AnyShop POS610 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POS610 and is the answer not in the manual?

Questions and answers

Summary of Contents for AnyShop POS610

  • Page 2: Table Of Contents

    4-2. MSR trouble ……………………….……………………. 6-2. Reference to upgrade and power supply …………... - Speaker and MIC. connection ………………….. 4-3. USB trouble …….……………………………………….. 6-3. AnyShop specification ………………………………………… - Printer connection ……………………………….……. 4-4. LCD trouble ……………..………………………………. - Power cable connection ………..………………..4-5. Touch screen trouble ……………………………….

  • Page 3: Warranty

    Chapter 1. Caution 1-1 Warranty We guarantee our POS terminal product and its parts against defects in materials and workmanship under proper use for a standard period of 2 years from the date of original purchase. During this period, we will repair or replace a defected and/or faulty product or parts without charge for spare and labor to the purchaser. The 1st year is applied with free workmanship and new or refurbished replacement parts with one-way freight cost born by seller and customer shall be responsible for return delivery charge.

  • Page 4: Copyright

    1-2 Copyright This publication including all photograph, illustration and software, is protected under international copyright law with all rights reserved in manufacturer. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. 1-3 Notice for safety 1.

  • Page 5: Circumstance Limitation

    - It is easy to make product out-of-order or system error. 1-4 Circumstance limitation ● Installation and maintenance service We recommend you to have service about product installation, maintenance and repair service from nominated service center and agent office. It is not our responsibility about out of order or system error after service and/or checking system from non predicted service provider. ●...

  • Page 6: Installation Tips

    ● Cleansing It is caused of damage on appearance and exterior surface after cleaning with chemical cleanser. We recommend you to use soft cloth, especially LCD screen. ● Product liability 1. We prohibit product to use for other purpose, but not POS. It is not supported of usual PC operating &...
  • Page 7 5. Keep out of direct sun-light, extreme high or low temperature, and humid area. 6. Take away from impact, shocked, and tremble place. 7. Place product to avoid with sewing machine, Welding instrument, electronic wave range, Audio and other high frequency generated equipment. 8.

  • Page 8: Checking Package

    Chapter 2. Product overview 2-1 Checking package 1. Confirm packing detail which is listed on user manual in package. 2. We provide POS terminal main unit, power cord, user manual and driver CD basically. » It is possible to download user manual and driver CD from our web.
  • Page 9 [Packing details] Driver CD User manual Power code AnyShop main unit...
  • Page 10 [Options] [12 inch LCD Monitor] [Front] [Rear] [Customer display] [Front] [Rear] -10-...

  • Page 11: Preparing Before Installation

    2-2 Preparing before installation 1. Remove masking tape for Touch screen protection. (It may cause abnormal operating when masking tape is not removed.) 2. Install option product(customer display, rear LCD monitor, etc) first when it need to set up with POS main unit. 2-3 Product consist - Detail indication can be different with each POS terminal model.

  • Page 12: Front View

    [Front view] CAMERA LCD & TOUCH SMART CARD READER PANNEL DISPLAY MAGNETIC STRIPE READER POWER POWER SWITCH DUAL SPEAKER -12-...

  • Page 13: Rear View

    [Rear view] CUSTOMER DISPLAY USB PORT I/O PORT STAND -13-...
  • Page 14 [Power & I/O port] Description Description AC IN POWER connector Monitor connector [Option) PS/2 MOUSE connector Parallel connector PS/2 KEYBOARD connector USB connector COM1, COM2, COM3 port LAN connector -14-...

  • Page 15: Installation Of Option Device

    2-4 Installation of option device [CDP installation] 1. Put (-) driver in the marked grooves : and split cover from the rear of POS main unit. 2. Connect cable from POS main unit to customer display(CDP) part and place the display in customer display space. 3.
  • Page 16 [2nd display installation : 12 inch LCD monitor] 1. Disjoin 2 screws from the marked and pull out the cover. 2. Put on the option cover and drive 2 screws up. -16-...
  • Page 17 3. Connect with 2nd Display cable. 4. Put down the cover finally. (Drive 2 screws up) 4. Settle LCD monitor down the frame and screw down 4pcs. -17-...
  • Page 18 5. Testing : It is successfully connected for CDP installation to POS unit when initial booting is on going after power off and (CDP and 12 inch LCD Monitor uses only COM4 port on board.) Notice : Remove AC power cord completely in installation or dissection of CDP &...

