. When you make settings from the keypad, the incremental unit is restricted by the number of digits that the LED monitor can display. (Example) If the setting range is from -200.00 to 200.00, the incremental unit is: "1"...
  • Page 98 (F code continued)
  • Page 99 E codes: Extension Terminal Functions...
  • Page 100 (E code continued)
  • Page 101 (E code continued) The shaded function codes ( ) are applicable to the quick setup. When you make settings from the keypad, the incremental unit is restricted by the number of digits that the LED monitor can display. (Example) If the setting range is from -200.00 to 200.00, the incremental unit is: "1"...
  • Page 102 (E code continued) When you make settings from the keypad, the incremental unit is restricted by the number of digits that the LED monitor can display. (Example) If the setting range is from -200.00 to 200.00, the incremental unit is: "1"...
  • Page 103 (E code continued) 5-10...
  • Page 104 C codes: Control Functions of Frequency When you make settings from the keypad, the incremental unit is restricted by the number of digits that the LED monitor can display. (Example) If the setting range is from -200.00 to 200.00, the incremental unit is: "1"...
  • Page 105 P codes: Motor Parameters The shaded function codes ( ) are applicable to the quick setup. 5-12...
  • Page 106 H codes: High Performance Functions 5-13...
  • Page 107 (H code continued) 5-14...
  • Page 108 (H code continued) When you make settings from the keypad, the incremental unit is restricted by the number of digits that the LED monitor can display. (Example) If the setting range is from -200.00 to 200.00, the incremental unit is: "1"...
  • Page 109 J codes: Application Functions When you make settings from the keypad, the incremental unit is restricted by the number of digits that the LED monitor can display. (Example) If the setting range is from -200.00 to 200.00, the incremental unit is: "1"...
  • Page 110 y codes: Link Functions 5-17...
  • Page 111 (y code continued) 5-18...

