BAS WiFiAgent Quick User Manual

Indoor usb wi-fi antenna

Enlarged version

Indoor USB Wi-Fi antenna

WiFiAgent

QUICK USER GUIDE

Thank you for choosing the Indoor USB WiFi antenna WiFiAgent! It has been

developed by a team of engineers determined to continue the tradition of

excellence and innovation of REMO-Electronics products.

The Indoor USB Wi-Fi antenna WiFiAgent is made of high-quality materials

in accordance with thoroughly detailed design. The quality management system

is certi ed by ISO 9001:2011.

The antenna can be installed either on a table, or a shelf, or nearby a

window, or any other horizontal surface. You won't even need any tools!

The WiFiAgent will improve the signal strength, as well as steadiness and

accuracy of data transmission on 2400MHz wireless network. Built-in Wi-Fi

adapter can provide the connection speed up to 150Mbps. A practical range of c

onnection up to 1000 meters. Built-in Wi-Fi antenna adapter of WiFiAgent is

compatible with Microsoft Windows XP/7/8/10 and diﬀerent OS dased on Linux.

Start

Step 1

Step 2

Step 3

Step 4

Step 5

Table of Contents

Do you have a question about the WiFiAgent and is the answer not in the manual?

Page 1 Indoor USB Wi-Fi antenna WiFiAgent QUICK USER GUIDE Thank you for choosing the Indoor USB WiFi antenna WiFiAgent! It has been developed by a team of engineers determined to continue the tradition of Step 3 excellence and innovation of REMO-Electronics products.
Page 2 In order to gain maximum signal, we recommend to use special utilites, Step 7 which are able to scan Wi-Fi network and display detailed information for each wireless network that are within range of WiFiAgent. As an example, we can specify the following utility (for installation on portable or stationary PC): for Windows: WirelessNetView (www.nirsoft.net/utils/wireless_network_view.html)
Page 3 Select the network to which you want to connect If necessary, enter the password..or Network key Use information about the signal level for setting the direction of the “WiFiAgent” Con rm the network and its parameters. Click on the “General”...
Page 4 Create your own Wi-Fi network (Access Point Mode) Before switching to Access Point mode - disable the Windows rewall Select mode: The Access Point REALTEK USB Wireless LAN Utility Run the utility by double-clicking Wait for switching the operation mode left-click Select Network Name (SSID) Select Channel...
