Yarvik PDV103 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Important Safety Instructions
W arning: To reduce the risk of electric shock, do not remove the front or back cover. There are
no user-serviceable parts inside. Refer servicing to qualified personnel.
Warning: To prevent fire or electric shock hazard, do not expose the unit to rain or moisture.
D o not expose the adapter or portable DVD player to water (dripping or splashing). Objects
filled with liquids, such as vases, should not be placed on the unit.
K eep the portable DVD player away from direct sunlight and heat sources such as radiators or
stoves.
D o not block the ventilation openings. Slots and openings on the unit are provided for ventila-
tion. The openings should never be blocked by placing your portable DVD player on a cushion,
sofa or other similar surface.
D o not place the portable DVD on an unstable cart, stand, tripod, bracket or table. The unit may
fall, resulting in possible damage or injury.
Never place heavy or sharp objects on the LCD panel or frame.
O nly use the AC adapter included with portable DVD player. Using any other adapter will void
your warranty.
T he plug of AC adapter is used as the disconnect device; the disconnect device must remain
easily accessible.
Unplug the adapter from the outlet when the unit is not in use.
Dispose of batteries in an environmentally-responsible manner.
C AUTION: Danger of explosion if battery is installed incorrectly. Only use replacement batteries
of the same or equivalent type.
W ARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive
heat such as sunshine, fire or the like.
WARNING: Excessive sound pressure from earphones or headphones can cause hearing loss.
W ARNING: Only use attachments/accessories specified by the manufacturer. The portable DVD
player is powered by the AC adapter. The AC adapter is used as the disconnect device; the
disconnect device must remain easily accessible.
C aution: Danger of explosion if battery is installed incorrectly. Only use replacement batteries of
the same or equivalent type (lithium battery).
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote the sustain-
able reuse of material resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was purchased. They can
take this product for environmental safe recycling.
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the PDV103 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yarvik PDV103

Summary of Contents for Yarvik PDV103

  • Page 1 English Important Safety Instructions W arning: To reduce the risk of electric shock, do not remove the front or back cover. There are no user-serviceable parts inside. Refer servicing to qualified personnel. Warning: To prevent fire or electric shock hazard, do not expose the unit to rain or moisture. D o not expose the adapter or portable DVD player to water (dripping or splashing). Objects filled with liquids, such as vases, should not be placed on the unit. K eep the portable DVD player away from direct sunlight and heat sources such as radiators or stoves. D o not block the ventilation openings. Slots and openings on the unit are provided for ventila- tion. The openings should never be blocked by placing your portable DVD player on a cushion, sofa or other similar surface. D o not place the portable DVD on an unstable cart, stand, tripod, bracket or table. The unit may fall, resulting in possible damage or injury. Never place heavy or sharp objects on the LCD panel or frame. O nly use the AC adapter included with portable DVD player. Using any other adapter will void your warranty. T he plug of AC adapter is used as the disconnect device; the disconnect device must remain easily accessible. Unplug the adapter from the outlet when the unit is not in use. Dispose of batteries in an environmentally-responsible manner. C AUTION: Danger of explosion if battery is installed incorrectly. Only use replacement batteries of the same or equivalent type. W ARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like. WARNING: Excessive sound pressure from earphones or headphones can cause hearing loss. W ARNING: Only use attachments/accessories specified by the manufacturer. The portable DVD player is powered by the AC adapter. The AC adapter is used as the disconnect device; the disconnect device must remain easily accessible.
  • Page 2 English WARNING Safety Precautions RISK OF ELECTRIC SHOCK DO NOT OPEN W arning: This digital video disc player employs a laser system. Use of controls, adjustments, or the performance of procedures other than those specified herein may result in hazardous radiation exposure. W arning: To prevent direct exposure to the laser beam, do not open the enclosure. Visible laser radiation when open. Warning: Never stare directly into the laser beam. Caution: Do not install this product in a confined space such as a bookcase or similar unit. W arning: When the unit is used by a child, parents must make sure the child understands the entire contents of the instruction book and ensure that the battery is used correctly at all times. W arning: If the battery overheats, swells or ruptures, please stop using the battery and contact the service centre to obtain a replacement. W arning: Do not charge the battery in a location with insufficient ventilation such as on a mattress, sofa, cushion or soft carpet. W arning: We are not liable for damages resulting from incorrect use of the battery or failure to heed our warning instruction label on the battery case. Warning: The length of any USB cable connected to the USB port must not exceed 250 mm. Notes on Copyrights: I t is forbidden by law to copy, broadcast, show, broadcast via cable, play in public, or rent copy- righted material without permission. T his product features the copy protection function developed by Macrovision. Copy protection signals are recorded on some discs. When recording and playing the pictures on these discs, pic- ture noise will appear. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovi-...
  • Page 3 English Identification of Controls Main Unit Left/Fast Backword Right/Fast Forword 3. Enter Down/Reverse Skip Up/Forward Skip 6. DVD/DVB-T 7. VOL- / VOL+ 8. Setup 9. Source 10. Stop 11. Play/pause 12. Open 13. SD/MMC/MS 14. USB 15. AV Out 16. Earphone Socket 17. Sound out 18. On/Off 19. DC in 9-12V 20. ANT. Insert the battery 1. Open the battery door. 2. Insert battery. Hole NOTES: Remove battery during storage or when you are not using the DVD player for a long time.
  • Page 4 English Identification of Controls Remote control unit 1. PLAY/PAUSE 6. REPEAT Press PLAY/PAUSE once to pause playback, Press REPEAT during playback to select a pressing PLAY/PAUSE second time will resume desired repeat mode. the playback. : you can play a chapter/title/all on a disc. : you can play a track/all on a disc. 2. STOP : you can select Repeat one/Repeat When this buttom is pressed once, the unit folder play mode on a disc. records the stopped point, from where playback 7.A B will resume if ENTER is pressed after wards. But if STOP button is pressd again instead of To repeat a segment: press AB once to set the ENTER button, there will be no resume function. starting point for repeat segment, press it again to set an end point, and the player will repeat 3. Reverse Skip the segment from the start to the end point. : G o to previous chapter/ track to the 8. PROGRAM beginning.
  • Page 5 English Identification of Controls 18. ANGLE/EPG Press ANGLE will change the view angle, on Remote control unit DVDs that support this feature. DVB show EPG information. : You can press PROGRAM repeatly to JPEG 19. SETUP select the slide show mode, the are 16 types slide show. Accesses or removes setup menu. 9. SOURCE 20. 10+ BUTTON DVD/CARD/USB. In order to select a track 10 or greater, first press 10+, For example; select track 12, first press 10. TITLE 10+, and then press number 2 button. : Return to DVD title menu. : Switch to TV or Radio program. 21. RETURN Return to upper menu or close menu. 11. DVD/DVB Switch to DVD or DVB mode. BUTTON Press BUTTON allow skipping back at 12.
  • Page 6 English SETUP Menu Setting System Setup Page P ress SETUP button to get the setup menu. Use direction buttons to select the preferred item. After finishing settings, press SETUP again to normal display. System Setup TV System Selecting the color system that corresponds to your TV when AV output. This DVD Player is compat- ible with both NTSC and PAL. PAL - Select this if the connected TV is PAL system. It will change the video signal of a NTSC disc and output in PAL format. NTSC - Select this if the connected TV is NTSC system. It will change the video signal of a PAL disc and output in NTSC format. Screen Saver This function is used to turn the screen saver on or off. TV Type Selects the aspect ratio of the playback picture. 4:3 PS: if you have a normal TV and want both sides of the picture to be trimmed or formatted to fit your TV screen. 4:3 LB: if you have a normal TV. In this case, a wide picture with black bands on the upper and lower portions of the TV screen will be displayed. 16:9: wide screen display. Password Input user password. Default password is 0000. Rating After input correct password, you can change parental level. Default Restore the factory setting of setup menu.
  • Page 7 English Language Setup Page Language setup You can select OSD language, and select audio/subtitle/menu language of DVD discs if available. Also you can select font type for mpeg4 subtitle. SETUP Menu Setting Audio Setup Page The function is usel to select the SPDIF output: SPDIF off, SPDIF/RAW,SPDIF/PCM.
  • Page 8 English Video Setup Page You can change the video setting: brightness, contrast, hue, saturation. Speaker Setup Downmix: LT/RT: When playing a 5.1ch DVD disc, the LS/RS/Center channel audio will output through both L and R channel. STEREO: When playing a 5.1ch DVD disc, the LS channel audio will output only through L channel, RS channel audio will output only through R channel, Center channel audio will output through both L and R channel. Channel Guide TV Channels: Enter TV channels list. In TV channels list, press DISPLAY key can sort programs. Radio Channels: Enter radio channels list. In radio channels list, press DISPLAY key can sort programs. Channels Class: Set channels class: Favor, Movie, News, Show. Channels Edit: Edit channels: rename, move, delete.