  • Page 112: Overview Of Function Codes

    5.2 Overview of Function Codes This section provides an overview of the function codes frequently used for the FRENIC-Eco series of inverter. For details of the function codes given below and other function codes not given below, refer to the FRENIC-Eco User’s Manual (MEH456), Chapter 9 "FUNCTION CODES."...
  • Page 113 • You can modify the reference frequency anywhere you choose using the gain and bias settings, to these analog inputs (voltages entered via terminals [12] and [V2]; the current entered via terminal [C1]). For details, refer to function code F18. •...
  • Page 114 The table below shows relationship between keying and run commands in running per a keypad (F02 = 0, rotation direction is defined by the digital inputs). Keying on the keypad Digital inputs Results (Final command) (FWD) (REV) Stop － － －...
  • Page 115 Base Frequency (F04) Set the rated frequency printed on the nameplate labeled on the motor. Rated Voltage at Base Frequency (F05) Set 0 or the rated voltage printed on the nameplate labeled on the motor. - If 0 is set, the rated voltage at base frequency is determined by the power source of the inverter. The output voltage will vary in line with any variance in input voltage.
  • Page 116 Example: Normal (linear) V/f pattern V/f Pattern with Non-linear Point below the Base Frequency V/f Pattern with Non-linear Point above the Base Frequency 5-23...
  • Page 117 Acceleration Time 1 Deceleration Time 1 F07 specifies the acceleration time, the length of time the frequency increases from 0 Hz to the maximum frequency. F08 specifies the deceleration time, the length of time the frequency decreases from the maximum frequency down to 0 Hz. •...
  • Page 118 FRENIC-Eco is a series of inverters exclusively designed for fans and pumps whose torque loads are characterized by a term of variable torque load that is a torque load increasing proportional to square of the load speed. FRENIC-Eco cannot drive any linear torque load even if you select a linear V/f pattern.
  • Page 119 Specifying a high torque boost level will generate a high torque, but may cause overcurrent due to over-excitation at no load. If you continue to drive the motor, it may overheat. To avoid such a situation, adjust torque boost to an appropriate level. When the non-linear V/f pattern and the torque boost are used together, the torque boost takes effect below the frequency on the non-linear V/f pattern’s point.
  • Page 120 Electronic Thermal Overload Protection for Motor F10 to F12 (Select motor characteristics, Overload detection level, and Thermal time constant) F10 through F12 specify the thermal characteristics of the motor for its electronic thermal overload protection that is used to detect overload conditions of the motor inside the inverter. F10 selects the motor cooling mechanism to specify its characteristics, F11 specifies the overload detection current, and F12 specifies the thermal time constant.
  • Page 121 Applicable Motor Rating and Characteristic Factors when P99 (Motor selection) = 0 or 4 Switching frequency Output current for Characteristic factor Thermal time Applicable for motor setting the thermal constant τ motor rating characteristic factor time constant (kW) (Factory default) (Imax) α1 α2...
  • Page 122 Example of Operating Characteristics 5-29...
  • Page 123 Restart Mode after Momentary Power Failure (Mode selection) Restart after Momentary Power Failure (Restart time) (Frequency fall rate) (Allowable momentary power failure time) F14 specifies the action to be taken by the inverter such as trip and restart in the event of a momentary power failure.
  • Page 124 Restart mode after momentary power failure (Basic operation) The inverter recognizes a momentary power failure upon detecting the condition that DC link bus voltage goes below the undervoltage level, while the inverter in running. If the load of the motor is light and the duration of the momentary power failure is extremely short, the voltage drop may not be great enough for a momentary power failure to be recognized, and the motor may continue to run uninterrupted.
  • Page 125 When the power is recovered, the inverter will wait 2 seconds for input of a run command. However, if the allowable momentary power failure time (H16) elapses after the power failure was recognized, even within the 2 seconds, the waiting time for a run command is canceled.
  • Page 126 Restart mode after momentary power failure (Allowable momentary power failure time) (H16) H16 specifies the maximum allowable duration (0.0 to 30.0 seconds) from an occurrence of a momentary power failure (undervoltage) until the inverter is to be restarted. Specify the coast-to-stop time during which the machine system and facility can be tolerated.
  • Page 127 Auto-restart after a recovery from momentary power failure (restart time) (H13) This function specifies the time period from momentary power failure occurrence until the inverter reacts for restarting process. If the inverter starts the motor while motor’s residual voltage is still in a high level, a large inrush current may flow or an overvoltage alarm may occur due to an occurrence of temporary regeneration.
  • Page 128 Restart after momentary power failure (Frequency fall rate) (H14) During restart after a momentary power failure, if the inverter output frequency and the motor rotation cannot be harmonized with each other, an overcurrent will flow, activating the overcurrent limiter. If it happens, the inverter reduces the output frequency to match the motor rotation according to the reduction rate (Frequency fall rate: Hz/s) specified by H14.
  • Page 129 F18, C50 Bias, Bias Reference Point (Frequency command 1) C32, C34 Analog Input Adjustment for [12] (Gain, Gain reference point) C37, C39 Analog Input Adjustment for [C1] (Gain, Gain reference point) C42, C44 Analog Input Adjustment for [V2] (Gain, Gain reference point) When any analog input for frequency command 1 (F01) is used, it is possible to define the relationship between the analog input and the reference frequency by multiplying the gain and adding the bias specified by F18.
  • Page 130 (Point A) To set the reference frequency to 0 Hz for an analog input being at 1 V, set the bias to 0% (F18 = 0). Since 1 V is the bias reference point and it is equal to 10% of 10 V, set the bias reference point to 10% (C50 = 10).
