Summary of Contents for Arbitron 1000-1160
- Page 1 EQUIPMENT MANUAL, ENCODER: 1000-1160 ©2010 Arbitron Inc. Document #: 1050-1473 Date: July 2010 Revision: For Arbitron Encoder Model: 1000-1160-xx 1U SGE Analog Encoder, RoHS Compliant...
-
Page 2: Document
Arbitron Encoder Model: 1000-1160-xx © 2010 Arbitron Inc. All rights reserved. This document may not be reproduced, in whole or part, without the express written consent of Arbitron Inc. This document and the information contained within is intended for Arbitron Inc. employees, customers, or authorized recipients only;... -
Page 3: Table Of Contents
Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx Table of Contents CONTACTS ............................6 1.1..........................6 NITED TATES 1.2......................6 UTSIDE THE NITED TATES 1.3..............................6 EGAL DISCLAIMER AND LIMITATION OF LIABILITY ..............7 WARNINGS ............................8 INTRODUCTION/OVERVIEW ......................9 4.1. - Page 4 Figure 6: DB9 Pinouts for Remote Bypass Control..............15 Figure 7: DB9 Pinouts for Remote Alarm Status Monitoring ............15 Figure 8: Status and Control Relay Connection Scheme.............. 17 Figure 9: Rear Panel of Arbitron RoHS Compliant Analog SGE with Time Decoder Option ..26 ©2010 Arbitron Inc.
- Page 5 Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx Table of Tables Table 1: DB9 Pinouts for Remote Monitoring of Encode/Bypass Status........12 Table 2: DB9 Pinouts for Remote Control of Encode/Bypass Status........... 14 Table 3: DB9 Pinouts for Remote Monitoring of Alarm Status ........... 15 Table 4: Encoder Overheat Behavior....................
-
Page 6: Contacts
1000-1160-xx CONTACTS If you need assistance or have any questions, please contact or call: 1.1. NITED TATES For any questions regarding this manual, please contact Arbitron as indicated below: For Radio: • Email: EncodingOperations@arbitron.com • Call: 410.312.8123 For Other Media: •... -
Page 7: Disclaimer And Limitation Of Liability
Arbitron Encoder Model: 1000-1160-xx DISCLAIMER AND LIMITATION OF LIABILITY By your use, receipt, and/or installation of the Arbitron Inc. encoders, you expressly acknowledge and agree to the foregoing: Disclaimer of Warranties. YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT USE OF ARBITRON INC. ENCODERS AND THIS EQUIPMENT MANUAL IS AT YOUR SOLE RISK AND THAT THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PERFORMANCE, ACCURACY AND EFFORT IS WITH YOU. -
Page 8: Warnings
Encoder, DO NOT expose this unit to rain or moisture. Due to the danger of personal injury, electrical shock, or damage to the instrument, ONLY Arbitron authorized service personnel shall gain access to the inside of the Studio Grade Encoder. DO NOT disconnect the earth ground from the power cord since this is a very important safety feature. -
Page 9: Introduction/Overview
XLR connectors. The Arbitron encoder listed on the title page of this manual has been designed to meet the requirements of the European Union's directive 2002/95/EC, commonly known as RoHS (Restriction of Hazardous Substances) Compliance. -
Page 10: Suggested Placement In Audio Chain Installation
Arbitron Encoder Model: 1000-1160-xx In AM radio stations, Arbitron recommends that the encoder is installed after the final audio processor (i.e. Orban Optimod, Telos Systems’ Omnia, or others) to take advantage of the more consistent audio leveling found at this point in the broadcast chain. In FM stations, Arbitron recommends that the encoder be installed after a pre-processor and before the final audio processor (i.e. -
Page 11: Figure 3: Rear Panel Of Arbitron Rohs Compliant Analog Sge (With Time Decoder Option Installed)
Figure 3. Figure 3: Rear Panel of Arbitron RoHS Compliant Analog SGE (with Time Decoder Option installed) Balanced XLR pinouts for the Arbitron SGE are as follows (See Figure 4): •... -
Page 12: Figure 5: Db9 Pinouts For Remote Bypass Monitoring
Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx 2. Connect the female end of an XLR cable to the connector marked A OUT on the back of the SGE. Connect the male end of this same cable to the input connector on the device to receive the encoded program material. -
Page 13: Operations
LACING THE NCODER IMPORTANT: Before the installation of this encoder is considered complete, Arbitron requires that a quality analysis check be performed on the encoded audio. The time required per encoder is minimal. Please call your Arbitron contact to arrange this test. -
Page 14: Table 2: Db9 Pinouts For Remote Control Of Encode/Bypass Status
Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx 6.3.2. Master Bypass While the SGE is powered, pushing the front panel Bypass/Enable push button to the ‘out’ position causes the SGE to bypass encoding. This effectively routes the audio input connectors to their corresponding output connectors. -
