Summary of Contents for MSC TC12
- Page 1 Remote visualizing solutions Thin Client Hardware Technical Manual and Installation Instructions Issue 1.00 12.6.2006 MSC Tuttlingen GmbH Rudolf-Diesel-Straße 17 78532 Tuttlingen Germany Tel. +49 7461 925-276 +49 7461 925-268 E-Mail sales-tut@msc.de www.msc-ipc.com...
- Page 3 Non-compliance may have an impact on the environment. Intended use The products of MSC Tuttlingen GmbH may only be used for the applications described in the technical documents, and only in connection with devices or components from other manufacturers which have been approved or recommended by us.
- Page 4 78532 Tuttlingen Germany Areas of use Products of MSC Tuttlingen GmbH meet the applicable, harmonized, European standards for the respective area of applications. Fitting conditions The fitting conditions and safety notes in the submitted document must be adhered to when commissioning and operating the products.
-
Page 5: Table Of Contents
TM: TC - Hardware Contents Contents Characteristics ..........................5 Features ............................5 Use ..............................6 Nomenclature..........................6 Overview ............................7 Installation ............................9 Unpacking and checking the delivery contents ................9 Storing and transporting.........................9 Installing ............................9 2.3.1 Temperature..........................10 2.3.2 Ventilation ............................10 2.3.3 Installation position........................11 2.3.4 Installation cutout .........................11 2.3.5 Mounting and sealing ........................12 Built-In = Built-in unit ........................12... - Page 6 Contents TM: TC - Hardware Mechanical Dimensions ......................33 TC12-B ............................33 5.1.1 Front ............................33 5.1.2 Device dimensions ........................34 5.1.3 Fitting dimensions ........................36 TC12-S ............................37 5.2.1 Front ............................37 5.2.2 Device dimensions ........................38 5.2.3 Adapter plate ..........................40 TC17-B ............................
- Page 7 Fig. 4-3: Microphone input and audio output ..................31 Fig. 5-1: TC12-B [Built-In] – Front ......................33 Fig. 5-2: TC12-B [Built-In] – Device dimensions ...................35 Fig. 5-3: TC12-B [Built-In] – Fitting dimensions ..................36 Fig. 5-4: TC12-S [Stand-Alone] – Front ....................37 Fig. 5-5: TC12-S [Stand-Alone] –...
- Page 8 TC. TC - Hardware Technical Manual and Installation Instructions Article no. 69 00 105 © Copyright MSC Tuttlingen GmbH, 78532 Tuttlingen, 2006 Subject to change without notice. Page 4 of 48 Rev. 1.00 dated 12.6.2006...
-
Page 9: Characteristics
TM: TC - Hardware Characteristics Characteristics Features Remote solutions are becoming more and more important for the operation and visualization of machines. Particularly the central software installation and maintenance of a few remote servers lead to considerable cost savings compared to the application of several panel PCs with the respective total software installation. -
Page 10: Use
Characteristics TM: TC - Hardware Operation terminals of TC line are completely configured "Thin Clients" for most different server environments e.g. RDP, Web or extended configurations. The Embedded operating system is particularly adapted to the ETX compatible computer platform and integrated into a HTML browser or terminal server client. -
Page 11: Overview
TM: TC - Hardware Characteristics Overview Device type Front panel Side view TC12-B [Built-In] TC12-S [Stand-Alone] TC12 a b c Display: 12.1" Built-in unit Add-on unit Dimensions: 315 mm x 280 mm Installation depth: 77 mm Depth: 85 mm Mounting with clamping jaws... - Page 12 Characteristics TM: TC - Hardware This page is left intentionally blank! Page 8 of 48 Rev. 1.00 dated 12.6.2006...