  • Page 131 Starting Frequency Stop Frequency At the startup of an inverter, the initial output frequency is equal to the starting frequency. The inverter stops its output at the stop frequency. Set the starting frequency to a level that will enable the motor to generate enough torque for startup.
  • Page 132 Specifying a too low carrier frequency will cause the output current waveform to have a large amount of ripples (many harmonics components). As a result, the motor loss increases, causing the motor temperature to rise. Furthermore, the large amount of ripples tends to cause a current limiting alarm.
  • Page 133 Output adjustment (F30) F30 allows you to adjust the output voltage or current representing the monitored data selected by function code F31 within the range of 0 to 200%. Function (F31) F31 specifies what is output to the analog output terminal [FMA]. Function Meter scale Data for F31...
  • Page 134 Pulse Output [FMP] (Pulse rate) (Duty) (Function) These function codes allow you to output to terminal [FMP] monitored data such as the output frequency and the output current in the form of a variable rate pulse train or a These function codes allow you to output monitored data (such as the output frequency and the output current) to terminal [FMP] in the form of a variable rate pulse train or a fixed rate pulse train.
  • Page 135 E01 to E05 Command Assignment to [X1] to [X5] E98, E99 Command Assignment to [FWD]and [REV] Function codes E01 to E05, E98 and E99 allow you to assign commands to terminals [X1] to [X5], [FWD], and [REV] which are general-purpose, programmable input terminals. These function codes may also switch the logic system between normal and negative to define how the inverter logic interprets either ON or OFF status of each terminal.
  • Page 136 Function code data Terminal commands assigned Symbol Active ON Active OFF 1000 (SS1) 1001 Select multistep frequency (SS2) 1002 (SS4) 1006 Enable 3-wire operation (HLD) 1007 Coast to a stop (BX) 1008 Reset alarm (RST) 1009 Enable external alarm trip (THR) 1011 Switch frequency command 2/1...
  • Page 137 Any negative logic (Active off) command cannot be assigned to the functions marked with "－" in the "Active OFF" column. The "Enable external alarm trip" and "Force to stop" are fail-safe terminal commands. For example, when data = "9" in "Enable external alarm trip," Active OFF (alarm is triggered when OFF);...
  • Page 138 Reset alarm -- (RST) (Function code data = 8) Turning this terminal command ON clears the (ALM) state--alarm output (for any fault). Turning it OFF erases the alarm display and clears the alarm hold state. When you turn the (RST) command ON, keep it ON for 10 ms or more. This command should be kept OFF for the normal inverter operation.
  • Page 139 Enable write from keypad -- (WE-KP) (Function code data = 19) Turning this terminal command OFF disables changing of function code data from the keypad. Only when this command is ON, you can change function code data from the keypad according to the setting of function code F00 as listed below.
  • Page 140 • When the inverter is driven by an external analog frequency command sources (terminals [12], [C1], and [V2]): The "Switch normal/inverse operation" command (IVS) can apply only to the analog frequency command sources (terminals [12], [C1] and [V2]) in frequency command 1 (F01) and does not affect frequency command 2 (C30) or UP/DOWN control.
  • Page 141 Universal DI -- (U-DI) (Function code data = 25) Using (U-DI) enables the inverter to monitor digital signals sent from the peripheral equipment via an RS485 communications link or a field bus option by feeding those signals to the digital input terminals.
  • Page 142 Run forward -- (FWD) (Function code data = 98) Turning this terminal command ON runs the motor in the forward direction; turning it OFF decelerates it to stop. This terminal command can be assigned only by E98 or E99. Run reverse -- (REV) (Function code data = 99) Turning this terminal command ON runs the motor in the reverse direction;...
  • Page 143 The table below lists functions that can be assigned to terminals [Y1], [Y2], [Y3], [Y5A/C], and [30A/B/C]. To make the explanations simpler, the examples shown below are all written for the normal logic (Active ON.) Function code data Functions assigned Symbol Active ON Active OFF...
  • Page 144 Inverter running -- (RUN) (Function code data = 0) This output signal is used to tell the external equipment that the inverter is running at a starting frequency or higher. It comes ON when the output frequency exceeds the starting frequency, and it goes OFF when it is less than the stop frequency.
  • Page 145 Motor overload early warning -- (OL) (Function code data = 7) This output signal is used to issue a motor overload early warning that enables you to take an corrective action before the inverter detects a motor overload alarm and shuts down its output.
  • Page 146 Cooling fan in operation -- (FAN) (Function code data = 25) Under the cooling fan ON/OFF control enabled (H06 = 1), this output signal is ON when the cooling fan is in operation, and OFF when it is stopped. This signal can be used to make the cooling system of peripheral equipment interlocked for an ON/OFF control.
  • Page 147 Inverter output on -- (RUN2) (Function code data = 35) This output signal comes ON when the inverter is running at the starting frequency or below or the DC braking is in operation. Overload prevention control -- (OLP) (Function code data = 36) This output signal comes ON when the overload prevention control is activated.
  • Page 148 Overload Early Warning/Current Detection (Level) Overload Early Warning/Current Detection (Timer) E34 and E35 specify, in conjunction with output terminal signals (OL) and (ID), the level and duration of overload and current beyond which an early warning will be issued. Overload Early Warning The warning signal (OL) is used to detect a symptom of an overload condition (alarm code of the motor so that the user can take an appropriate action before the alarm actually happens.
  • Page 149 Command Loss Detection (Level) When the analog frequency command (by frequency setting through terminals [12], [C1], and [V2]) has dropped below 10% of the expected frequency command within 400 ms, the inverter presumes that the analog frequency command wire has been broken and continues its operation at the frequency determined by the ratio specified by E65 to the reference frequency.
