Summary of Contents for Zachry INW-E295BT
- Page 1 Zachry Electronics INW-E295BT User Manual More Bluetooth Video File Play QQ Music Settings Prev Next IQIYI Video For the proper operation and safety of the machine,please read it before using.
- Page 2 E295BT, it’s easily manipulated, let you fully enjoy the music.Please read it before using. INW-E295BT is a intelligent operating system music controller launched only by our companywith good quality and reasonable price, powerful, simple interface and high-class. It is HD player, support multiple video formats to play movie.
- Page 3 Page Up / Page Down Security and maintenance 1、Security and maintenance 1.1.Power supply: AC90V~AC250V. 1.2.Please wiring follow the installation guide,if it is wrong connection,it will destroy the machine. 1.3.Please do not install it at some places where the temperature is above 50℃ or too humid. 1.4.Only can turn on the unit unless assuring all the cables are right connected.
- Page 4 Page Up / Page Down Security and maintenance 2.Security and maintenance 2.1.In stallation 1) Take down the terminals,wiring the cables to the terminals. 2 ）Install metal fastening into the back box and tighten the screws. 3 ）Please aim four square holes to drag hook and screw hole of metal fastening (as shown below:1.2.3.4)to install the machine,after they fit perfectly,put the...
- Page 5 Page Up / Page Down Wiring Introduction 2.3.Wiring Introduction： 1)Input power:power cable:1-2mm2 Single-stranded copper core 2)RJ45 network:LAN cable 3)RS485:LAN cable...
- Page 6 Page Up / Page Down Wiring Introduction 4)AUX audio input:audio cable(two-core shielded cable):Rvvp2×0.75. 5)Speaker(left/right channel)output:speaker cable:RVH2×100 RVH2×200 6)Subwoofer output::audio cable(two-core shielded cable): Rvvp2×0.75. 7)Speaker(left/right channel)output:speaker cable:RVH2×100 RVH2×200 8)FM radio antenna:single-stranded core cable,diameter is not less than 1mm, the length is not less than 1m.
- Page 7 Page Up / Page Down Functions Interface and Buttons Introduction 3、Functions Interface and Buttons Introduction Sleep Button Back Home Volume Volume down Power Switch RESET TF Card...
-
Page 8: Remote Control
Page Up / Page Down Remote Control 3.3. Remote Control 1. POWER press this button to power on,again (ON/OFF) is power off. POWER 2. MUSIC press this button to listen to music. MUSIC FILM RADIO PROG HOME 3. FILM press this button into film manager. MENU RETURN 4. - Page 9 Page Up / Page Down Remote Control 10. TV MODE press this button,it will display”Output mode”,”video output” and” audio output”,you can choose it. 11. MOUSE press this button to shift mouse operation 12. Prev/next song press this button when playing music,prev or next song,press for long is fast forward or fast backword.
- Page 10 Page Up / Page Down Features 1.Beautiful outlook:simplicity and nobility,7" touch screen,TFT 1024*600 HD resolution screen, Hi-Fi stereo,24 bit Hi-Fi audio output,easy-operation. 2.Network connection:standard RJ45 network port,built-in Wi-Fi. 3.Multi-operation:support USB/wireless keyboard and mouse,remote control,touch button and touch screen to operate.Support for RS485,Samba to share the online database,they can search sources among them.
- Page 11 Page Up / Page Down Features/ON-OFF 8. Play video:support 1080P,720P,RM,AVI,MP4,MOV,VOB,FLV,WMV,etc. 10.E-photo:you can browse the pictures easily(JPG,BMP,GIF,PNG),set your favorite picture as background. 11.FM Radio:FM manual/automatic select the channels,pre-set 30 channels,internet audio(listen to internet radio all over the world with different language). 12.recording:built-in microphone,you can record your message and storage.
- Page 12 Page Up / Page Down Main Interface Display 5.2.Main display interface:click the icon enter into the functions,or operate it on the remote control...
-
Page 13: Play Music
Page Up / Page Down Play music 5. Play music 1) After enter into music player,it will play music in local disk.if there is no file in local disk,it will play music from TF/USB. 2) Click”music”on the main interface to play music,you can choose “Local”,”TF”,”USB”,”AUX”, ”FM”... - Page 14 Page Up / Page Down Play video / browse picture / FM you can choose slideshow/edit/rotate left 5. Play video and browse picture /rotate right/crop/set picture as/details. Click”movie”into file list,there is on on the file is video,select one and play it,as shown as below: 5.5.FM radio: Others are picture,select one to browse,at Click”Radio”into it,as shown as below:...