  • Page 19: Installation Of Keyboard & Mouse

    [Installation of Keyboard and mouse] 1. Keyboard installation : Connection of PS/2 type keyboard. 2. Mouse installation : Connection of PS/2 type mouse. -19-...

  • Page 20: Installation Of Usb Device

    [Installation of USB device] USB port is provided 2 ports in rear I/O and 2 ports in side I/O supported standard USB 2.0. Some USB device(optional device) is operated only with specific driver software installed. It may cause abnormal working if it is connected with multiple USB devices together. We recommend you to use USB hub for supplying power with external adapter.

  • Page 21: Ethernet Port Connection

    [Ethernet port connection : LAN cable] Ethernet port support 10/100/1000Mbps located with rear I/O. Connector type is RJ45. LAN LED is light on in proper connected case. -21-...

  • Page 22: Speaker And Mic. Connection

    [Speaker and MIC. connection] 1. Speaker connection 2. MIC. connection -22-...

  • Page 23: Printer Connection

    [Printer connection] Connect printer cable among Serial, Parallel and USB port you required. -23-...

  • Page 24: Power Cable Connection

    [Power cable connection] 1. Connect power cable to power connector. 2. Press power button in POS main unit. This POS terminal support 110V ~ 220V power consumption and is adjusted required power voltage with dip switch setting. » We recommend you to use grounded power connection in AC adaptor connection with power code. -24-...
  • Page 25 [Dip switch setting] Select proper voltage supported dip switching setting. » 115V : 100V ~ 120V » 230V : 200V ~ 240V -25-...

  • Page 26: Pos Operating

    [POS operating] » Power on POS accessory and peripherals first before POS power-on. 2. Confirm Windows booting if it is fine. 1. Press power button in POS unit. (It will be lighted on POWER LED.) -26-...

  • Page 27: Pos Closing

    [POS closing] We recommend you to close Windows in O/S for product stability. Please close all application programs before Windows termination. * We recommend you to use grounded power connection in AC adaptor connection with power code. 1. Select „Turn off Computer‟ on Start in Windows initial screen 2.

  • Page 28: System Driver

    2-5. System driver OPOS driver We provide UNIPOS driver for OPOS driver system to our product based on Windows XP O/S. You can download also from our web if you need latest version of OPOS driver. Supported device : Cash drawer, CDP(Customer display), MSR(Magnetic Card Reader) and Printer OPOS driver installation ●...
  • Page 29 Chapter 3. BIOS SETUP UTILITY This motherboard supports a programmable firmware chip that you can update using the provided utility. Use the BIOS Setup program when you are installing a motherboard, reconfiguring your system, or prompted to “Run Setup.” This section explains how to configure your system using this utility. Even if you are not prompted to use the Setup program, you can change the configuration of your computer in the future.
  • Page 30 You should be careful in BIOS change and it may cause malfunction or break-up in case you change it without full comprehension. Set-up (DEL) After pressing [power] button, when system starts, click [DEL] key or shown screen message Press [Del] to enter SETUP after pressing [Del] key then system set up screen changed.

  • Page 31: Bios Menu Screen

    3-1. BIOS menu screen When you enter the BIOS, the following screen appears. The BIOS menu screen displays the items that allow you to make changes to the system configuration. To access the menu items, press the up/down/right/left arrow key on the keyboard until the desired item is highlighted, then press [Enter] to open the specific menu.

  • Page 32: Standard Cmos Features

    3-2. Standard CMOS features. The Standard CMOS Features screen gives you an overview of the basic system. -32-...

