Page 1: Quick Start Guide
LAN-Cell Gateway Series Secure Cellular Data Gateway Quick Start Guide Model 1xMG-401 November 2004... - Page 2 The LAN-Cell is the ideal gateway for all data passing between cellular carrier’s data networks and LAN-attached devices. By integrating NAT, firewall and VPN capability, Proxicast’s LAN- Cell is a complete security solution that protects your intranet, efficiently manages data on your network, and intelligently controls the use of cellular data network access.
-
Page 3: Front Panel Connections
Antenna Attach the supplied antenna to the SMA connector located on the side of the LAN-Cell, near the Proxicast logo. Use only the antenna supplied with your unit. Be sure to tighten the antenna connector fully to ensure a reliable cellular connection. - Page 4 Configuring the LAN-Cell Activating the Cellular Modem The embedded cellular modem in the LAN-Cell must be “activated” with the designated cellular service provider before it can establish a cellular data connection. You must subscribe to a carrier’s cellular data plan before activating the LAN-Cell. The LAN-Cell’s cellular modem is pre-configured for a specific cellular service provider at the time of manufacture.
- Page 5 Step 7: Wait 5 seconds, then type: AT+MIN? and press return. The modem will respond with the programmed MIN. Step 8: Disconnect the serial cable and return the switch to the RUN position. Your LAN-Cell is now ready to be configured for your specific application. Please see the User’s Guide for additional information.
- Page 6 Cellular Modem If your LAN-Cell was purchased directly from Proxicast along with an unlimited cellular data plan, then the LAN-Cell’s cellular modem is ENABLED and configured as NAILED UP (always on) and the unit is ready for use. Otherwise, the LAN-Cell’s embedded cellular modem is NOT ENABLED by default.
- Page 7 Troubleshooting PROBLEM CORRECTIVE ACTION None of the LEDs Make sure that you have the correct power adapter connected to the LAN- turn on Cell and have plugged it into an appropriate power source. Check all cable connections. If the LEDs still do not turn on, you may have a hardware problem. In this case, you should contact your vendor.
- Page 8 ON then OFF the Cellular Modem screen. It may also be caused if other Cellular Modem parameters do not match those required by the carrier. Contact your cellular service provider or Proxicast for more information on carrier specific settings. Unable to perform You must have the LAN-Cell in a location with cellular service.
