Summary of Contents for Larsson & Jennings SAXON AUTOMATIC

  • Page 3 S A X O N A U T O M AT I C...
  • Page 4 www.larssonandjennings.com/support...

  • Page 5: Table Of Contents

    C O N T E N T S International Warranty Watch Specification Watch Features Operating Instructions Crown Positions Manual Winding Changing the Time Changing the Date Adjusting Straps & Bracelets Water Resistance Care...

  • Page 6: International Warranty

    I N T E R N AT I O N A L W A R R A N T Y Automatic watches from Larsson & Jennings are guaranteed for 5 years from date of purchase. The watch movement, hands and dial are the only components covered during this warranty period.
  • Page 7 I N T E R N AT I O N A L W A R R A N T Y The warranty does not cover the following: ∙ Damages, and/or malfunctioning of the watch after the terms of warranty. ∙ Damages, and/or malfunctioning of the watch, caused by unauthorised persons or its representatives.

  • Page 8: Watch Specification

    W AT C H S P E C I F I C AT I O N 9.85mm 39mm 20mm...
  • Page 9 W AT C H S P E C I F I C AT I O N Watch Saxon Automatic Movement ETA 2892.A2 / 21 Jewels 4Hz / 28’800 vph 42 hour static power reserve Case Back Exhibition / Mineral Glass...

  • Page 10: Watch Features

    W AT C H F E AT U R E S K E Y 1. Hours 2. Minutes 3. Sweeping Seconds 4. Date 5. Crown...

  • Page 11: Operating Instructions

    O P E R AT I N G I N S T R U C T I O N S Automatic watch movements generate their own power from the activity of the wrist while wearing the watch. The watch holds a power reserve of 42 hours when fully wound - this power reserve will gradually diminish when the watch is not being worn.

  • Page 12: Crown Positions

    C R O W N P O S I T I O N S...
  • Page 13 C R O W N P O S I T I O N S Position 1 Closed Position 2 Open, for manual winding Position 3 Date Change Position 4 Time Change...

  • Page 14: Manual Winding

    M A N U A L W I N D I N G Clockwise...
  • Page 15 M A N U A L W I N D I N G Unscrew crown to Position 2. When Power Reserve is depleted or the watch has stopped, wind the crown clockwise 5-10 times maximum. Stop winding when you feel some resistance, as over-winding may cause tension damage inside the movement.

  • Page 16: Changing The Time

    C H A N G I N G T H E T I M E...
  • Page 17 C H A N G I N G T H E T I M E Unscrew crown and pull the crown out to Position 4. Adjust the time by turning in either direction. Once you have changed the time, return the crown to Position 1 by pushing and screwing the crown back against the case.

  • Page 18: Changing The Date

    C H A N G I N G T H E D AT E Clockwise...
  • Page 19 C H A N G I N G T H E D AT E Unscrew the crown and pull the crown out to Position 3. Turn the crown clockwise, going through the date numbers to reach the correct date. Resetting the date will be required at the end of months that are shorter than 31 days, due to the 31 date wheel.

  • Page 20: Adjusting Straps & Bracelets

    A D J U S T I N G T H E C L A S P ( M i l a n e s e c l a s p) Insert the strap tool into the clasp gap. Gently pull down until flat to release the full clasp movement.
  • Page 21 A D J U S T I N G T H E C L A S P ( D e p l o y m e n t c l a s p) For premium leather straps with deployment clasps: To adjust length: Lift bar with lion engraving and select strap hole for clasp pin to go through.
  • Page 22 C H A N G I N G T H E S T R A P Securely hold the watch head, identifying the areas to insert the watch strap tool provided with your new strap.
  • Page 23 C H A N G I N G T H E S T R A P Insert the watch tool between the lug and the strap, placing the end of the tool on the adjustable spring bar. Once in position, manoeuvre the tool down to release the pin from the lug, where the strap will detach.
  • Page 24 C H A N G I N G T H E S T R A P Note: If you do not have a strap tool, please contact our support team at: support@larssonandjennings.com For further instructions, please see: www.larssonandjennings.com/support...
  • Page 25 R E M O V I N G L I N K S In order to remove links on a Larsson & Jennings watch with a linked bracelet it is highly recommended to go to a local jewellers who will be able to add or remove links to reach the desired size.

  • Page 26: Water Resistance

    W AT E R R E S I S TA N C E The Saxon Automatic watch is water resistant to 10ATM. Larsson and Jennings recommends following these guidelines for acceptable usage for the ATM ratings of this watch: 1 0 AT M : Activities such as showering, bathing, swimming in a pool and snorkelling are acceptable.
  • Page 27 W AT E R R E S I S TA N C E Note: The ATM rating only refers to watch heads, and not the strap. Leather straps should avoid contact with water or very high humidity atmospheres. For more information on what our water resistance ratings mean, please visit www.larssonandjennings.com/FAQs...

  • Page 28: Care

    C A R E The Saxon Automatic watch should not be exposed to heavy wear, abrasions or knocks. The watch contains a number of mechanical parts which can be damaged by excessive shocks to the watch. Hard metals, stones or aggregates will scratch the case.
  • Page 29 C A R E brush and warm fresh water, and gently brush around the exterior casing. Finish by wiping dry with a soft cloth. If the watch comes into contact with salt water or abrasive chemicals, ensure you clean the watch thoroughly with fresh water as above.
  • Page 30 Thank you for your purchase from Larsson & Jennings...
  • Page 31 Made in Switzerland www.larssonandjennings.com...
