Summary of Contents for Swing-N-Slide NE 4273
- Page 1 NE 4273 Picnic Table check out http://www.swing-n-slide.com for updates to these instructions. ASSEMBLY INSTRUCTIONS Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232...
- Page 2 When the equipment is taken out of service, it must be disassembled and disposed of in such a way that no unreasonable hazards will exist at the time the set is discarded. Important! Additional Safety Instructions for all Swing-N-Slide Playground Equipment. Save this instruction sheet in the event the manufacturer needs to be contacted.
- Page 3 This product is intended for single family home/residential use only and not intended for use in any public setting. Placement in any public setting constitutes a misuse of this product. IMPORTANT! ADDITIONAL REQUIRED SAFETY INSTALLATION INSTRUCTIONS According to ASTM requirements, all kits must be anchored to the ground and, if the unit has a climbing rope, the rope end must be anchored to the ground. If soil conditions permit stakes to be pulled out easily, cementing into ground is necessary.
-
Page 4: Hardware Included
(64) 2" deck screws (36) 2-1/2" deck screws LUMBER LIST NOTE: (2) 1'' x 4'' x 14'' SWING-N-SLIDE MANUFACTURES MULTIPLE KITS FROM A CENTRAL WOOD PACK. DUE TO THIS YOU MAY (4) Shutters RECEIVE EXTRA BOARDS THAT THIS PROJECT DOES NOT REQUIRE. -
Page 5: Tools Required
TOOLS REQUIRED SAFETY GLASSES HAMMER SQUARE PHILLIPS BIT & DUST MASK ELECTRIC DRILL CIRCULAR SAW TAPE MEASURE PICNIC TABLE COMPONENTS Picnic Table Plan (2) Table Supports (1) Plan... - Page 6 Picnic Table ssembly Instructions Fig. 1 (10) 1'' x 4'' x 40'' 1-1/4'' screws per board Fig. 1a (10) 2'' screws (10) 2'' screws 2'' Deck Screw 1-1/4'' Deck Screw Table Assembly 1. Assemble the Picnic Table Top as shown in (Fig. 1). Note: Make certain to install hardware in the manner shown as this will make steps later on in the assembly process much easier.
- Page 7 Picnic Table ssembly Instructions Fig. 2 (4) 1'' x 4'' x 40'' 1-1/4'' screws per board (4) 1'' x 4'' x 40'' 1-1/4'' screws per board Fig. 2a (2) 1'' x 4'' x 22-1/4'' 1-1/4'' screws per board 1-1/4'' Deck Screw Bench and Leg Assemblies 1.
- Page 8 Picnic Table ssembly Instructions 2'' screws per joint 1'' x 6'' x 15-5/16'' Fig. 3 Drape Cut Board 65˚ 65˚ 1'' x 6'' x 47-1/2'' 2'' screws per joint Fig. 3a UNDERSIDE VIEW 16-3/16'' FLUSH 6-5/8'' 6-5/8'' 21-1/2'' FLUSH 2'' Deck Screw Pinic Table End Assemblies 1.
- Page 9 Picnic Table ssembly Instructions Fig. 4 3-15/16'' 1'' x 6'' x 39-9/16'' 2'' screws per joint Drape Cut Board 5-1/8'' Fig. 4a 4-7/16'' 4-7/16'' FLUSH 2'' screws per joint (2) Shutters 2'' Deck Screw Pinic Table End Assemblies Cont. 1. Install Drape Cut Boards as shown in (Fig. 4). 2.
- Page 10 Picnic Table ssembly Instructions FLUSH 2-1/2'' screws Fig. 5 per board FLUSH 2-1/2'' screws per board Fig. 5a 2-1/2'' screws FLUSH per board FLUSH 2-1/2'' screws per board 2-1/2'' Deck Screw Picnic Table Final Assembly 1. Attach Picnic Benches to one of the Picnic Table Ends as shown in (Fig. 5). 2.
- Page 11 Picnic Table ssembly Instructions FLUSH Fig. 6 2-1/2'' screws per joint FLUSH UNDERSIDE VIEW Fig. 6a (2) Table Supports 3/4'' Truss Head screws FLUSH per Support 2-1/2'' Deck Screw 3/4'' Truss Head Screw Picnic Table Final Assembly Cont. 1. Attach Picnic Table Top as shown in (Fig. 6). 2.
- Page 12 Questions???... Call our Customer Service Department at 1-800-888-1232 © PlayCore Inc. 2009 Printed In USA LA 6101...
