Gekasmetal AMANDA User Manual

Air heater pellet stove
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AIR HEATER PELLET STOVE BY GEKASMETAL
AMANDA
9KW
Manual
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMANDA and is the answer not in the manual?

Questions and answers

Summary of Contents for Gekasmetal AMANDA

  • Page 1 AIR HEATER PELLET STOVE BY GEKASMETAL AMANDA Manual Page 1...

  • Page 2: Table Of Contents

    AIR HEATER PELLET STOVE BY GEKASMETAL Please read the instructions carefully before installation, use and maintenance This manual of use constitutes integral part of the product. Dear client, Thank you for placing your confidence in our company and congratulations for your choice! You have purchased one of the many products of Gekas Metal company, intended for the heating of private or public spaces with the use of solid fuels.

  • Page 3: Warnings And Guarantee Terms

    AIR HEATER PELLET STOVE BY GEKASMETAL 3. FUMES EXTRACTION SYSTEMS......................8 FLUE..............................9 ADDITIONAL REQUIREMENTS FOR APPLIANCES EQUIPPED WITH ELECTRIC FAN FOR FUME DISCHARGE..........10 EXAMPLES OF PROPER CONNECTION.......................10 FLUE TERMINALS..........................11 COMBUSTION PRODUCTS MOUTH HEIGHT....................11 PRODUCT REQUIREMENTS FOR THE FUME EXTRACTION SYSTEM..........12 4. CLEANING AND MAINTENANCE......................12 5.
  • Page 4 AIR HEATER PELLET STOVE BY GEKASMETAL •This appliance should not be used as waste incinerator. • Do not use any kind of flammable liquid for ignition. • During the loading do not bring the sack of the pellet in contact with the appliance.

  • Page 5: Reference Standards

    AIR HEATER PELLET STOVE BY GEKASMETAL • Keep this manual in a safe place, since it is an integral part of the product. If the product is sold or transferred to another user make sure that the manual will accompany the product.

  • Page 6: Installation Instructions

    AIR HEATER PELLET STOVE BY GEKASMETAL When the product reaches the end of its lifetime, it should not be disposed with the rest of urban wastes. Disposal of the product prevents negative environmental and health consequences derived from inappropriate disposal and allows the materials of the product to be recycled in order to achieve important energy and resource saving.

  • Page 7: Installation Area Requirements

    AIR HEATER PELLET STOVE BY GEKASMETAL The installation of the appliance in areas with high risk of fire is forbidden. The installation in the internal of domestic areas is, also, forbidden (except for the appliances with resistant function):  In areas where there are liquid fuel appliances of constant or non constant function which receive the combustion air in the area where they are placed, or ...

  • Page 8: Installation Of Swivel Or Fume Receptor

    AIR HEATER PELLET STOVE BY GEKASMETAL The placement of the fumes extraction pipes Φ80mm can be achieved whether on an installation with existing chimney (minimum surface 200cm² and with an inspection chamber on the for annual cleaning), or on an installation without existing chimney, with the use of a tee pipe (with cap) connection. The line horizontally reaches the outside of the building.

  • Page 9: Flue

    AIR HEATER PELLET STOVE BY GEKASMETAL  Temperature class,  Pressure class (leaktightness) which should be equal, at least to the required leaktightness of the appliance  Moisture resistance,  The class or stage of corrosion and the specifications of the material of the internal wall which contacts the fumes.

  • Page 10: Additional Requirements For Appliances Equipped With Electric Fan For Fume Discharge

    AIR HEATER PELLET STOVE BY GEKASMETAL  The flues should have, across their length, diameter no less than that of the connection of the extraction pipe of the appliance. Possible changes are allowed only on the entrance of the stove ...

  • Page 11: Flue Terminals

    AIR HEATER PELLET STOVE BY GEKASMETAL The use of sealing pipes is mandatory FIREPLACE Fireplaces, for the release of combustion products in the atmosphere, apart from the general requirements that are defined, they should:  Function with negative pressure (positive pressure is not allowed), ...

  • Page 12: Product Requirements For The Fume Extraction System

    AIR HEATER PELLET STOVE BY GEKASMETAL Area for the height of the mouth with inclination ( ß >10°) REFERENCE DESCRIPTION DISTANCE IN mm Calculated distance 90° from the roof surface 1300 Height over the ridge of the roof. The mouth of a pipe-in-pipe system should not be near obstacles that may create swirling zones or obstruct proper fume discharge and roof maintenance activities. Check for other ridges or skylights and attics.
  • Page 13 AIR HEATER PELLET STOVE BY GEKASMETAL According to article 2 No. 37 of the decree of 22 January 2008 regular maintenance includes interventions intended to minimize the damage of normal use, as well as troubleshooting of accidents which induce the need for first interventions. These interventions do not alter the structure of the installation or the target of use, according to the requirements of current technical regulations and the manual of use and maintenance provided by the constructor.

  • Page 14: Technical Characteristics

    AIR HEATER PELLET STOVE BY GEKASMETAL In case of detection of abnormalities the owner or his/her representative, should warn in writing, in the maintenance report, for the unsuitability of use of the appliance, until the restoration of safety conditions. The inspection and maintenance report should mention information related to the technician or company that performed the actions of inspection or/and maintenance, along with contact information, date and signature of the technician.

  • Page 15: Operation

    AIR HEATER PELLET STOVE BY GEKASMETAL CONTROLLER comes separately (unedited) with two screws. You place it on its base, on the top of the stove, with the assistance of a “key” 1. ON/OFF(ESC) button Single press: - Activates the boiler, - Within a menu, it causes exit from menu.
  • Page 16 AIR HEATER PELLET STOVE BY GEKASMETAL 3. Plus Button (+) Increase and navigation button Single press: - Enables the screen for room temperature settings. - Within a menu, it causes scroll up. - During the setting of a value, it causes increase of the value.
  • Page 17 AIR HEATER PELLET STOVE BY GEKASMETAL - Within a menu, it selects and opens the specific menu. - During the processing of a value, it records the value. Prolonged press: -In case the fuel storage is completely empty, it will empty the combustion chamber, resulting in the appearance of an error message, if the user attempts to refill it with the pressing of the ON/OFF(ESK) button .
  • Page 18 AIR HEATER PELLET STOVE BY GEKASMETAL After you connect the appliance to electric current, turn the switch, on the back of the appliance, on position 1. On the screen the following appear: Name - type of the appliance and operation program (i.e.
  • Page 19 AIR HEATER PELLET STOVE BY GEKASMETAL During this time, if the appliance perceives flame existence, then it moves to <PRE-OPERATION> phase. Otherwise, startup is being terminated and error E20 appears on the screen. The appliance perceives the existence of flame if there is fume temperature increase.

  • Page 20: Errors

    AIR HEATER PELLET STOVE BY GEKASMETAL <CONSTANT HOLD> ο When the area temperature equals the one requested (or slightly higher than 0,5 C), then the appliance enters <CONSTANT HOLD> phase for a few minutes. This happens because a solid fuel system has not the same ignition flexibility as a liquid or gas fuel system. Therefore, a common practice is the attempt for reduction of ignitions. To achieve this, the control system, after disabling the operation orders, enters a hold phase during which it preserves the flame, so that the return in <OPERATION>...
  • Page 21 AIR HEATER PELLET STOVE BY GEKASMETAL these phases. • The system does not return in function if the error has not been removed by the user. Ε21 High Fumes Fume temperature over the limit, for a • The boiler moves to <FINAL CLEANING> phase, if existing.