  • Page 150 Detect Low Torque (Detection level) Detect Low Torque (Timer) The signal (U-TL) turns on when the torque calculated by the inverter with reference to its output current has dropped below the level specified by E80 for the time longer than the one specified by E81.
  • Page 151 Motor (Rated current) P03 specifies the rated current of the motor. Enter the rated value shown on the nameplate of the motor Motor (Auto-tuning) This function automatically detects the motor parameters and saves them in the inverter’s internal memory. Basically, you do not need to perform tuning if you use a Fuji standard motor with a standard connection with the inverter.
  • Page 152 Motor Selection Automatic control (such as auto-torque boost and auto-energy saving) or electronic thermal motor overload protection uses the motor parameters and characteristics. To match the property of a control system with that of the motor, select characteristics of the motor and set H03 (Data Initialization) to "2"...
  • Page 153 When Fuji standard 8-series motors (P99 = 0) or other motors (P99 = 4) are selected, the motor parameters for P02 through P08 are as listed in following tables. 200 V series motors shipped for Japan Rated Motor capacity No-load current Applicable current (kW)
  • Page 154 400 V series motors shipped for Japan Motor capacity Rated current No-load current Applicable (kW) motor rating (kW) 0.01 to 0.09 0.06 0.22 0.20 13.79 11.75 0.10 to 0.19 0.10 0.35 0.27 12.96 12.67 0.20 to 0.39 0.20 0.65 0.53 12.95 12.92 0.40 to 0.74...
  • Page 155 Auto-resetting (Times) Auto-resetting (Reset interval) While the auto-resetting feature is specified, even if the protective function subject to retry is activated and the inverter enters the forced-to-stop state (tripped state), the inverter will automatically attempt to reset the tripped state and restart without issuing an alarm (for any faults).
  • Page 156 Cooling Fan ON/OFF Control To prolong the life of the cooling fan and to reduce fan noise during running, the cooling fan is stopped when the temperature inside the inverter drops below a certain level while the inverter is stopped. However, since frequent switching of the cooling fan shortens its life, it is kept running for 10 minutes once it is started.
  • Page 157 Curvilinear acceleration/deceleration Acceleration/deceleration is linear below the base frequency (linear torque) but slows down above the base frequency to maintain a certain level of load factor (constant output). This acceleration/deceleration pattern allows the motor to accelerate or decelerate with the maximum performance of the motor.
  • Page 158 Searching for idling motor speed to follow The frequency drop caused by the current limiting control during auto search for idling motor speed is determined by the frequency fall rate specified by H14. To use the auto search, be sure to enable the instantaneous overcurrent limiting (H12 = 1). Select starting characteristic (STM) (Digital input signal) The (STM) terminal command specifies whether or not to perform auto search operation for idling motor speed at the start of running.
  • Page 159 Starting patterns The inverter makes its frequency shift in accordance with the starting patterns shown below to search the speed and rotation direction of the idling motor. When harmonization is complete between the motor speed (including its rotation direction) and the inverter output frequency, the frequency shift by auto search operation is terminated.
  • Page 160 Instantaneous Overcurrent Limiting H12 specifies whether the inverter invokes the current limit processing or enters the overcurrent trip when its output current exceeds the instantaneous overcurrent limiting level. Under the current limit processing, the inverter immediately turns off its output gate to suppress the further current increase and continues to control the output frequency.
  • Page 161 Command sources specified by H30 Data for H30 Frequency command Run command Inverter itself (F01/C30) Inverter itself (F02) Via RS485 communications link Inverter itself (F02) (standard) Via RS485 communications link Inverter itself (F01/C30) (standard) Via RS485 communications link Via RS485 communications link (standard) (standard) Via RS485 communications link...
  • Page 162 Automatic Deceleration H69 specifies whether automatic deceleration control is to be enabled or disabled. During deceleration of the motor, if regenerative energy exceeds the level that can be handled by the inverter, overvoltage trip may happen. With automatic deceleration enabled, when the DC link bus voltage exceeds the level (internally fixed) for starting automatic deceleration, the output frequency is controlled to prevent the DC link bus voltage from rising further;...
  • Page 163 Clear Alarm Data H97 deletes the information such as alarm history and data at the time of alarm occurrence, including alarms that have occurred during the check-up or adjustment of the machinery. Data is then brought back to a normal state without an alarm. Deleting the alarm information requires simultaneous keying of keys.
  • Page 164 Judgment on the life of DC link bus capacitor Whether the DC link bus capacitor (reservoir capacitor) has reached its life is determined by measuring the length of time for discharging after power off. The discharging time is determined by the capacitance of the DC link bus capacitor and the load inside the inverter. Therefore, if the load inside the inverter fluctuates significantly, the discharging time cannot be accurately measured, and as a result, it may be mistakenly determined that the life has been reached.
  • Page 165 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Select life Judge the Lower the judgment Detect Detect DC Detect input life of DC carrier Function criteria of output fan lock link bus phase loss frequency DC link bus phase loss capacitor automatically...
  • Page 166 Conversion table (Decimal to/from binary) Binary Binary Decimal Decimal Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 5-73...
  • Page 167 Dew Condensation Prevention (Duty) When the inverter is stopped, dew condensation on the motor can be prevented, by feeding DC power to the motor at regular intervals to keep the temperature of the motor above a certain level. To utilize this feature, you need to assign a terminal command (DWP) (dew condensation prevention) to one of general-purpose digital input terminals (function code data = 39).

