- Page 1 Enhanced UBA Product user guide Click here to edit Document Version: May 2016 © Chorus 2016...
-
Page 2: Table Of Contents
4.8 Handover link 4.9 Backhaul VARIANTS OF ENHANCED UBA ENHANCED UBA FEATURES 6.1 Interleaving 6.2 Interleaving settings for Enhanced UBA O 6.3 PPPoA modem support 6.4 Tail Extension SERVICE SPECIFICATION TARGETS 7.1 Exceptions to service specifications AGGREGATION AND HANDOVER OF TRAFFIC 8.1 Geographic availability... - Page 3 9.14.2 Handover links cable standards 9.14.3 ONBOARDING TO ENHANCED UBA 10.1 Prerequisites 10.2 Enhanced UBA set-up guide 10.3 Coverage area mapping and remapping 10.4 Mapping and remapping process service level agreement 10.5 Coverage area mapping process 10.6 Mapping process charge 10.7 Remapping process...
- Page 4 14.2 Other Chorus services CONNECTION AND PREMISES NETWORKING 15.1 Connection option tasks END CUSTOMER EQUIPMENT REQUIREMENTS 16.1 Overview 16.2 Key capabilities 16.3 CPE requirements Add document name here | Sept 2016...
-
Page 5: Introduction
With Enhanced UBA you can provide your customers with a range of own-branded, broadband enabled services and applications such as voice over internet protocol (VoIP) and internet access. The Basic UBA variant EUBA 0 can be found described in this product user guide. 2 Benefits 2.1 Key benefits of Enhanced UBA: ... - Page 6 Enhanced UBA is an intermediate input service that you can combine with your own network, or other services, to provide a range of own-branded broadband enabled services and applications such as voice over internet protocol (VoIP) and internet access. It is designed to serve your customers with either single or multiple access devices such as computers, consoles or telephones.
-
Page 7: Enhanced Uba Components
4.2 Enhanced UBA access Enhanced UBA consists of a DSL data connection from the ETP at your customer’s premises to the DSLAM at the local exchange or cabinet. While Enhanced UBA is optimised for ADSL2+, it is possible to use ADSL1 modems (see section 11 ‘end... -
Page 8: Local Aggregation Path
In the context of Tail Extension a Remote handover point is an EAS located in a coverage area which is not the coverage area in which the Enhanced UBA access tail is provided. If you don’t have the ability to hand over traffic at the local handover point you can purchase Tail Extension (or another backhaul service) to take the Enhanced UBA traffic to a remote handover point that you’ve nominated. -
Page 9: Variants Of Enhanced Uba
Enhanced UBA 90 is suitable for G.711 codec. All four variants of Enhanced UBA can be provided with a voice service, such as Baseband. However, the Baseband Copper and Baseband IP services are not provided as part of the Enhanced UBA service and are as defined in the Baseband Service Description and product user guide. -
Page 10: Interleaving Settings For Enhanced Uba O
6.3 PPPoA modem support PPPoA modem support is a feature, available on all Enhanced UBA variants, that allows a modem configured for Basic UBA to be connected to an Enhanced UBA tail and deliver a Add document name here | Sept 2016... -
Page 11: Tail Extension
PPPoA modem support is an optional feature provided in accordance with the WSA. 6.4 Tail Extension Tail Extension is a backhaul service that extends an Enhanced UBA access tail from the local handover point to a remote handover point that you’ve nominated. For more detail on how Tail Extension works refer to section 4.6. - Page 12 These service specifications are design targets and should be used by you when developing end-to-end real time and best efforts applications. However the Enhanced UBA service will likely only form a small part of any such end-to-end application. Actual performance is not guaranteed as it is subject to external influences.
-
Page 13: Exceptions To Service Specifications
(LAP) dimensioned to support the throughput rate for Enhanced UBA of both best efforts and real time traffic. If you do not wish to (or are unable to) collect Enhanced UBA traffic from the local handover point and would like to transport the traffic to a remote handover point where you have already established a handover link, you may do so using one of the following: •... -
Page 14: Geographic Availability
The location of handover points and related coverage areas may change in the future as the ADSL2+ network is rolled out. Please refer to Clause 17.1.4 of the UBA STD Operations Manual for more detail on our obligation to notify changes to coverage. -
Page 15: Relationship With Other Products
8.3 Relationship with other products Enhanced UBA can be combined with a number of Chorus input products, such as handover links, UBA Backhaul, and Commercial Colocation. You can choose to use Enhanced UBA with or without Tail Extension. Enhanced UBA traffic can also share a handover link with High Speed Network Service (HSNS). -
Page 16: How Enhanced Uba Works
802.1q Ethernet service between and end customer’s premises and a defined handover point. 9.1 Class of service design A key characteristic of the Enhanced UBA product is the ability to provide multiple class of service (CoS) each with your own traffic contract. Add document name here | Sept 2016... - Page 17 Figure 5: Quality of service classes standard • Enhanced UBA real time is mapped to class 0, and identified by 802.1p tags of 6. • Enhanced UBA best efforts is mapped to class 5, and identified by 802.1p tags of...