  • Page 33: Advanced Bios Features

    Date[Day, xx/xx/xxxx] Video The date format is <Week>, <month>, <day>, <year>. This category detects the type of adapter used for the primary monitor that must match your video display card and monitor. • EGA / VGA: Enhanced Graphics Adapter/Video Graphics Array. For EGA, VGA, SVGA, Time[xx:xx:xx] or PGA monitor adapters.
  • Page 34 The “Advanced BIOS Features” screen appears when choosing the “Advanced BIOS Features” item from the “Initial Setup Screen” menu. It allows the user to configure the motherboard according to his particular requirements. Below are some major items that are provided in the Advanced BIOS Features screen. A quick booting function is provided for your convenience.
  • Page 35 This item allows you to setup the CPU thermal management function. Set the boot up Num Lock status. The options are “On” and “Off”. Delay Prior to Thermal Gate A20 Option With the default value of 16 Minutes, the BIOS activates the Thermal Monitor in automatic mode Normal : A pin in the keyboard controller controls GateA20 16 minutes after the system starts booting up Fast : Lets chipset control GateA20 (Default)
  • Page 36 3-4. Advanced chipset features -36-...
  • Page 37 DRAM Timing Selectable Video BIOS Cacheable This item allows you to select the DRAM timing value by SPD data or Manual by yourself. This feature is only valid when the video BIOS is shadowed. It enables or disables the caching of The choices: Manual, By SPD.

  • Page 38: Integrated Peripherals

    3-5. Integrated peripherals Use this menu to specify your settings for integrated peripherals. -38-...
  • Page 39 [On-chip IDE device] IDE HDD Block Model IDE Primary/Secondary Master/Slave PIO/UMDA If the IDE hard drive supports block mode select Enabled for automatic detection of the optimal The channel has both a master and a slave, making four IDE devices possible. Because two IDE number of block read/writes per sector the drive can support.
  • Page 40 [On-board device] Azalia/AC97 Audio Select This item allows you to Enabled/Disabled Azalia/AC97 chipset. The options: Auto, AC97 Audio only, Disabled. -40-...
  • Page 41 [ Super I/O device] Power ON Function This feature allows you to wake up the system using any of the listed options. POWER After PWR-fail The options: [Mouse Left], [Mouse Right], [Any KEY], [Button Only]. Onboard Serial Port The options are [off], [on]. Select an address and corresponding interrupt for the first and second serial ports.
  • Page 42 Onboard LAN Boot ROM Onboard Serial Port 3 Serial Port 3 Use IRQ The options are [disabled], [enable Select an address and corresponding interrupt for the serial ports. Select an IRQ for the serial ports. The choice: [Disabled], [3F8], [2F8], [3E8], [2E8]. The options: IRQ3, IRQ4, IRQ5, IRQ7, IRQ10, IRQ11 Watch Dog Timer Select 4.9 Serial Port 4 Use IRQ...

  • Page 43: Usb Device Setting

    [USB device setting] USB 1.0 / 2.0 Controller USB Keyboard Function The choices: Disabled, Enabled. The choices: Disabled, Enabled. USB Mouse Function USB Operation Mode The choices: Disabled, Enabled Allows you to configure the USB 2.0 controller in HiSpeed (480 Mbps) or Full Speed (12 Mbps).

  • Page 44: Power Management Set Up

    3-5. Power management setup The power management setup controls the single board computer's “green” features to save power. The following screen shows the manufacturer‟s defaults. -44-...
  • Page 45 ACPI Function Suspend Mode The choices are “Enabled” and “Disabled”. The item allows to set the number of minutes before the system enters suspend mode. ACPI Suspend Type The choices: Disabled, 1, 2, 4, 8, 12, 20, 30, 40 Min, 1 Hour. This item allows you to set ACPI suspend type to S1/POS(Power On Suspend) or S3/STR(Suspend To RAM).

  • Page 46: Pnp/Pci Configurations

    3-6. PnP/PCI configurations Rest Configuration Data Resource Controlled By The default is “Disabled”. Select Enabled to reset Extended System Configuration Data (ESCD) if you have The commands here are “Auto(ESCD)” or “Manual”. Choosing “Manual” requires you to choose resources installed a new add-on card, and system configuration is in such a state that the OS cannot boot. from the following sub-menu.

  • Page 47: Pc Health Status

    3-7. PC health status System Temperature Chassis FAN Speed This shows you the current temperature of system. This shows the Chassis FAN Speed (RPM). CPU Temperature VCore and Others Voltage This shows the current CPU temperature. This shows the voltage of VCORE, +5V, +12V, VCC(V), AVCC(V), VCC3(V), VBAT(V), and 3VSB(V).