  • Page 168: Chapter 6 Troubleshooting

    Chapter 6 TROUBLESHOOTING 6.1 Before Proceeding with Troubleshooting If any of the protective functions have been activated, first remove the cause. Then, after checking that the all run commands are set to off, reset the alarm. Note that if the alarm is reset while any run commands are set to on, the inverter may supply the power to the motor which may cause the motor to rotate.

  • Page 169: If No Alarm Code Appears On The Led Monitor

    6.2 If No Alarm Code Appears on the LED Monitor 6.2.1 Motor is running abnormally [ 1 ] The motor does not rotate. Possible Causes What to Check and Suggested Measures (1) No power supplied to the Check the input voltage, output voltage and interphase voltage unbalance. inverter.
  • Page 170 Possible Causes What to Check and Suggested Measures (9) The coast-to-stop Check the data of function codes E01, E02, E03, E04, E05, E98 and E99 command was effective. and the input signal status with Menu #4 "I/O Checking" using the keypad. Release the coast-to-stop command setting.
  • Page 171 Possible Causes What to Check and Suggested Measures (6) Overload Measure the output current. Lighten the load. Check if mechanical brake is working. Release the mechanical brake (Adjust the dumper of the fan or the valve of the pump). (In winter, the load tends to increase.) (7) Mismatch with the In case auto-torque boost or auto-energy saving operation is under way, characteristics of the...
  • Page 172 Possible Causes What to Check and Suggested Measures (2) The external frequency Check that there is no noise in the control signal wires from external sources. command device was Isolate the control signal wires from the main circuit wires as far as used.
  • Page 173 [ 6 ] The motor does not accelerate and decelerate at the set time. Possible Causes What to Check and Suggested Measures (1) The inverter ran the motor Check the data of function code H07 (Acceleration/deceleration pattern). by S-curve or curvilinear Select the linear pattern (H07 = 0).

  • Page 174: Problems With Inverter Settings

    6.2.2 Problems with inverter settings [ 1 ] Nothing appears on the LED monitor. Possible Causes What to Check and Suggested Measures (1) No power supplied to the Check the input voltage, output voltage and interphase voltage unbalance. inverter (main circuit Connect a molded case circuit breaker, an earth leakage circuit breaker power, auxiliary power for (with overcurrent protection) or a magnetic contactor.

  • Page 175: If An Alarm Code Appears On The Led Monitor

    6.3 If an Alarm Code Appears on the LED Monitor Quick reference table of alarm codes Alarm Alarm Name Refer to Name Refer to code code Fuse blown 6-13 Instantaneous overcurrent Charger circuit fault 6-13 Electronic thermal overload relay 6-14 Ground fault Overload 6-14...
  • Page 176 Possible Causes What to Check and Suggested Measures (4) The value set for torque Check that the output current decreases and the motor does not come to boost (F09) was too large. stall if you set a lower value than the current one for F09. (F37 = 0, 1, 3, or 4) Lower the value for torque boost (F09) if the motor is not going to stall.
  • Page 177 Possible Causes What to Check and Suggested Measures (5) Braking load was too Compare the braking torque of the load with that of the inverter. heavy. Set the rated voltage (at base frequency) (F05) to 0 to improve braking ability. (6) Malfunction caused by Check if the DC link bus voltage was below the protective level when the noise.
  • Page 178 Possible Causes What to Check and Suggested Measures (3) Interphase unbalance rate Measure the input voltage. of three-phase voltage Connect an AC reactor (ACR) to lower the voltage unbalance between was too large. input phases. Raise the inverter capacity. (4) Overload cyclically Measure ripple wave of DC link bus voltage.
  • Page 179 The 200V series inverters with a capacity of 45 kW or above and the 400V series inverters with a capacity of 55 kW or above each have a cooling fan/fans for heat sinks and a DC fan for internal air circulation (dispersing the heat generated inside the inverter).
  • Page 180 Possible Causes What to Check and Suggested Measures (4) The set activation level Check the thermistor specifications and recalculate the detection voltage. (H27) of the PTC Reconsider the data of function code H27. thermistor for motor overheat protection was inadequate. (5) A PTC thermistor and Check the connection and the resistance of the pull-up resistor.
  • Page 181 [ 13 ] Electronic thermal overload relay Problem Electronic thermal function for motor overload detection was activated. Possible Causes What to Check and Suggested Measures (1) The characteristics of Check the motor characteristics. electronic thermal did not Reconsider the data of function codes P99, F10 and F12. match those of the motor Use an external thermal relay.
  • Page 182 [ 15 ] Memory error Problem Error occurred in writing the data to the memory in the inverter. Possible Causes What to Check and Suggested Measures (1) While the inverter was Check if pressing the key resets the alarm after the function code data writing data (especially are initialized by setting the data of H03 to 1.
  • Page 183 [ 18 ] Option card communications error Problem A communications error occurred between the option card and the inverter. Possible Causes What to Check and Suggested Measures (1) There was a problem with Check whether the connector on the bus option card is properly mating with the connection between the connector of the inverter.
  • Page 184 [ 21 ] Tuning error Problem Auto-tuning failed. Possible Causes What to Check and Suggested Measures (1) A phase was missing Properly connect the motor to the inverter. (There was a phase loss) in the connection between the inverter and the motor. (2) V/f or the rated current of Check whether the data of function codes F04, F05, H50, H51, P02, and P03 the motor was not properly...
  • Page 185 Possible Causes What to Check and Suggested Measures (6) A high intensity noise was Check if appropriate noise control measures have been implemented (e.g., given to the inverter. correct grounding and routing of control and main circuit wires). Improve noise control. Improve noise reduction measures on the host side.

