Uninterruptible power supply 13.7VDC - 2A

Made in France

In accordance with our policy of continuous improvement of our products, the information contained in this manual may be subject

to change without notice. ATLS can not be held liable for errors contained in this document, for incidental or consequential

The products of the ALTEC range are designed and made in France by the company ATLS

Green light for the sector information

Red light for low battery information

MOUNTING DIRECTION

damages relating to the supply, the quality or the use of this document.

ALTEC is a registered trademark of ATLS

N O T I N S 0 U K 0 0 0 0 5 5 - V 1 . 0 1

I N S T A L L A T I O N G U I D E

PROTECTED AGAINST :

- Overvoltage

- Overcurrent

- Short circuits

- Reverse polarity

- Deep discharge of the

battery

Non-contractual picture

Need help?

Do you have a question about the AL02 ECO and is the answer not in the manual?

Page 1 ATLS can not be held liable for errors contained in this document, for incidental or consequential damages relating to the supply, the quality or the use of this document. The products of the ALTEC range are designed and made in France by the company ATLS ALTEC is a registered trademark of ATLS...
Page 2: Safety Instructions
AL02 ECO can still deliver up to 1.75A. In case of prolonged power failure, the AL02 ECO has a deep discharge detection that cuts the battery when the voltage across its terminals falls below 9VDC.
Page 3 WIRING SELV Secondary circuit with safety extra-low voltage Tamper circuit for opening and removal. Before wiring the tamper, check if the circuit does not exceed 60VDC/0,1A. The output power failure « ERR. OUT (ACin)» goes from 0V to an open state during a power failure.
Page 4: Technical Features
BATTERIES DESTRUCTION The battery backup of the AL02 ECO is not supplied by ATLS. However, do not dispose of batteries in your trash, it is forbidden to cremate, bury them or throw them into landfills. Dispose batteries according to the current laws and regulations. Please contact relevant authorities for further information on the arrangements put in place in your region to collect, to recycle and to dispose of used batteries.