  • Page 48: Load Set Up Defaults

    3-8. Load setup defaults Use this menu to load the BIOS default values that are factory settings for optimal performance system operations. While Award has designed the custom BIOS to maximize performance, the factory has the right to change these defaults to meet their needs. Press <Y>...

  • Page 49: Set Password

    3-9. Set password You can set password. It is able to enter/change the options of setup menus. -49-...
  • Page 50 3-10. Save and exit setup If you select this and press <Enter>, the values entered in the setup utilities will be recorded in the CMOS memory of the chipset. The processor will check this every time you turn your system on and compare this to what it finds as it checks the system. This record is required for the sys- tem to operate. -50-...

  • Page 51: Exit Without Saving

    3-11. Exit without saving Selecting this option and pressing <Enter> lets you exit the setup program without recording any new values or changing old ones. -51-...

  • Page 52: Network Trouble

    Chapter 4. Trouble-shooting 4-1. Network trouble Symptom Corrective Procedure Check if hub or switch is working correctly  Cannot access LAN Check the RJ45 cable connection  Check if the RJ-45 LEDs are on  Reinstall LAN card   Replace motherboard 4-2.

  • Page 53: Usb Trouble

    4-3. USB trouble Symptom Corrective Procedure USB port doesn‟t work at all ▪ Check Windows device manager about device recognition ▪ Check USB device status and connection ▪ Erase and re-install USB driver ▪ Change USB device 4-4. LCD trouble Symptom Corrective Procedure LCD backlight doesn‟t work...

  • Page 54: Power Trouble

    4-6. Power trouble Symptom Corrective Procedure Suddenly power off and system is not executed ▪ Check A/C cable connection ▪ Confirm motherboard power connection ▪ Check CPU setting status ▪ Check DRAM setting ▪ Check power button cable connection ▪ Change power supply unit 4-7.
  • Page 55 4-9. Printer trouble Symptom Corrective Procedure Printer is not operated ▪ Check printer power supply ▪ Replace printer paper roll ▪ Check printer cable -55-...

  • Page 56: Motherboard Jumper Setting

    Chapter 5. Motherboard jumper setting 5-1. Motherboard jumper setting -56-...
  • Page 57 -57-...

  • Page 58: Motherboard Dip Switch & Interface Description

    5-2. Motherboard dip switch & interface description Slot Label DDR2 SO-DIMM slot None CF1 Compact Flash socket DIMMA1 Label Function Internal Connector Label Function Note AMPJ1 Amplifier connector 4 X 1 header, pitch 2.5 4mm CPU-FAN1 CPU fan connector 3 X 1 header, pitch 2.5 4mm SYS_FAN1 System fan connector 3 X 1 header, pitch 2.5 4mm...
  • Page 59 SATA1 Serial ATA connectors [black] 7-pin header SATA2 Serial ATA connectors [black] 7-pin header Jumpers Label Function None CLRRTC1 Clear CMOS 3 X 1 header, pitch 2.5 4mm JCOMPWR1 COM port 1, 2 RI/+5V/+12 selection 5 X 2 header, pitch 2.00 mm JCOMPWR2 COM port 3,4 RI/+5V/+12 selection 5 X 2 header, pitch 2.0 0mm...

  • Page 60: Serial Port Power Setting

    5-3. Serial port power setting 5○○○1 Pin 9 12V output 6○○○2 5○○○1 Pin 9 5V output 6○○○2 Pin 9 RI 5○○○1 6○○○2 (Ring Indicate) COM2 COM1 COM3 -60-...

  • Page 61: Cmos Clear

    5-4. CMOS Clear ○ ○ ○ Protect CMOS ○ ○ ○ Clear CMOS -61-...

  • Page 62: Safety & Danger Precaution

    Chapter 6. Replacement 6-1. Safety and danger precaution We don't have responsibility about repairing through service provider which is not identified by seller officially. 1. Always disconnect the unit from the power outlet. 2. Remove all cables away from POS main unit before repairing. 3.
  • Page 63 [Main unit dissection] 1. Drive 2 screws out like the above and take off hinge cover. 2. Screw 8 pcs out from the frame under the hinge cover area. -63-...

  • Page 64: Main Unit Dissection

    3. Pull out main unit from the stand. 4. Complete main unit dissection. -64-...
  • Page 65 [MSR] » It is supported to PS2, USB and Serial port for cable connection. 1. Remove dummy cover. 2. Connect MSR cable. 3. Fix MSR with 2 screws. -65-...