  • Page 186: If An Abnormal Pattern Appears On The Led Monitor While No Alarm Code Is Displayed

    Possible Causes What to Check and Suggested Measures (5) Broken communications Check continuity of the cable, contacts and connections. cable or poor contact. Replace the cable. (6) A high intensity noise was Check if appropriate noise control measures have been implemented (e.g., given to the inverter.
  • Page 187 [ 2 ] _ _ _ _ (under bar) appears Problem An under bar ( _ _ _ _ ) appeared on the LED monitor when you pressed the key or entered a run forward command (FWD) or a run reverse command (REV). The motor did not start. Possible Causes What to Check and Suggested Measures 5_01...

  • Page 188: Chapter 7 Maintenance And Inspection

    Chapter 7 MAINTENANCE AND INSPECTION Perform daily and periodic inspection to avoid trouble and keep reliable operation for a long time. Take care of the following items during work. • Before proceeding to the maintenance/inspection jobs, turn OFF the power and wait more than five minutes for models of 30 kW or below, or ten minutes for models of 37 kW or above.
  • Page 189 Table 7.1 Continued Check part Check item How to inspect Evaluation criteria 1) Abnormal noise and excessive Structure such 1) Visual or hearing 1), 2), 3), 4), 5) vibration inspection as frame and No abnormalities cover 2) Loosen bolts (tightened parts) 2) Retighten.

  • Page 190: List Of Periodical Replacement Parts

    7.3 List of Periodical Replacement Parts Each part of the product has its own service life that will vary according to the environmental and operating conditions. It is recommended that the following parts be replaced as specified below. When the replacement is necessary, contact your Fuji Electric representative. Table 7.2 Replacement Parts Part name Standard replacement intervals...
  • Page 191 -2 Measuring the capacitance of the DC link bus capacitor (during power-off time under ordinary operating condition) In general, the discharging condition of the DC link bus capacitor during a power-off time under the ordinary operating condition at the end user’s installation is different from that under which the initial measurement is conducted at the time of factory shipment.

  • Page 192: Measurement Of Electrical Amounts In Main Circuit

    (2) Early warning of lifetime alarm For the components listed in Table 7.3, you can get an early warning of lifetime alarm at one of the transistor output terminals ([Y1] to [Y3]) and the relay contact terminals ([Y5A] - [Y5C], and [30A/B/C]) as soon as any of the conditions listed under the "Judgment level"...

  • Page 193: Insulation Test

    Figure 7.1 Connection of Meters 7.5 Insulation Test Because an insulation test is made in the factory before shipment, avoid a Megger test. If a Megger test is unavoidable, follow the procedure below. Because a wrong test procedure will cause breakage of the inverter, take sufficient care.

  • Page 194: Inquiries About Product And Guarantee

    7.6 Inquiries about Product and Guarantee When making an inquiry Upon breakage of the product, uncertainties, failure or inquiries, report the following information to your Fuji Electric representative. Inverter type (Refer to Chapter 1, Section 1.1.) SER No. (serial number of equipment) (Refer to Chapter 1, Section 1.1.) Function codes and their data that you changed (Refer to Chapter 3, Section 3.4.3.) ROM version (Refer to Chapter 3, Section 3.4.6.) Date of purchase...

  • Page 195: Chapter 8 Specifications

    Chapter 8 SPECIFICATIONS 8.1 Standard Models 8.1.1 Three-phase 200 V series...

  • Page 196: Three-Phase 400 V Series

    8.1.2 Three-phase 400 V series...

  • Page 198: Specifications Of Keypad Related

    8.2 Specifications of Keypad Related 8.2.1 General specifications of keypad Table 8.1 General Specifications Items Specification Remarks Protective structure Front side: IP40, Back (mounting) side: IP20 Site to be installed In door Ambient -10 to 50°C temperature Ambient humidity 5 to 95% RH, no condensation allowed No corrosive gas, no inflammable gas, no dust, and no direct Ambient air sunlight allowed...

  • Page 199: Data Transmission Specifications

    8.2.3 Data transmission specifications Table 8.4 Data Transmission Specification Items Specification Remarks Station address No need to specify. To use any keypad, no setup is needed for RS485 Communications protocol Modbus-RTU communications related function codes y01 to y10 Synchronization system Asynchronous start-stop system because their data is ignored.

  • Page 200: Common Specifications

    8.3 Common Specifications...

  • Page 202: Terminal Specifications

    8.4 Terminal Specifications 8.4.1 Terminal functions For details about the main and control circuit terminals, refer to Chapter 2, Section 2.3.6 and Section 2.3.7 (Table 2.10), respectively.

  • Page 203: Running The Inverter With Keypad

    8.4.2 Running the inverter with keypad (Note 1) When connecting a DC reactor (DCR), first remove the short bar between terminals [P1] and [P+]. A DCR is optional for inverters below 75 kW but standard for inverters of 75 kW or above. For inverters of 75 kW or above, be sure to connect a DCR.

