Page 1 8ft Wide “Poly-Pitch” Assembly Instructions...
Page 2: Table Of Contents
8ft Wide “Poly-Pitch” Assembly Instructions CONTENTS Section Page FOUNDATION TUBES: Option A – Concreted Foundation Tubes FOUNDATION TUBES: Option B – Ground Anchor Plates TIMBER BASE RAILS (Along the sides) STEEL FRAME ASSEMBLY & INSTALLATION TIMBER END FRAME ASSEMBLY & INSTALLATION...
Page 3: Foundation Tubes: Option A - Concreted Foundation Tubes
8ft Wide “Poly-Pitch” Assembly Instructions Work Safely When you tackle a job it is important to work safely. Please consider the following points when building your Polytunnel.  Keep your work area tidy. A tidy site is a safe site.
Page 4 8ft Wide “Poly-Pitch” Assembly Instructions Slot the Foundation Tubes into the concrete, to the outside of the string lines. Make sure the Foundation Tubes are vertical, touching the string line and spaced at 5ft centres. The Foundation Tubes should be protruding above ground by approximately 35cm.
Page 5: Foundation Tubes: Option B - Ground Anchor Plates
8ft Wide “Poly-Pitch” Assembly Instructions FOUNDATION TUBES: Option B – Ground Anchor Plates Set two string lines to the width of the polytunnel (8ft apart). Ensure they are parallel. Tip! It’s best to put your polytunnel on a flat, level site.
Page 6: Timber Base Rails (Along The Sides)
8ft Wide “Poly-Pitch” Assembly Instructions TIMBER BASE RAILS (Along the sides) Lay the lengths of 38mm x 89mm timber along the side of the polytunnel, end-to-end. Join together with the timber joint plates and 30mm twist nails. Position the joined timbers against the foundation tubes and flush with the M20 fitting at one end.
Page 7: Steel Frame Assembly & Installation
8ft Wide “Poly-Pitch” Assembly Instructions STEEL FRAME ASSEMBLY & INSTALLATION Assemble the hoops. Lay the components out on a flat surface with the fittings in the positions shown. Please note the orientation of the fittings. Tip! If you have ordered crop/tie bars, it’s easier to put the KH25 fittings onto the inner hoops now.
Page 8 8ft Wide “Poly-Pitch” Assembly Instructions The A20 fitting is slotted over each foundation tube for the hoop to rest on. Set the A20 fittings on the end foundation tubes so that they are level across the width of the ‘tunnel and approximately 5cm above top of the base rail.
Page 9 8ft Wide “Poly-Pitch” Assembly Instructions 12 Set the end hoops so that they are vertical (looking from the side) by adjusting the position of the KH25 fittings on the end hoop. Copyright © Robinson Polytunnels 2014...
Page 10: Timber End Frame Assembly & Installation
8ft Wide “Poly-Pitch” Assembly Instructions TIMBER END FRAME ASSEMBLY & INSTALLATION For each Timber End Frame you will need: a. 3 pieces of timber at 89mm x 38mm x 2400mm long b. 2 corner joint plates c. 1 batten 38mm x 19mm x 1800mm long (temporary) d.
Page 11: Timber Base Rail (Across The Ends)
8ft Wide “Poly-Pitch” Assembly Instructions TIMBER BASE RAIL (Across the ends) Place the end of the timber 89mm x 38mm x 240cm long up to the side of the door post. Mark the timber to the outside face of the timber base rail already fitted along the side of the polytunnel and cut to length.
Page 12: Timber Side Rail (Option)
8ft Wide “Poly-Pitch” Assembly Instructions TIMBER SIDE RAIL (OPTION) Set the M25 fittings and H25 fittings 90cm above the top of the Base Rail. Fix the timber rails along the sides of the polytunnel, ensuring they are parallel with the base rail.
Page 13: Roll Up Curtain (Option)
8ft Wide “Poly-Pitch” Assembly Instructions ROLL UP CURTAIN (OPTION) Cut the 2m wide roll of polythene down the centre, to 1m wide. (This may have already been done for you). Join the lengths of curtain tube together starting with the plain-ended piece. Fix the tubes together with a self-drill screw.
Page 14 8ft Wide “Poly-Pitch” Assembly Instructions Take up the slack in the polythene by rolling the drive tube into the polythene. Slot the gearbox assembly onto the square shaft and slide the guide tube into tube on the gearbox bracket. Hold the guide tube onto the inside faces of the base rail and side rail and fix it to the base rail with an M8 x 50 coach screw.
Page 15: End Panels & Side Netting (Included With Timber Side Rail Option)
8ft Wide “Poly-Pitch” Assembly Instructions END PANELS & SIDE NETTING (INCLUDED WITH TIMBER SIDE RAIL OPTION) Cut a piece of polythene to fit over the panel at the side of the doorway and around the side of the polytunnel by approximately 40cm (approximately 1m x 1.5m).
Page 16: Fitting The Anti Hot Spot Tape
8ft Wide “Poly-Pitch” Assembly Instructions 10. FITTING THE ANTI HOT SPOT TAPE The Anti Hot Spot Tape is applied to the hoops of the polytunnel where the polythene would touch. Starting just above the A20 fitting on the Foundation Tube, place the Anti Hot Spot Tape on the outside face of the hoop.
Page 17: Fitting The Polythene - Polythene To Base Rail
8ft Wide “Poly-Pitch” Assembly Instructions 11. FITTING THE POLYTHENE – POLYTHENE TO BASE RAIL Unroll and unfold the polythene and drape it over the polytunnel framework with an equal amount over each side and each end. Carefully slice the polythene diagonally from the top corners of the doorway.
Page 18 8ft Wide “Poly-Pitch” Assembly Instructions 10 Continue around the corners, pulling the polythene towards to doorway. 11 Now fix the polythene to the door posts. The polythene is pulled into the doorway and pleated. Trap the polythene behind the batten as you nail the batten into the rebate.
Page 19: Fitting The Polythene - Polythene To Side Rail
8ft Wide “Poly-Pitch” Assembly Instructions 12. FITTING THE POLYTHENE – POLYTHENE TO SIDE RAIL Unroll and unfold the polythene and drape it over the polytunnel framework with an equal amount over each side and each end. Carefully slice the polythene diagonally from the top corners of the doorway.
Page 20 8ft Wide “Poly-Pitch” Assembly Instructions 10 Continue around the corners, pulling the polythene towards to doorway. 11 Now fix the polythene to the door posts. The polythene is pulled into the doorway and pleated. Trap the polythene behind the batten as you nail the batten into the rebate.
Page 21: Door Assembly & Installation
8ft Wide “Poly-Pitch” Assembly Instructions 13. DOOR ASSEMBLY & INSTALLATION For each door frame you will need: a. 2 pieces of timber at 42mm x 38mm x 1830mm long (verticals) b. 3 pieces of timber at 42mm x 38mm x 770mm long (horizontals) c.
Page 22 8ft Wide “Poly-Pitch” Assembly Instructions Starting with the mid-rail, nail a batten over the polythene and net. Use 50mm long nails, 9 nails per batten. Next nail on the end battens and finally the side battens. Trim off the surplus polythene and net.
Page 26: Polytunnel Maintenance
8ft Wide “Poly-Pitch” Assembly Instructions POLYTUNNEL MAINTENENCE Your polytunnel should require very little maintenance during normal use. 1. “Moving” parts of your polytunnel are the most susceptible to damage from extreme weather conditions. These include items like doors and roll up curtains. To minimise the likelihood of damage, ensure that the doors and curtains are operating correctly and adjust where necessary.