-
Page 18: Enhanced Uba Protocol Stack
Untagged or incorrectly tagged traffic will be discarded. 9.2 Enhanced UBA protocol stack As illustrated in the figures below, the Enhanced UBA protocol stack is designed to support the CoS based design, specifically the simultaneous delivery of real time and best efforts traffic. -
Page 19: Enhanced Uba Ethernet Architecture
Figure 8: Enhanced UBA protocol stack with PPoA modem support 9.3 Enhanced UBA Ethernet architecture Enhanced UBA is an Ethernet service with a VLAN based architecture. Each Enhanced UBA access tail connection is carried over dedicated VLANs from your customer’s... - Page 20 Our network will translate the 802.1q VLAN ID to the 802.1ad identifiers. • The Enhanced UBA VLAN will support both best efforts traffic and real time traffic as long as that traffic is tagged correctly. Incorrectly marked traffic, including no markings at all, will be discarded.
- Page 21 If their LAN is not using 802.1q then the modem or gateway must tag the traffic according to the appropriate class of traffic. The figure below shows the format of the Ethernet frames for tagging Enhanced UBA traffic: Figure 11: Enhanced frames format Tag protocol identifier (TPID) is a 16 bit field containing the Ethertype.
-
Page 22: Traffic Management
Note: across multiple handovers for the same service provider there may be replication of S-VIDs on different handovers. 9.4 Traffic Management The Enhanced UBA service specifications for real time and best efforts traffic are managed through our network through a number of traffic management techniques, as shown below:... - Page 23 2 full length frames and a 200 byte VoIP packet to be sent without discard. At an aggregate level the Enhanced UBA traffic is managed as following: • All real time traffic is aggregated per service provider and strictly prioritised over the local aggregation path.
-
Page 24: Pppoa Modem Support
Figure 13: Best efforts aggregate traffic contract 9.5 PPPoA modem support PPPoA modem support is a feature that allows a modem configured for Basic UBA to be connected to an Enhanced UBA tail and deliver a best efforts channel. The diagram below shows how the PPPoA modem support feature will be supported on... -
Page 25: Tail Extension
2 would have a VLAN id of 5/1806. 9.6 Tail Extension Tail Extension is a backhaul service that extends an Enhanced UBA access tail from the local handover point to a remote handover point that you’ve nominated. The following diagram shows how Tail Extension works:... -
Page 26: Ip Addressing
8.5. 9.7 IP addressing Enhanced UBA is an Ethernet Layer 2 tail service optimised to carry real time and best efforts IP traffic. All Layer 3 IP characteristics and features, including IP addressing, are your responsibility. -
Page 27: Dhcp Option 82 Features
• PPP over Ethernet (PPPoE). This would be supported by many legacy and current generation devices utilised to deliver Basic UBA services, as well as many L2TP gateways. However, you must ensure these devices support priority-tagging and 802.1Q VLAN marking of the Ethernet frames. -
Page 28: Upstream Speed
This Port ID is independent of the ASID or SVID/CVID (VLAN identifiers) although there will only be a 1:1:1 mapping between these values. The Port ID is returned in the OO&T order request for the service. Port IDs will change if the physical port changes, e.g. under some fault conditions, change addresses and cabinetisation (when the end customer is moved to a new DSLAM). -
Page 29: Security
‘leak’ between end customers. Since each end customer uses the same 802.1q VLAN, which is then translated into a unique VLAN within the Chorus network, it is not possible for an end customer to spoof a neighbour’s VLAN. - Page 30 deliver a maximum 1500 byte IP packet from the end customer, or a 1492 byte IP packet carried over PPPoE. Note: that PPPoE is optional. 802.1 q (VLAN) settings: VLAN ID of 10 is required 802.1 p (Ethernet priority flags) settings: Best effort-class frames are tagged ‘0’.
-
Page 31: End Customer Interface Security Settings
You must establish a handover link at a minimum of one handover point before you’re able to connect any Enhanced UBA end customers. A handover link is required to hand over Enhanced UBA traffic to you. A handover link is made up of two parts: •... - Page 32 • Handover fibre – which runs from the MOFDF to your equipment. Refer to the Handover Connection product user guide for more information. Our handover link is a single service that includes both the Handover Connection and the Handover fibre. For your handover link, we provides the Handover Connection.