  • Page 204: Running The Inverter By Terminal Commands

    8.4.3 Running the inverter by terminal commands (Note 1) When connecting a DC reactor (DCR), first remove the short bar between terminals [P1] and [P+]. A DCR is optional for inverters below 75 kW but standard for inverters of 75 kW or above. For inverters of 75 kW or above, be sure to connect a DCR.
  • Page 205 (Note 5) Normally no need to be connected. Use these terminals when the inverter is equipped with a high power factor PWM converter with a regenerative facility. (Note 6) You can select the frequency command either electronically by supplying a DC voltage signal (within the range of 0 to 10 V, 0 to 5 V, or 1 to 5 V) between terminals [12] and [11], or manually by connecting a frequency command potentiometer to terminals [13], [12], and [11].

  • Page 206: External Dimensions

    8.5 External Dimensions 8.5.1 Standard models Unit: mm Power supply Type voltage FRN0.75F1S-2J Three- FRN1.5F1S-2J phase FRN2.2F1S-2J 200 V FRN3.7F1S-2J FRN5.5F1S-2J FRN0.75F1S-4J Three- FRN1.5F1S-4J phase FRN2.2F1S-4J 400 V FRN3.7F1S-4J FRN5.5F1S-4J 8-12...
  • Page 207 Unit: mm Power Dimensions (mm) Type supply φA φB voltage FRN7.5F1S-2 141.7 16 FRN11F1S-2 196 63.5 46.5 46.5 260 118.5 96.5 Three- FRN15F1S-2 136.7 21 phase FRN18.5F1S-2 200 V 166.2 FRN22F1S-2 FRN30F1S-2 FRN7.5F1S-4 141.7 16 FRN11F1S-4 196 63.5 46.5 46.5 260 118.5 96.5 Three- FRN15F1S-4...
  • Page 208 Unit: mm Power Dimensions （mm） supply Type φA voltage FRN37F1S-2J 310.2 Three- FRN45F1S-2J phase FRN55F1S-2J 345.2 200 V FRN75F1S-2J FRN37F1S-4J 310.2 FRN45F1S-4J FRN55F1S-4J FRN75F1S-4J Three- 345.2 FRN90F1S-4J phase FRN110F1S-4J 400 V FRN132F1S-4J FRN160F1S-4J 509.2 13.5 15.5 FRN200F1S-4J 1000 FRN220F1S-4J 8-14...

  • Page 209: Dc Reactor

    8.5.2 DC reactor Dimension (mm) Power Mounting Terminal supply Inverter type Reactor Mass through through voltage hole for: hole for: DCR2-37C 210 ± 10 185 101 ± 2 50.5 ± 1 125 FRN37F1 -2J Three- DCR2-45C 210 ± 10 185 106 ±...

  • Page 210: Keypad

    8.5.3 Keypad 8-16...

  • Page 211: Protective Functions

    8.6 Protective Functions Alarm monitor output Name Description displays [30A/B/C] Overcurrent Stops the inverter output to protect the inverter from an During protection overcurrent resulting from overload. acceleration Short-circuit Stops the inverter output to protect the inverter from protection overcurrent due to a short-circuiting in the output circuit. During deceleration Ground fault...
  • Page 212 Alarm Name Description monitor output displays [30A/B/C] Ffus Blown fuse Upon detection of a fuse blown in the inverter’s main circuit, this function stops the inverter output. (Applicable to 90 kW or above (for both 3-phase 200 V and 3- phase 400 V)) Abnormal Upon detection of an abnormal condition in the charger circuit inside the inverter,...
  • Page 213 Alarm Name Description monitor output displays [30A/B/C] Operation Start The inverter prohibits any run operations and displays on the error check 7-segment LED monitor if any run command is present when: detection function - Powering up - An alarm is released (the key is turned ON or an alarm reset (RST) is input.) - "Enable communications link (LE)"...

  • Page 214: Chapter 9 List Of Peripheral Equipment And Options

    Chapter 9 LIST OF PERIPHERAL EQUIPMENT AND OPTIONS The table below lists the main peripheral equipment and options that are connected to the FRENIC-Eco. Use them in accordance with your system requirements. For details, refer to the FRENIC-Eco User's Manual (MEH456), Chapter 6 "SELECTING PERIPHERAL EQUIPMENT."...
  • Page 215 Name of peripheral Function and application equipment Molded case circuit breaker Earth leakage When connecting the inverter to the power supply, add a recommended molded case circuit breaker * circuit breaker and earth leakage circuit breaker* in the path of power supply. Do not use * with overcurrent the devices with the rated current out of the recommenced range.
  • Page 216 Name of option Function and application DC reactors A DCR is mainly used for power supply normalization and for supplied power-factor (DCRs) reformation (for reducing harmonic components). 1) For power supply normalization - Use a DCR when the capacity of a power supply transformer exceeds 500 kVA and is 10 times or more than the rated inverter capacity.
  • Page 217 Name of option Function and application External An external potentiometer may be used to set the drive frequency. Connect the potentiometer potentiometer for to control signal terminals 11 to 13 of the inverter. frequency commands Multi-function Allows you to monitor the status of the inverter including voltage, current, and input power, as keypad well as to set various parameters in a conversational mode.

