Summary of Contents for WOW! Videoke Premium TKM-360P
-
Page 2: Table Of Contents
Quick Guide - HOT KEY - Channel Setting Introduction How to take care of your WOW Videoke Premium Package Contents / Optional Items Nomenclature 9-13 - Main Player - Remocon - Microphone How to operate the WOW Videoke Premium - Power On/Off - Installation of song pack Installation Guide 15-17... -
Page 3: Quick Guide
HOT KEY RANDOM FAVORITE SONG PLAY RECORDING HANDCLAP... -
Page 4: Channel Setting
Channel setting TKM-360P has eight (8) available channels. Please take note that wireless microphones and main player should be on the same channel. In case of channel interference (either one or two of the microphones cannot be detected by the main player), Please follow the step by step instruction below for re-channeling. - Page 5 Step2) Wireless Microphone (transmitter) Change by using remote control (point the remote control to the MIC sensor near the switch of the microphone) 1) Turn on the Microphone. 2) Press [REC] - Microphone LED will blink once. 3) Press [MENU] button - Microphone LED will turn off. 4) Please input the channel number among 1 to 8.
-
Page 6: Introduction
WOW Videoke Premium. The WOW Videoke Premium provides various kinds of Moving Picture Background. (Nature, 3D, MTV, K-POP Video) The WOW Videoke Premium provides additional built-in memory space of 64MB, so you can either record songs save pictures to use as background image. five WOW Videoke Premium - MTV is original music video with original singer's voice. -
Page 7: How To Take Care Of Your Wow Videoke Premium
WOW Videoke Premium WOW Videoke Premium. WOW Videoke Premium. WOW Videoke Premium WOW Videoke Premium” WOW Videoke Premium WOW Videoke Premium WOW Videoke Premium WOW Videoke Premium WOW Videoke Premium. w w w. wow v i d e o ke.com... -
Page 8: Package Contents / Optional Items
An additional song packs will allow you to sing with your loved ones and friends. Wireless MIC : You can add one more wireless microphone. Total 3 MIC(2 wireless, 1 wired) are supported in TKM-360P. MIC stand : You can display both wireless MIC and wired MIC with MIC stand. -
Page 9: Nomenclature
MIC POWER Switch FRONT MIC 3 input MIC 2 MIC 1 POWER indicator lamp indicator lamp indicator lamp REAR Adaptor input USB input Audio output Video output SIDE SD CARD slot POWER Switch w w w. wow v i d e o ke.com... -
Page 10: Remote Control
(Remote Control) w w w. wow v i d e o ke. co m... -
Page 11: Power On/Off
(Remote Control) FUNCTION SUBSTANCES POWER Power On/ Off. MENU Detail Functions. SONG SEARCH Song search by Title, Artist, Lyrics, Number. NUMBER NUMBER. START START. CANCEL CANCEL. MUSIC NOTE Select the music note display on/off. APPLAUSE Create a mood with applause effect. ▲▼◀▶... - Page 12 (Remote Control) w w w. wow v i d e o ke. co m...
- Page 13 (Microphone) If the microphone does not work even within a short distance from the main Player, the batteries need to be changed. 1.Turn in a counter-clockwise direction to open the cover. 2. Insert the batteries correctly. 3.Turn in a clockwise direction to close the cover. w w w.
-
Page 14: How To Operate The Wow Videoke Premium
WOW Videoke Premium -WOW Videoke Premium main unit WOW Videoke Premium Please refer to the Installation Guide. -WOW Videoke Premium main unit side WOW Videoke Premium turning off the main player. WOW Videoke Premium POWER WOW Videoke Premium. WOW Videoke Premium WOW Videoke Premium w w w. - Page 15 WOW Videoke Premium WOW Videoke Premium MIC3. WOW Premium MIC3. w w w. wow v i d e o ke.com...
- Page 16 WOW Videoke Premium input w w w. wow v i d e o ke. co m...
- Page 17 WOW Videoke Premium w w w. wow v i d e o ke.com...
-
Page 18: Additional Menu Function & Configuration Settings
{START}. WOW Videoke Premium WOW Videoke Premium {RSRV}. Title, Artist and Number {FAVORITE} w w w. wow v i d e o ke.com... - Page 19 Recorded songs are stored in the WOW Videoke Premium's built-in memory. The user memory is shared by the recorded songs and the user photos. The total memory is 64MB which is equivalent to 60 minutes of recorded songs. 35 minutes is immediately available while the remaining 25 minutes was used for the pre-loaded user photos and TJ media encoder.