-
Page 13: Installation
TM: TC - Hardware Installation Installation Unpacking and checking the delivery contents Unpacking • Check the packaging of the TC for transport damages. • Remove the packaging carefully in order to avoid damages. Save the original packaging for a possible new transportation of the TC. Keep also the supplied documents. -
Page 14: Temperature
• Provide sufficient volume for the air exchange in control cabinet/panel. The free space around the TC must be at least 50 mm, at the rear side a free space of 20 mm is permissible. Example: TC12-B The following is valid correspondingly for other built-in versions. -
Page 15: Installation Position
The vertical installation as well as deviations up to ± 30° in the below indicated directions are permitted. For deviations from vertical installation it is to be considered that no accumulation of heat arises in the interior of the housing. Example: TC12-S [Stand-Alone] The following is valid correspondingly for all versions. +30° –30°... -
Page 16: Mounting And Sealing
Sealing on the back side is not interrupted and goes round the border of the plate: Round-cord of sponge rubber, Ø 3 mm, stuck in a groove with milling depth of 2 mm. Example: TC12-B The following is valid correspondingly for other built-in versions. -
Page 17: Stand-Alone = Add-On Unit
• Attach the housing coupling to the adapter plate. • Screw on the adapter plate with mounted equipment flange on the rear-mounted part of housing. Example: TC12-S The following is valid correspondingly for other add-on versions. Rear-mounted part of housing... -
Page 18: Providing Readiness Of Operation
Installation TM: TC - Hardware Providing readiness of operation Fail-safe connections for ensuring trouble-free operation: Use only shielded cables and metallic connectors for all signal connections. Screw down or lock all plug connectors. This improves the electrical shielding. Do not install signal lines in the same cable ducts as high voltage lines. -
Page 19: Connecting To Power Supply
Grounding bolt M4x10 at the interface sheet steel [Built-In] or flat pin 6.3x0.8 at the adapter plate [Stand-Alone] on the rear of the housing Warning View on rear of the housing e.g. TC12-B [Built-In] e.g. TC12-S [Stand-Alone] Grounding point Grounding point... -
Page 20: Using Peripheral Devices
TM: TC - Hardware Using peripheral devices The devices of MSC Tuttlingen GmbH offer by means of their peripheral interfaces the possibility to connect different components. When using standard peripheral devices (e.g. at the USB port) you have to note that their electromagnetic interference immunity is often only sufficient for office environments. -
Page 21: Commissioning And Operating
General requirements Limitation of liability All technical specifications and approvals apply only to expansions approved by MSC Tuttlingen GmbH. No liability can be accepted for impairment of functions caused by the use of devices and components from other manufacturers. All modules and components are electrostatically sensitive. -
Page 22: Opening The Device And Closing It Again
Commissioning and Operating TM: TC - Hardware 3.1.2 Opening the device and closing it again Notice: Only remove the interface sheet steel [Built-In] or the adapter plate [Stand-Alone] for exchanging Compact-Flash card and battery. Caution TC should remain closed. Do not loosen any further screws at the housing. Example: TC17-S [Stand-Alone] The following is valid correspondingly for all versions. -
Page 23: Back-Up Battery
TM: TC - Hardware Commissioning and Operating 3.1.3 Back-up battery The battery that is installed on the base board provides Real Time Clock and CMOS memory with a current, in order to permanently save system information, even if the board is separated from the supply. -
Page 24: Flash Memory
Exchanging the Compact-Flash card If data are destroyed on the Compact-Flash card, it is to be replaced by a new one, that can be got by MSC Tuttlingen GmbH. To replace the Compact-Flash card, follow these steps: • Observe the precautions in section "General requirements". -
Page 25: Connecting Peripheral Devices
3.2.1 Interfaces Access to ports Connections to peripheral devices are placed on the front under the covering and on the rear of the housing. Example: TC12-B [Built-In] The following is valid correspondingly for all versions. Front view Rear view Ethernet Grounding + –... -
Page 26: Peripherals
Commissioning and Operating TM: TC - Hardware Identification label The identification label outside on the interface sheet steel [Built-In] or inside on the adapter plate [Stand-Alone] shows the configuration of the interfaces. Ethernet Erdung Power MIC-Input Audio (Mono) Line-Out (Stereo) Fig. -
Page 27: Operating The Tc
TM: TC - Hardware Commissioning and Operating Operating the TC Touchscreen Membrane keyboard Fig. 3-4: Front view [e.g. TC17-S] 3.3.1 Membrane keyboard a b c The membrane keyboard on the front panel contains four function keys and the status LED. Fig. -
Page 28: Touchscreen
Setting/Operating the TC 3.4.1 Operating system and software According to your order MSC Tuttlingen GmbH configures the TC as Win Client, Web Client or extended Client, equipped with operating system and software based on that. Description for handling of the operating interface Successively instructions will be written according to these software packages. -
Page 29: Terms Of Warranty
TM: TC - Hardware Commissioning and Operating Terms of warranty For the devices of MSC Tuttlingen GmbH, the agreements determined in the General Terms and Conditions (AGB) are valid. All wearing parts are excluded from warranty. Wearing parts are parts which are subject to maintenance or routine check-up: all fans, all drive units, display backlight, battery. - Page 30 Commissioning and Operating TM: TC - Hardware This page is left intentionally blank! Page 26 of 48 Rev. 1.00 dated 12.6.2006...
