Primary Screen; Planning Mode - satmap Active 20 Quick Start Manual

Primary Screen:

Current Location
Toggle Maps
Data Boxes
North Up / Trail Up /
Trail Up (Low)
• Current Location is shown by the blue circle. If you are moving the Direction Indicator will
be displayed.
• Toggle Maps will switch the mapping between the base maps and any other mapping
scales from the inserted MapCard, if any are available at position and zoom level.
• Zoom In / Zoom Out to change the magnification of the map data on the screen.
Map layers will change at certain set levels (where available).
• Data Boxes These can be overlaid on the map in groups of two or four, and provide live
data on your current trip; the data displayed can be customized in the settings menu
(Main Menu > Settings > x Data Box
graph; please see full user guide for more information.
• North Up / Trail Up / Trail Up (Low)
(i.e. top of screen is fixed north), Trail Up
travel), and Trail Up (Low) [as Trail Up, but with the
the map screen; best for fast moving activities such as cycling].
6
GPS Map
Zoom in
Zoom out
Layout). There is also an option to overlay an altitude
This changes map orientation from North Up
(map automatically orientates in direction of
Current Location indicator set lower on
Primary Screen:
• Whilst in GPS MAP, moving the d-pad or dragging the map on the touchscreen will take you
into Planning mode and the blue Current Location
In this mode you can move about the map using the d-pad or touchscreen.
• Toggle Maps & Zoom In / Out work the same as in GPS Map mode.
• Centre press on the joystick to go to the

PLANNING mode

circle changes to orange with crosshairs.
POSITION INFO screen.