-
Page 33: Service Provider Interface For Pppoa Modem Support
MRU – 1500B Authentication protocol – PAP Multilink PPP – controlled by service provider Enhanced UBA port ID (identical to DHCP option 82 insert) - inserted as the first vendor attribute in the PPPoE active discovery initiation (PADI). Ethernet MTU 1526 Bytes Jumbo frames to support PPPoE and 1500B IP packet. -
Page 34: Service Provider Interface Security Settings
It may not be unique among multiple handover points. The S-vid/C-vid returned in OO&T is for the main Ethernet channel, not PPPoA modem support. 802.1 q (VLAN) settings: assigned by Chorus 802.1 p (Ethernet priority flags) settings: Best effort-class frames are tagged ‘0’. -
Page 35: Onboarding To Enhanced Uba
Online Order and Tracking (OO&T) capability in place • Online Fault Management (OFM) capability in place • Any other criteria set out in the UBA STD for Enhanced UBA 40kbps, 90kbps and 180kbps; • Any other criteria required by Chorus. -
Page 36: Coverage Area Mapping And Remapping
The Enhanced UBA set-up guide is a checklist to guide you through the steps required to set-up Enhanced UBA for the first time. Each step in the checklist refers to this product user guide for more detail. The Enhanced UBA set-up guide is available on our website. -
Page 37: Coverage Area Mapping Process
10.6 Mapping process charge There is no charge to complete the initial coverage area mapping process. However, any subsequent requests will be billed as per the price list set out under the UBA STDs. 10.7 Remapping process Remapping occurs when you want to change your existing coverage area mapping. This could be caused by the addition of a new handover link or replacement of Tail Extension with another backhaul service. - Page 38 Handover link Secondary UBA Backhaul Secondary UBA Backhaul The following scenarios are not in scope as current business rules for UBA Backhaul specify that you can only connect a coverage area to one primary link. Existing Terminating Services New Terminating Services...
-
Page 39: Remapping Process Charge
If you request Enhanced UBA that cannot be delivered because there is no service coverage then this request will be rejected. - Page 40 The minimum specifications for the Enhanced UBA variant. • Exchange/cabinet capability, e.g. does the exchange have ADSL2+ DSLAMs. The following table shows the maximum attenuation for Enhanced UBA variants, and the respective derived minimum speeds: Service variant Minimum speed up/down...
-
Page 41: Faults
You must conduct fault pre-diagnosis to establish that the fault is not within your responsibility prior to reporting the fault to us. For Tail Extension, faults will either be logged against the Enhanced UBA access tail or a handover link. For more details please refer to the Premises Networking – Assure Activities Service Description. -
Page 42: Service Provider Tier 1 Testing
If the number of re-syncs is less than the number shown in the table below, you should advise your end user that the there is no apparent fault with the network and your service is performing satisfactorily. LQD test length LQD spontaneous resyncs 24 Hours >... -
Page 43: Pricing
The following list details the major pricing components for Enhanced UBA. This list is illustrative only; for the binding terms relating to these pricing components including the price please refer to the UBA STD Price List or the price list as set out on the Chorus website. -
Page 44: Ancilliary Charges
Where the handover ID of the handover link is located at the same exchange as the Enhanced UBA access tail, then Tail Extension step A will be applied. This will result in a $0 charge for Tail Extension monthly charge. -
Page 45: Billing
Chorus Services Agreement price list. 14 Billing Enhanced UBA will be billed as a Chorus service as per existing services currently offered to you by Chorus. If you’re using electronic billing, the billing details for Enhanced UBA will be presented on your electronic bill. -
Page 46: Other Chorus Services
UBA plan name i.e. Enhanced UBA 40kbps. The charges for Tail Extension will appear on the you bill under the Enhanced UBA access tail access service identifier (ASID); therefore sorting an electronic bill by ASID will ensure that the Enhanced UBA access tail is associated with the appropriate Tail Extension charge. -
Page 47: Connection Option Tasks
(exchange/cabinet visit required). 4. If there is a connection and wiring requested additional wiring charges will apply. For more details please refer to the UBA final review on the Commerce Commission website. 15.1 Connection option tasks... -
Page 48: End Customer Equipment Requirements
16 End customer equipment requirements 16.1 Overview The end customer equipment required for Enhanced UBA utilises bridged Ethernet over ATM. The detailed technical specifications are described in section 4.11. An equipment guide is available on our website. 16.2 Key capabilities Generally these capabilities are provided by the modem or gateway device, but this is not mandated. -
Page 49: Cpe Requirements
802.1p setting. Traffic that is not marked as best efforts (‘0’) or real time (‘6’) will be discarded. 16.3 CPE requirements Changes to CPE when moving from Basic UBA to Enhanced UBA Function Basic UBA end customer...