-
Page 31: Technical Data
Component Description Indication Basic system Front Aluminum printed in MSC design / silk-screen printing in RAL 5013 (cobalt blue) customer-specific design is possible membrane keyboard with 4 function keys Status LED Operating panel Touchscreen resistive-analogue 12.1" / SVGA (800 x 600 pixel) - Page 32 Technical Data TM: TC - Hardware Component Description Indication Configuration as … /Win Win Client Operating system Windows CE 5.0 Software Microsoft Terminal Client (RDP) .NET Web Services CITRIX Client ICA Web Client /Web Operating system Embedded Linux Software Browser Mozilla Java VM2 (JDK 1.4x) extended Client Operating system...
- Page 33 TM: TC - Hardware Technical Data Supply voltage 24 VDC / 18...36 VDC (SELV) Power consumption Device with 12.1" display 40 W typ. Device with 17.0" display 70 W typ. Mechanical dimensions depending on device variation (see chapter "Mechanical Dimensions") depending on equipment Weight (see section "Device-specific"...
-
Page 34: Device-Specific
Specific dates for different versions of the TC line are described in this section. Type indication Article no. Front Display Touch Housing Other* Weight TC12-B/Win 63 09 U22 4.15 TC12-B/* TC12-S/Win 63 09 U21 4.95 TC12-S/* TC17-B/Win 63 09 U42 6.75... -
Page 35: External Connections
TM: TC - Hardware Technical Data External connections 4.3.1 USB ports 4 pin USB connector, Type A, to connect USB peripheral devices. USB Type A, Meaning 4 pin VCC USB Voltage supply USB– Data USB+ Data Ground Fig. 4-1: Note: 2 x USB 1.1 at front, covering IP 65 2 x USB 1.1 at rear There are only 3 x USB with maximum current consumption. - Page 36 Technical Data TM: TC - Hardware This page is left intentionally blank! Page 32 of 48 Rev. 1.00 dated 12.6.2006...