-
Page 20: Sd Card
SD CARD. SD CARD manual Procedures :TKM-360P Power OFF → Insert SDCARD →TKM-360P Power ON → System → booting (SD CARD directories created) → TKM-360P Power OFF → Disconnect SD CARD and connect to PC by USB cable →... -
Page 21: Encoder
ENCODER What is TJ Media Encoder? TJ Media Encoder is a converting program that provides users to convert their moving pictures or image files to the suitable format for TKM-360P. System Requirements Operating System :Windows XP,Windows Vista Processor : Intel Pentium ll or AMD 233MHz up... - Page 22 TJ Media Encoder Installation Connect the TKM-360P with PC using USB cable and turn on the power. Directory named“TKM-360P U_M”will be created. Open the “TKM-360P_M” folder and double click the “TJ Media_Encoder.exe” to execute installation. Installation progress [ 1. Program Setup Start] [ 2.Select Destination Location]...
- Page 23 [ 3.Select Start Menu Folder] [ 4.Select AdditionalTasks ] [ 5.Ready to Install] [ 6.Setup Finished ] w w w. wow v i d e o ke.com...
- Page 24 Converting moving pictures Double click the TJ Media Encoder icon to start the program. Click [Video]. Click [File Add] to load a file that you want to convert. w w w. wow v i d e o ke. co m...
- Page 25 Converting moving pictures Click [Option] if you want the converted files saved as an another file name and or in different location. Click [Convert] to execute converting. After converting is finished, you can check the file in the saving folder (Initial saving folder : My Documents →TJMedia) w w w.
- Page 26 Converting Image files StartTJ Media_Encoder and click [Image]. Click [File Add] to load an image file that you want to convert. w w w. wow v i d e o ke. co m...
- Page 27 Converting Image files Click [Option] to save as an another file name and or in different location. You can also spin the direction of the image. Click [Convert] to execute converting. SD CARD manufactures SanDisk Transcend Kingston cd-r king RiDATA 1GB, 2GB, 4GB, 8GB KINGMAX KingCom...
-
Page 28: Music Note
MUSIC NOTE To display the music note, play a song and press {MUSIC NOTE} button in remote control. While music note is displaying, you can change lyrics mode by press {music note} button in remote control. 2970 Built-in Songs are available to display the music notes. (Medley, Event, MTV, MVP, some MIDI songs are not available music note display) w w w. -
Page 29: Usb Function
WOW Videoke Premium PC connection ‘TKM-360P U/M’ WOW Videoke Premium Windows XP, 7 O/S. w w w. wow v i d e o ke.com... -
Page 30: Using Your Photos As Background Image
Using your photos as background image TKM-360P U/M. WOW Videoke Premium main player on. Press “BGV”button to select “USER” and your photos will be shown. 1MB. You can add approximately 110 images to the main player base on the size of each image is 350KB. -
Page 31: Troubleshooting Guide
WOW Videoke Premium WOW Videoke Premium. WOW Videoke Premium a. Press The {+} Button Of the MIC In The Remote Control To Increase The Volume Of the MIC. WOW Videoke Premium WOW Videoke Premium WOW Videoke Premium w w w. wow v i d e o ke.com... -
Page 32: Q&A - Other
Enter the menu then [Config], then enter [TV Set-Up] then select either NTSC or PAL. {RSRV} {RSRV}. w w w. wow v i d e o ke. co m... -
Page 33: Product Specification
Product Specification Item Specs Output 2Vrms Audio Frequency 20Hz - 20KHz Input AC100 - 240V (50-60Hz) Adaptor Output DC12V, 0.5A ~ 1A Video Output 75 1.0Vp-p Ω Input DC12V, 0.5A~1A Consumption(W) Main Station Weight (g) Dimension(WxDxH) 156x116x50 w w w. wow v i d e o ke.com... - Page 34 Declaration of Conformity Trade Name : TJ media Model : TKR-320 Responsible Party : TJ media co.,Ltd. Address : 640-8 Deungchon-dong, Gangseo-gu, Seoul 157-030, Korea Telephone : 82-2-3663-4700 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
