Summary of Contents for Simon Vision inno-eye S1006
-
Page 1: Quick Start Guide
S1000 Series Quick Start Guide English Software Release 1.3 www.inno-eye.com... -
Page 2: Table Of Contents
Table of Contents Ⅰ. Product Information ....................3 1. Product Types and Specifications .............. 3 2. Product Components ..................4 Ⅱ. System Configuration ................... 5 1. Hardware Configuration ................5 2. I/O Cable Pin Map .................... 6 3. Installing inno-eye Simulator ..............7 Ⅲ. -
Page 3: Ⅰ. Product Information
Ⅰ. Product Information Quick Start Guide provides a quick and easy guide to install and use inno-eye S-series for the first-time user. 1. Product Types and Specifications Category S1002 S1006 Processor Dual ARM926EJ-S™ RISC Processor Data Memory 128Mbit Stacked DDR SDRAM Flash Memory 1Gbit Resolution... -
Page 4: Product Components
2. Product Components inno-eye’s components are as follows. 1) Standard Components Type Common Built-in Lens Type CS-Mount Type Product Information Guide ×1 ea. Built-in Lens Type CS-Mount Type ×1 ea. ×1 ea. Mounting Bracket ×1 ea. Hexagon Socket Adaptor Ring Lens Focusing Jig Head Bolt for C-Mount inno-eye... -
Page 5: Ⅱ. System Configuration
Ⅱ. System Configuration 1. Hardware Configuration inno-eye can be connected to Control Box , and other accessories as follows : 1) Control Box Control box is a device to supply Power to inno-eye and connect inno-eye with other external devices. Control box is linked up with inno-eye through 12 pin circular cable (HBSM-ACBA) provided. -
Page 6: I/O Cable Pin Map
2) PC PC is connected to inno-eye through the ethernet cable (ZSCR-RJ45) provided. By using inno-eye Simulator installed in PC, we can setup inspection conditions and monitor the results of inspection. 3) Composite Video Monitor Video-out(CVBS) port on monitor is connected to inno-eye mono video out port through Phone Jack ↔... -
Page 7: Installing Inno-Eye Simulator
3. Installing inno-eye Simulator Download inno-eye Simulator and install on PC inno-eye Simulator can be downloaded at http://inno-eye.coreicc.net/kr/support/support.php. After clicking inno-eye download site, User enter client name, company name, email address and click ‘’OK button’’, The compressed file including inno-eye simulator and license key will be sent to the email address entered. - Page 8 key received by email and click the Registration button in order. License means that PC obtains certification which have a permission to use inno-eye Simulator. So, User must register another license by receiving additional license key to use inno-eye Simulator at another PC. Serial number on inno-eye’s cover must be registered to connect inno-eye it inno-eye Simulator.
- Page 9 inno-eye Simulator is comprised as follows : A. Connect inno-eye : Menu for connecting inno-eye to inno-eye Simulator B. Setup Camera : Menu for setting up conditions of taking images, I/O and Illuminator. C. Setup Tools : Menu for selecting tools to be applied for inspection and setting up the inspection specifications such as parameters.
-
Page 10: Ⅲ. Setting Up Inno-Eye Inspection
Ⅲ. Setting up inno-eye Inspection 1. Video Display Display video after connecting inno-eye and PC. ① Connecting inno-eye to inno-eye Simulator installed on PC After Connecting inno-eye and PC by using ethernet cable, then run inno-eye Simulator. ② Click [ Connect inno-eye > Connect inno-eye ]and then, inno-eye dialog box is shown up. - Page 11 inno-eye is automatically set to Run mode when it boots. For displaying images and setting up inspection parameter, change mode option into Setup mode. After that, View Images button can be toggled between Pause View and View Images when user click it. For detailed information for inno-eye Run mode, Refer to the Full Manual Part 2.
-
Page 12: Setting Up Tools
2. Setting up Tools inno-eye Simulator provides 17 kinds of tools for you to execute more accurate inspection. You can register more than one tool according to the purpose of inspection. Category Tool Descriptions Calculate the rotation, and position shift of objects Position Alignment Position °... - Page 13 Example 1 : Position Alignment Tool It is hard to say that the position of inspection object is always located at the same position under the camera view. By using Position Alignment tool, you can execute inspection regardless of the rotation and shift of objects. ①...
- Page 14 Example 2 : Distance Tool Measure the distance between the two designated areas of tested object. ① Click [ Setup Tools> Inspection Tool > Distance ] ② Designate the Inspection area of 1 and 2. Distance Tool finds the nearest point of objects edge from the center of inspection area, and measures the distance of two points.
-
Page 15: Setting Up Trigger
④ Click Add button to register Distance Tool to the tool list. 3. Setting up Trigger Trigger is a timing signal to take images using a camera of inno-eye. Once a trigger signal is received, inno-eye acquires images simultaneously and automatically executes inspection by using acquired images. inno-eye provides 3 kind of triggers: A. - Page 16 To set Trigger, click [ Setup Camera>Setup Trigger ] Selected trigger type is displayed on upper right side of inno-eye Simulator. As inno-eye operates by trigger signal, setting trigger is essential. In case the trigger user set is hardly applicable, click Simulation Trigger Test button so that inno-eye can receive the test trigger signal from Simulator.
-
Page 17: Saving Job File
4. Saving Job File Click Save Job File to save all inspection specifications that is set before as a single Job file. A Job File consists of camera configuration, master image and inspection tool sets. (Job file is saved at C://DIVision/job as default.) 5. -
Page 18: Ⅳ. Executing Inspection Using Inno-Eye
Ⅳ. Executing Inspection using inno-eye You can easily check the results after executing your inspection by inno-eye. ① Once the Job File is sent to inno-eye, inno-eye will reboot automatically. ② After the reboot, inno-eye is set to Run mode and execute inspections by itself according to the user-set trigger method. - Page 19 When Simulator is used for monitoring inspection, inspection results will be shown in 1/4 sizes on Simulator display. You can download full manual at www.inno-eye.com More information about inno-eye and operation of tools are available in full manual.
-
Page 20: Ⅴ. Warranty Information
Ⅴ. Warranty Information DONG IL TECHNOLOGY warrants that this product is free from defective material and workmanship. We will warrant repair of the product free of charge or with charge when product fail to operate properly. To get product warranty, please visit www.inno-eye.com and click Product Registration at Support menu where you can find Product registration form. - Page 21 DONG IL TECHNOLOGY ⓒ2015. All rights reserved. This manual is protected under international copyright laws. No part of this manual may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of DONG IL TECHNOLOGY.