  • Page 66: Hdd Change

    [HDD change] 2. When press „PUSH‟ guide, HDD will be come out. 1. Take HDD cover out from the unit. 3. Insert new HDD and put the cover on. -66-...

  • Page 67: Motherboard Change

    [Motherboard change] » We recommend removing MSR, HDD and CDP before motherboard replacement. 1. Disjoin 8 screws from the above spot with (+) driver on rear side of Complete rear cover out. main unit and take off the rear cover of main unit. -67-...
  • Page 68 2. Drive 10 screws up from the frame after split of rear cover and pull Finish taking off frame. out the frame. -68-...
  • Page 69 DUCT 3. Split FAN and DUCT after taking off the frame. 4. Remove 4 screws in the marked spot and pull out FAN and DUCT. -69-...
  • Page 70 6. Separate cable from motherboard. Finish isolating motherboard. 5. Drive 4 screws up from like the above after put out of FAN and 7. Assembly in opposite procedure of the above after connecting DUCT. cable to motherboard. -70-...

  • Page 71: Fan & Heatsink Change

    [FAN & HEATSINK change] 1. Divide frame and rear cover from the rear side of main unit. 2. Remove 4 screws from the marked spot and pull out FAN and (It is the same of taking off rear cover and frame with DUCT.
  • Page 72 DUCT Complete to put out FAN and DUCT. 3. Screw 4 pcs out from the marked area. (Only changing FAN and DUCT, Separate part like 1 & 2 step, put FAN and DUCT for replacement on the proper and assembly in opposite procedure.) -72-...
  • Page 73 HEATSINK 4. Disconnect cable from motherboard. (Finish to pull out 5. Remove 2 screws from the marked, and take off HEATSINK. motherboard) 6. Exclude cable from the HEATSINK. (Finish isolating HEATSINK.) 7. Assembly in opposite procedure after replacement of HEATSINK. -73-...

  • Page 74: Power Supply Unit Change

    [Power supply unit change] » We recommend removing MSR, HDD and CDP first before replacement of Power supply unit. 1. Separate rear cover after 8 screws out from the marked spot with (+) 2. Take off frame with 10 screws out after pull-out of rear cover. driver in rear side of main unit.
  • Page 75 3. Drive 2 screws up like the above after frame removal. Complete to extract Power supply unit. 4. Assembly in opposite steps after replacement of power supply unit. -75-...

  • Page 76: Cpu Change

    [CPU change] [Pull out] » It is easy to be damaged on CPU handling in force in wrong position. [Insert] Please refer Motherboard jumper setting for CPU position. 3. Insert new CPU in proper position. 1. Turn CPU fixture to 180 (-) driver.

  • Page 77: Ram Change

    [RAM change] - Please refer to Motherboard jumper setting for RAM location. 3. Insert new memory in the slot and press 1. Push left and right RAM fix guide to each side like the above. slightly. 2. Pull RAM memory out. -77-...

  • Page 78: Reference To Upgrade And Power Supply

    6-2. Reference to upgrade and power supply Intel C Mobile 1.5 GHz Upgrade reference DDR2 SODIMM 512MB (up to 2GB) 2.5" SATA HDD 120GB above Power Type Operating 0 ~ 60°C (32 ~ 140°F) Power supply specification Temperature Operating Humidity 0% ~ 90% relative humidity, non-condensing Size (L x W) 6.69"...

  • Page 79: Anyshop Specification

    6-3. AnyShop specification Chipset Intel 915GME Intel 945GME Intel Mobile Processor(Default Celeron Mobile 1.5GHz) Intel Core 2 Duo / Core Solo / Core Duo / Celeron M SATA 2.5inch (Default 120GB) DDR2 SODIMM x 1slot (Default 512MB Up to 2GB)
  • Page 80 Camera Camera Dallas Dallas I-button reader VFD type Customer Display (20 x 2) 2nd LCD 12inch LCD : 800 x 600 Resolution DVR Card : 4channels support WiFi Mini PCI for wireless LAN Mini PCI for VGA card Safety & EMI CE, FCC, KCC Power Supply AC 110 or 220V (Max.230 watt)