Page 15: Larm Tatus Emote Onitoring
Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx Figure 6: DB9 Pinouts for Remote Bypass Control 6.4. LARM TATUS EMOTE ONITORING The encoder provides the means to remotely monitor its error status. This is provided via the DB9 connector on the rear panel labeled BYPASS MONITOR—the same connector that... -
Page 16: Theory Of Operation For The Status And Control Relays
Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx The pins are connected to an internal relay of the encoder. The relay contacts are rated at 0.3A max, 24VDC. The alarm/status relay connections are set by the following conditions: •... -
Page 17: Using The Lcd Menu
5. Time board status message (e.g., “No Time Board Expected”). 6. Two numbers displayed as “XXXXXXXXXX XXXXXX” The first number is provided for Arbitron internal use only. The second number is the encoder serial number. 7. Internal temperature of the unit in degrees Celsius, displayed as “Temperature XX C”... -
Page 18: Encoder Overheat Behavior
VERHEAT EHAVIOR Arbitron encoders are designed to withstand heat at tolerances similar to those of other studio- grade broadcasting equipment. When properly installed in a climate-controlled environment as described in Section 5, the encoder should experience no overheat issues. Should your encoder LCD display an “Over Temp”... -
Page 19: Document
Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx 7.1.2. Signal to Noise Ratio Typically -80 dBu over a 20Hz-20kHz bandwidth 7.1.3. Gain +0.4dB over 20Hz-20kHz 7.1.4. Input Impedance User Selectable 600Ω, balanced terminated (“600”) or 10kΩ, balanced bridging (“HI”) 7.1.5. -
Page 20: Alarm ( Relay ) Specifications
Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx 7.2. LARM RELAY PECIFICATIONS 7.2.1. Absolute Maximum Voltage Input 24VDC or 24VAC 7.2.2. Absolute Maximum Current Input 300 mA 7.3. OWER PECIFICATIONS 7.3.1. Voltage 100 – 240 VAC 7.3.2. Current 1.4 Amps maximum... -
Page 21: Nvironmental Pecifications
Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx 8.2. NVIRONMENTAL PECIFICATIONS 8.2.1. Temperature Ranges Operating: 0-45 C/32-115 F Ambient Storage: 0-70 C/32-158 F Ambient Internal: 0-69 C/32-156 F (indicated on LCD Display in degrees Celsius) 8.3. LOCK CCURACY ±1.71 Minutes per year at 0 - 40... - Page 22 Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx ©2010 Arbitron Inc.
-
Page 23: Appendix A Using The Optional Time Decoder Input
Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx Appendix A Using the Optional Time Decoder Input ©2010 Arbitron Inc. - Page 24 Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx ©2010 Arbitron Inc.
- Page 25 Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx A. Using the Optional Time Decoder Input The SGE’s internal clock, just like any other clock, can drift. Many encoder models use an optional Time Decoder Input to reduce the overall clock drift to match that of the station clock.
-
Page 26: Figure 9: Rear Panel Of Arbitron Rohs Compliant Analog Sge With Time Decoder Option
CLOCK CODE IN Figure 9: Rear Panel of Arbitron RoHS Compliant Analog SGE with Time Decoder Option A.2. Confirming Whether the SGE Time Decoder is Enabled To verify that the SGE Time Decoder Input is enabled, once power is applied to the SGE, follow these steps: 1. - Page 27 Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx When the encoder first boots up, it synchronizes its internal clock with the Time Decoder Input using a maximum allowed clock drift of 15 minutes. Once a successful synchronization has occurred, in future synchronization events the maximum clock drift used to synchronize the internal clock will be 15 seconds.
- Page 28 Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx A.4. LCD Messages Related to Time Update If an error occurs when the encoder attempts to communicate with the Time Decoder Input or attempts to synchronize its internal clock, this is indicated via the Encoding Status LED and a message on the LCD.
- Page 29 Description: A problem was detected when attempting to synchronize the SGE internal clock. The encoder will be in bypass mode, and the Encoding Status LED will be flashing RED/OFF. Corrective Action: Contact Arbitron. • No Time Board Expected Description: The time synchronization functionality is disabled.
- Page 30 Equipment Manual Document # 1050-1473 Rev. D Arbitron Encoder Model: 1000-1160-xx • Station Time OK Format EBU • Station Time OK Format IRIG • Station Time OK Format SMPTE • Station Time OK Format ESETC89 • Station Time OK Format ESETC90 Description: Any of these messages can appear when the encoder is synching its internal clock and are reports of normal behavior.