  • Page 218: Chapter 10 Conformity With Standards

    Chapter 10 CONFORMITY WITH STANDARDS 10.1 Conformity with UL Standards and Canadian Standards (cUL-listed for Canada) 10.1.1 General The UL standards, originally established by Underwriters Laboratories, Inc. of U.S., are now a set of standards authorized in the U.S. for preventing fire and accidents, thereby protecting operators, service personnel, and ordinary citizens.

  • Page 219: Harmonic Component Regulation In The Eu

    10.4 Harmonic Component Regulation in the EU 10.4.1 General When a general-purpose industrial inverter is to be used in the EU, the harmonics emitted from the inverter to power lines are strictly regulated as stated below. When an inverter whose rated input is 1 kW or below is connected to a public low-voltage power supply, it is subject to the harmonics emission regulations (users A and B below), except when the inverter is connected to an industrial low-voltage power supply (user C below).

  • Page 220: Conformity With The Emc Directive In The Eu

    10.5 Conformity with the EMC Directive in the EU 10.5.1 General The CE Marking on inverters does not ensure that the entire equipment including CE-marked products is compliant with the EMC Directive. Therefore, it is the responsibility of the equipment manufacturer to ensure that the equipment including the product (inverter) or connected with it actually complies with the standard and to put a CE Marking as the equipment.
  • Page 221 Table 10.1 EMC-compliant Filters and Leakage Current Power Leakage current (mA) * EMC-compliant supply Inverter type Installation style filter model voltage Normal condition Worst condition FRN0.75F1S-2J FRN1.5F1S-2J EFL-4.0E11-2 2.96 2.96 FRN2.2F1S -2J FRN3.7F1S-2J FRN5.5F1S-2J EFL-7.5E11-2 10.6 10.6 FRN7.5F1S-2J FRN11F1S-2J Split style EFL-15SP-2 20.0 23.0...

  • Page 222: Recommended Installation Of Emc-Compliant Filter

    10.5.3 Recommended installation of EMC-compliant filter This section shows how to install an EMC-compliant filter. In the footmount style, mount the inverter on the EMC-compliant filter. In the split style, mount the filter beside or under the inverter. For the footmount style, inverters with ratings of 400 V 5.5 kW and 15 kW require a panel-mount adapter (option) as listed below.

  • Page 223: Emc-Compliant Environment And Class

    The EMC-compliant filter and the inverter should be connected with each other according to the procedure given below. The wiring on the inverter and motor should be performed by an authorized electrical engineer. In order to ensure compliance with the EMC Directive, this procedure should be followed as closely as possible. Basic connection procedure 1) Install the inverter and the EMC-compliant filter on a grounded metal plate.
  • Page 224 FRN110F1S-4J 1) Remove the front cover. (Refer to Chapter 2, Section 2.3 "Wiring.") 2) Change wiring at points A and B shown in the internal location diagram below. Figure 10.4 Internal Location Diagram (FRN110F1S-4J) Point A As shown below, remove the screw (M4) to release the wire end terminal and secure the terminal to the support with the screw removed.
  • Page 225 FRN132F1S-4J, FRN160F1S-4J 1) Remove the front cover. Refer to Chapter 2, Section 2.3 "Wiring." 2) Change wiring at points A and B shown in the internal location diagram below. Figure 10.7 Internal Location Diagram (FRN132F1S-4J, FRN160F1S-4J) Point A As shown below, remove the screw (M4) to release the wire end terminal and secure the terminal to the support with the screw removed.
  • Page 226 FRN200F1S-4J, FRN220F1S-4J 1) Remove the front cover. Refer to Chapter 2, Section 2.3 "Wiring." 2) Change wiring at points A and B shown in the internal location diagram below. Figure 10.10 Internal Location Diagram (FRN200F1S-4J, FRN220F1S-4J) Point A As shown below, remove the screw (M4) to release the wire end terminal and secure the terminal to the support with the screw removed.
  • Page 227 The wiring change in Note 1 can improve the EMC-compliant level of the inverter for an environment or class; however, it increases the leakage currents listed in Table 10.1 to the ones listed below. Make sure that these leakage currents are allowable for your system requirements beforehand. Leakage current (mA) Power supply EMC-compliant...
  • Page 228 MEMO...
  • Page 229 Designed For Fan and Pump Applications Instruction Manual First Edition, September 2004 Third Edition, April 2011 Fuji Electric Co., Ltd. The purpose of this instruction manual is to provide accurate information in handling, setting up and operating of the FRENIC-Eco series of inverters. Please feel free to send your comments regarding any errors or omissions you may have found, or any suggestions you may have for generally improving the manual.

This manual is also suitable for:

Frn2.2f1?-2jFrn5.5f1?-2jFrn7.5f1?-2jFrn11f1?-2jFrn1.5f1?-2jFrn18.5f1?-2j ... Show all

Table of Contents