- Page 15 FM / File Management / Recording Page Up / Page Down channel to delete and add it , as shown in below picture. ： 5.6. File Management Click”file management”enter into it,you can find all videos,audios,pictures,e-books and downloaded apks,select object file and long press,it will pop-up function menu,you can sort,copy,paste,cut,delete,rename,add new catalogue,etc,as shown as below.
- Page 16 Page Up / Page Down Recording / Camera(option) ： 5.7. Recording(option) Camera(option): Click”Recorder”enter into it,as shown as Click”camera”enter into it,as shown as below: below: More Bluetooth Video record your message Play File QQ Music Settings Prev Next IQIYI Video Click” to start recording,click to stop, If you want to take a picture,click“...
-
Page 17: Video Output
IQIYI Video The output mode should be the same as TV input signal,support double-screen display (INW-E295BT and TV),In HDMI output mode,pull out of the cable to exit TV-OUT. Note:if you switch the video play into TV-OUT,INW-E295BT will not display the video,it... - Page 18 Page Up / Page Down Browser/Timer switch ON/OFF Timer switch ON/OFF Click”App”into application list,click””clock” →set alarm→add alarm,as shown as below When INW-E295BT connecting internet Timer switch on:click→add alarm→switch or Wi-Fi,click”browser”,you can browse on→set time/audio/volume→OK. websites.As shown as below: Timer switch off:click→add alarm→switch...
- Page 19 Page Up / Page Down Timer switch ON/OFF / RS485 / Browser You can set any group ID and machine ID, when the group ID is 0000,you can control all the machines which the group ID is also 0000. Every machine has the only ID and cannot be changed.when the machine ID is not 0000 , the group ID and machine ID get matched.
- Page 20 Connect USB to the PC. When INW-E295BT is on,you can use USB The machine will automatically search data cable to connect INW-E295BT to PC,it will Wi-Fi which are nearby to you.click it popup “USB connected”,click”Turn on USB and automatically obtain an IP address, storage”, after connected,you can copy and...
- Page 21 Page Up / Page Down Settings etc. WIRESS&NETWORKS Display: Click settings→WIRELESS&NETWORKS You can adjust brightness,Contrast,saturation, →Wi-Fi wallpaper,screen adaption,Display output mode. Wi-Fi connection:After turn on the machine, it is on. Ethernet connection:Turn off the Wi-Fi,then connect it. Sound: You can adjust volume,mute,HDMI sound,...
- Page 22 Page Up / Page Down Settings Enable media scanning on TF/USB,check Account&sync: You can set individual account synchronize with the total space/available,Erase this storage, this machine,or more. etc. Location service: Apps: Google location service and Location&Google When install apps which are unknown search.
- Page 23 Page Up / Page Down Settings Language&input: Date&time Set language,keyboard,input,etc. set date,time and time zone. Backup&reset: If you want to”Factory data reset”,please click”back up my data” Developer options: USB debugging Development device ID Allow mock locations HDCP checking Desktop backup password Strick mode enabled...
- Page 24 Settings/Simple Troubleshooting Page Up / Page Down About device: Pointer location You can check system update,legal information, Show touches model number,Android vision,Baseband vision, Show screen updates kernel vision,build number,machine ID. Show CPU usage Force GPU rendering Window animation scale Transition animation scale Don't keep activities Background process limit Show all ANRs:...
- Page 25 Page Up / Page Down Simple Troubleshooting/device by yourse Note: 1. if the above solutions can not solve Reasons and s olutions. the problems,please consult with nearby 1 . ch eck the power supply wiri ng is r ight or not. display 2 .
- Page 26 When firmware upgrading,the data which are connect INW-E295BT to computer,press storage in INW-E295BT will be deleted , so and hold ” Forced Updates”, computer will before upgrading , please backup all the display data.In the progress of upgrading,the data...
-
Page 27: Product Specifications
Page Up / Page Down Product Specifications Product Specifications AC110V-AC220V 50Hz Screen display 7”touch screen,1024*600 HD resolution Power TV-OUT 1.0GHZ YPbPr、HDMI( option Multitouch interaction, Touch 25W+25W Output power screen capacitive-touch screen Frequency 20HZ-20KHZ Camera 200W camera(option) response WIFI、Ethernet 80DB 0.03% network Input 2GB DDRIII... - Page 28 Thank you for using Zachry products.