-
Page 37: Mechanical Dimensions
• 12.1" display • Membrane keyboard - 4 function keys 250 x 188.5 - LED a b c • 2 x USB under covering • Touchscreen Fig. 5-1: TC12-B [Built-In] – Front Rev. 1.00 dated 12.6.2006 Page 33 of 48... -
Page 38: Device Dimensions
Mechanical Dimensions TM: TC - Hardware 5.1.2 Device dimensions TC12-B [Built-In] 272.5 15.5 Page 34 of 48 Rev. 1.00 dated 12.6.2006... -
Page 39: Fig. 5-2: Tc12-B [Built-In] - Device Dimensions
39.5 15.5 General tolerances ISO 2768 – mK Fig. 5-2: TC12-B [Built-In] – Device dimensions Note: Positioning the clamping jaws It is recommended to place the enclosed clamping jaws at the positions marked in the figure to fix the device. -
Page 40: Fitting Dimensions
Mechanical Dimensions TM: TC - Hardware 5.1.3 Fitting dimensions TC12-B [Built-In] Recommended installation cutout Fig. 5-3: TC12-B [Built-In] – Fitting dimensions Page 36 of 48 Rev. 1.00 dated 12.6.2006... -
Page 41: Tc12-S
• 12.1" display • Membrane keyboard - 4 function keys 250 x 188.5 - LED a b c • 2 x USB under covering • Touchscreen Fig. 5-4: TC12-S [Stand-Alone] – Front Rev. 1.00 dated 12.6.2006 Page 37 of 48... -
Page 42: Device Dimensions
Mechanical Dimensions TM: TC - Hardware 5.2.2 Device dimensions TC12-S [Stand-Alone] Page 38 of 48 Rev. 1.00 dated 12.6.2006... -
Page 43: Fig. 5-5: Tc12-S [Stand-Alone] - Device Dimensions
TM: TC - Hardware Mechanical Dimensions TC12-S [Stand-Alone] General tolerances ISO 2768 – mK Fig. 5-5: TC12-S [Stand-Alone] – Device dimensions Rev. 1.00 dated 12.6.2006 Page 39 of 48... -
Page 44: Adapter Plate
Scale 1:1 Material thickness: 2.5 mm Fig. 5-6: TC12-S [Stand-Alone] – Adapter plate Note: When selecting a housing coupling (an equipment flange) it is to be ensured that the tube internal diameter is at least 40 mm. -
Page 45: Tc17-B
TM: TC - Hardware Mechanical Dimensions TC17-B 5.3.1 Front • TC17-B Built-In = Built-in unit • 410 mm x 370 mm • 17.0" display • Membrane keyboard - 4 function keys - LED • 2 x USB under covering • Touchscreen 341 x 273.5 a b c Fig. -
Page 46: Device Dimensions
Mechanical Dimensions TM: TC - Hardware 5.3.2 Device dimensions TC17-B [Built-In] 362.5 16.5 Page 42 of 48 Rev. 1.00 dated 12.6.2006... -
Page 47: Fig. 5-8: Tc17-B [Built-In] - Device Dimensions
TM: TC - Hardware Mechanical Dimensions TC17-B [Built-In] 362.5 338.5 188.5 40.5 16.5 General tolerances ISO 2768 – mK Fig. 5-8: TC17-B [Built-In] – Device dimensions Note: Positioning the clamping jaws It is recommended to place the enclosed clamping jaws at the positions marked in the figure to fix the device. -
Page 48: Fitting Dimensions
Mechanical Dimensions TM: TC - Hardware 5.3.3 Fitting dimensions TC17-B [Built-In] Recommended installation cutout Fig. 5-9: TC17-B [Built-In] – Fitting dimensions Page 44 of 48 Rev. 1.00 dated 12.6.2006... -
Page 49: Tc17-S
TM: TC - Hardware Mechanical Dimensions TC17-S 5.4.1 Front • TC17-S Stand-Alone = Add-on unit • 410 mm x 370 mm • 17.0" display • Membrane keyboard - 4 function keys - LED • 2 x USB under covering • Touchscreen 341 x 273.5 a b c Fig. -
Page 50: Device Dimensions
Mechanical Dimensions TM: TC - Hardware 5.4.2 Device dimensions TC17-S [Stand-Alone] Page 46 of 48 Rev. 1.00 dated 12.6.2006... -
Page 51: Fig. 5-11: Tc17-S [Stand-Alone] - Device Dimensions
TM: TC - Hardware Mechanical Dimensions TC17-S [Stand-Alone] General tolerances ISO 2768 – mK Fig. 5-11: TC17-S [Stand-Alone] – Device dimensions Rev. 1.00 dated 12.6.2006 Page 47 of 48... -
Page 52: Adapter Plate
Mechanical Dimensions TM: TC - Hardware 5.4.3 Adapter plate TC17-S [Stand-Alone] for mounting a housing coupling Scale 1:1 Material thickness: 2.5 mm Fig. 5-12: TC17-S [Stand-Alone] – Adapter plate Note: When selecting a housing coupling (an equipment flange) it is to be ensured that the tube internal diameter is at least 40 mm.
