Page 1: Quickstart Guide
FireBird Frame Grabbers - Installation and Use QUICKSTART GUIDE... -
Page 2: Table Of Contents
FIREBIRD FRAME GRABBER – QUICKSTART GUIDE Contents HARDWARE INSTALLATION SOFTWARE INSTALLATION UPDATING THE FIREBIRD FIRMWARE WHERE TO GO NEXT ASDEMO APPLICATION - BASIC OPERATION ASDEMO APPLICATION - ADVANCED OPTIONS WHAT ELSE IS INSTALLED? SOFTWARE UN-INSTALLATION CONTACT DETAILS FireBird Frame Grabber – Quickstart Guide v1.6... -
Page 3: Hardware Installation
FireBird, it should be aligned at the (taking the usual anti-static more information. case, so the cables should be carefully upper 6 ways of the 8 way FireBird precautions). checked for the pattern of squares connector as shown below. „ CoaXPress Boards Only: If the... -
Page 4: Software Installation
By default, selecting Typical installs ActiveSiliconCleanUpTool.exe to and documentation referred to in this z fbd-cl for the FireBird Camera Link everything, but individual options can remove any unused files left behind document can be found in the Apps view Package. -
Page 5: Updating The Firebird Firmware
The Design option controls the configuration mode of the board. The options presented depend on the board in use. This example shows the options with a 4xCXP FireBird. Default updates the firmware keeping the same configuration mode as before the update. -
Page 6: Where To Go Next
BIOS updates, „ Check that a suitable PCI Express slot The FireBird Hardware Manual gives FireBird can transfer data at very high especially if any bandwidth problems is in use (see Hardware Installation full details of all connectors, LEDs and rates but if the PC cannot keep up the are seen. -
Page 7: Asdemo Application - Basic Operation
Note: The above refers to Windows. For the location of utilities and documentation for other operating systems refer to the specific Quickstart Guide. Note: <xx> represents the camera interface, e.g. CXP or CL. FireBird Frame Grabber – Quickstart Guide v1.6... -
Page 8: Asdemo Application - Advanced Options
4. Similarly a histogram and statistics are displayed for the image, or by entering coordinates, for just part of the image. 5. The console shows details of any error messages. FireBird Frame Grabber – Quickstart Guide v1.6... -
Page 9: What Else Is Installed
Start Menu. These Open Documentation Directory link. a form that can be sent to Active Silicon from cameras. For CoaXPress systems it configure the FireBird board to match technical support. The information is is largely replaced by ASDemo, but the the camera. -
Page 10: Software Un-Installation
PC to allow developers to refer to both old and new SDKs. „ To remove the GenICam library remove package GenICam vX.Y. „ Note: XX.YY.ZZ.BBBB or X.Y.Z or X.Y represents the version number. FireBird Frame Grabber – Quickstart Guide v1.6... - Page 11 This page intentionally blank. FireBird Frame Grabber – Quickstart Guide v1.6...
-
Page 12: Contact Details
