Ethernet Gateway Set-Up

Please refer to the following pages for detailed instructions on the correct procedures for setting up the Ethernet
gateway.
Please note the following settings should be used:
Module IP
Default Gateway IP
Subnet Mask
Socket Timeout
Converter Mode
Char Timeout
Port Number
Server IP
Watchdog Interval
Baud Rate
Data Bits
Stop Bits
Parity
RS232/RS485
Serial Reply Timeout
RS485 On Delay
RS485 Off Delay
Building a be er future together
Enviro UK Ltd., Commerce Court, Cutler Heights Lane, Bradford, BD4 8NW.
01274 662226 | sales@envirouk.com | www.envirouk.com & www.becsuk.com
The IP address being allocated to the gateway
The default gateway IP address being allocated.
If this is not available (enter zeroes in these fields)
The desired subnet mask
90
0
0
N/A
N/A
15 Minutes
4800
8
1
None
RS485
25
5
0