  • Page 9: Dvb Setup Menu

    English SETUP Menu Introduction DVB SETUP MENU System Config TV Setting: Selects TV system and TV type. Video Setting: Change the video setting: brightness, contrast, hue, saturation. Audio Setting: Selects coaxial digital out mode: OFF, RAW, PCM. Language: Selects OSD language. Parent Control: Change password and set channel lock. Default password is 0000. Time Setting: Set time zone. System Info: Informations about the update data, tuner, F/W version and model version. Installation Auto Scan: Auto search all available channels. Manual Scan: Manual search channels. Default Setup: Reset DVB factory setting. Game There are three games:BoxMan,Burning Tetris and Hit Rat. Select “ENTER” to play.
  • Page 10 English EPG (Electronic Program Guide) The DVB-T player provides you an Electronic Program Guide to take a fast preview of live broadcasts from each TV channel in advance of watching it in full screen. 1 Press EPG <EPG> . An Electronic Program Guide Menu appears on the screen, with a TV channel menu to the left and corresponding live broadcast of the selected program to the right. 2 Press “ ” button to more digital teletext provided by the selected channel. Press “ ”button to return to program list. 3 Press “ ”button / “ ” button to toggle through each TV channel and to see its live broadcast. *To exit from this page ---Press“EPG” button. Digital Teletext If the program you are watching broadcasts digital teletext, the DVB-T player can display teletext.The content of digital teletext varies according to the program provider. It could be pictures and sound for the program, pages of information on the programs, the weather, the news or other options. Press TTX button, the teletext window appear on the screen. Press #$ button, turn over the teletext information.
  • Page 11 English Parameters and specifications Electronical parameters Item Standard requirement Power requirements : AC 100-240 V , 50/60 Hz Dimensions (Approx.) : 204(L)X165(W)X41(H)MM Power consumption : <10W Weight (Approx.) : 0.77 kg Operating humidity : 5 % to 90 % VIDEO OUT : 1 Vp-p (75 ) AUDIO OUT : 1.4 Vrms (1 KHz, 0 dB) System Laser : Semiconductor laser, wavelength 650 nm Signal system : NTSC / PAL Frequency : 20Hz to 20 kHz(1dB) Signal-to-noise ratio : More than 80 dB (ANALOG OUT connectors only) Dynamic range : More than 85 dB (DVD/CD) Note: Design and specifications are subject to change prior notice.
