The Bathlift people
OPERATING INSTRUCTIONS
AQUAJOY SAVER
AQUAJOY JUNIOR SAVER
SUITABLE FOR ADULTS & CHILDREN
First point of contact is always as follows unless supplied
by a Local Authority or Dealer.
CONSETT BUSINESS PARK
TEL:
FAX:
Email:
AND
AQUAJOY by DRIVE
CONSETT
COUNTY DURHAM
DH8 6BN
(0044) 01207 501555
(0044) 01207 599789
info@aqua-joy.com
www.aqua-joy.com
1
Version 8

Advertisement

loading
Need help?

Need help?

Do you have a question about the junior saver and is the answer not in the manual?

Questions and answers

Summary of Contents for Aquajoy junior saver

  • Page 1 The Bathlift people OPERATING INSTRUCTIONS AQUAJOY SAVER AQUAJOY JUNIOR SAVER SUITABLE FOR ADULTS & CHILDREN First point of contact is always as follows unless supplied by a Local Authority or Dealer. AQUAJOY by DRIVE CONSETT BUSINESS PARK CONSETT COUNTY DURHAM...

  • Page 2: Quick Check List

    QUICK CHECK LIST CHARGING YOUR HANDCONTROL Before you first use your Bathlift, please charge your battery handcontrol for 12 hours. Please continue to charge your battery hand control after every bath or for at least 12 hours per week. You cannot overcharge your battery hand control. If the battery hand control indicator light flashes red it means you do not have sufficient charge to use your Bathlift.

  • Page 3: Safety Precautions

     If you are unable to take a bath on your own, use the bathlift only under supervision.  The Aquajoy Saver must only be used to assist one person getting in and out of the bath at a time, do not use it for any other means.

  • Page 4: Standard Components

     Hand Control – Please place this on charge for 12 hours before using your Aquajoy Saver Bathlift for the first time. Connect the hand control to the battery charger and plug the charger into a mains power supply - OUTSIDE THE BATHROOM and allow the battery to charge for a minimum of 12 hours.
  • Page 5 How to install your AquaJoy SAVER Bathlift Base Section The Aquajoy Saver can be easily installed in two sections: Seat Section  Seat section including actuator  Base section Fig 1 How to install your Aquajoy Saver Bathlift  Please ensure your bath is clean and dry before installing your bathlift.
  • Page 6 PLEASE PAY SPECIAL ATTENTION TO THE FOLLOWING: PLEASE ENSURE THAT BOTH THE ACTUATOR LATCH AND THE ACTUATOR BRACKET ARE FULLY ENGAGED BEFORE OPERATION AND THE PIN IS SECURELY IN PLACE ON THE LOWER BRACKET. Top Latch Closed: Bottom Bracket Also ensure that Push to close and Closed: Close and Push the pin is...
  • Page 7 How to bathe with your Aquajoy Saver  After installing your bathlift and connecting the hand control, simply press and hold the UP button to raise the seat (Fig 10).  Raise the seat until it is level with the top of the bath, then take your finger off the UP button.
  • Page 8 How to remove your AquaJoy SAVER Bathlift  Empty the water from the bath.  Press and hold the Down button to lower the bathlift to its lowest position (Fig  DISCONNECT THE HAND CONTROL!  Fold the side flaps onto the seat (Fig ...
  • Page 9 How to charge your Aquajoy Saver Hand Control  For safety reasons, please ensure that you do not charge your battery hand control in your bathroom.  Connect the battery hand control cable to the charger cable by matching connections together.
  • Page 10 10,000 cycles if used and maintained correctly in the environment for which it has been designed. However, in order to maximise the life of the Bathlift and to ensure optimum reliability, performance and safety, AquaJoy by Drive recommends that you replace your bathlift handcontrol, actuator and charger in accordance with your product warranty.
  • Page 11 ROUTINE CHECK LIST TO CHECK THAT THE FOLLOWING PARTS ARE IN GOOD WORKING ORDER, PLEASE FOLLOW THE PROCEDURES BELOW:- BATTERY Attach your battery hand control to your bathlift, press the Up button, the bathlift should go up. Press the Down button and the bathlift should go down. When you are pressing either button, if the indicator light flashes red on the hand control, you need to recharge your battery hand control.
  • Page 12 To clean the bathlift, simply use a normal household cleaner and a damp cloth. The AQUAJOY SAVER BATHLIFT can be used with or without covers. The standard covermats can be easily removed and washed in your washing machine up to a maximum temperature of 60°.
  • Page 13 Can I / How do I wash my covermats? The AQUAJOY SAVER / JUNIOR SAVER can be used with or without covers. The standard covermats can be easily removed and washed in your washing machine up to a maximum temperature of 60°. We recommend that you wash your cover mats after every two to three baths if possible to avoid any dirt or residue building up.
  • Page 14 Technical Data Specifications for AQUAJOY SAVER Max.user weight: 160kg (24st/330lbs) Total weight: 10.98kg Seat section only: 4.80kg Base section only: 3.06kg Actuator: 3.12 kg Seat height (Min/Max): 7.8cm/46.5cm Actuator power input: 13.2V : 1300mAh Environmental protection: IP66 Hand Control (Battery)
  • Page 15 Symbols used on labels and instructions Resistance of a product Recyclable Storage temperature range to a spray jet Sealed against the Dispose correctly Read instructions carefully effects of shower Caution 13.2V DC Direct current Battery state indicator...
  • Page 16 PLEASE NOTE: ONLY REMOVE THE ACTUATOR IF YOU WOULD LIKE TO INSTALL AND REMOVE THE BATHLIFT IN 3 SECTIONS AND IF YOU HAVE BEEN TRAINED BY AQUAJOY by DRIVE ON HOW TO DO THIS) Seat Section  Seat section including actuator Base Section ...
  • Page 17 How to re-attach the Actuator to the SAVER Bathlift:  Ensure the actuator latch at the back of the seat is open (Fig 10)  Place the bottom end of the actuator in the locator hole on the bottom of the bathlift frame (Fig 11) ...
  • Page 18 The Full Cover provides extra comfort Swivel and Slide Unit (AQJA0012) The Aquajoy Swivel and Slide transfer disk will help you to get on and off your bathlift easily and safely. It is ideal for people who have difficulties shuffling into the centre of the bathlift and allows them to slide and turn into the correct position to bathe.
  • Page 19 FITTING OF ACCESSORIES TO FIT & REMOVE THE COVERS If you have covermats for your Bathlift, please fit them before you bathe. To fit the one piece seatbase and backrest cover stretch the two plastic corners (on the reverse of your cover) over the two corners of your Bathlift backrest - just as you would with a fitted bed sheet then slip the two sideflaps of the seat into either side of the seat cover.
  • Page 20 The pommel will now sit in place Simply lift upwards and the pommel will release If any holes are required to be punched into the AquaJoy Bathlift covers to accommodate the pommel, this will be completed on site by AquaJoy prior to dispatch.
  • Page 21 TO FIT & REMOVE THE WING SUPPORTS ON THE BACKREST Simply locate the guides on the wings into the location points on either side of the backrest. Simply lift upwards from the location points and the wing supports will release. TO FIT THE CHEST &...

  • Page 22: Warranty

    (as with a belt). To secure the user, simply insert the lap harness clip into the buckle. Warranty AquaJoy by Drive guarantees this product for three years on the frame and 1 year on the battery hand control, charger and accessories. For extended warranties and maintenance packages, please contact AquaJoy by Drive.
