Fireside CFB60 Installation Manual

Crossfire brass burners 60k – 120k btu system with flkv12. 121k - 249k btu systems with flkv34 and flkv34fit180. 250k - 299k btu match lit system with dflkv34 and dflkv34fit250. 300k+ btu match lit system with dflkv34 and dflkv34fit300
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation Manual
Crossfire Brass Burners
B
R
A
S
S
B
U
R
N
E
R
S
www.firesidexpressions.com | 1.888.986.1535 | support@firesidexpressions.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CFB60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fireside CFB60

  • Page 1 Installation Manual Crossfire Brass Burners www.firesidexpressions.com | 1.888.986.1535 | support@firesidexpressions.com...
  • Page 2 General Warnings and Information ..................3 Selecting a location for your fire feature .................4 Construction of enclosure ......................4 General Fire Pit Installation .......................4 Media Installation ........................5 Fire Feature Operation ......................6 Lighting Instructions ........................6 Maintenance ..........................6 Troubleshooting .........................7 Warranty ............................7 INSTALLATION FOR ALL MODELS 60K –...
  • Page 3 PARTS LIST FOR CERTIFIED MODELS CROSSFIRE BRASS BURNER MATCH LIT SYSTEMS Model # CFB60LP: CFB60LP burner, plate or pan, lava rock Model # CFB60NG: CFB60NG burner, plate or pan, lava rock Model # CFB120LP: CFB120LP burner, plate or pan, lava rock, gas reducing orifice Model # CFB120NG: CFB120NG burner, plate or pan, lava rock, gas reducing orifice Model # CFB180LP: CFB180LP burner, plate or pan, lava rock, gas reducing orifice Model # CFB180NG: CFB180NG burner, plate or pan, lava rock, gas reducing orifice...
  • Page 4 FIRE PIT CLEARANCES WARNING: It is the responsibility of the installer to follow ALL LOCAL • 36” horizontally from any structure or combustibles. CODES concerning the installation and operation of the fire pit. In the ab- • Overhead clearance should be a minimum of 120”. sence of local codes, please follow: •...

  • Page 5: Media Installation

    MEDIA INSTALLATION Gas or Liquid Propane. Do not use Natural Gas appliance with Liquid Pro- pane or Liquid Propane appliance with Natural Gas. Refer to the labeling WARNING: Only use approved decorative media (glass, lava rock, ceramic on the appliance to confirm gas type. log sets, etc.) that have been manufactured for specific use in fire features.

  • Page 6: Maintenance

    FIRE FEATURE OPERATION LIGHTING INSTRUCTIONS FOR: 3V Battery Operated System, 24V Premium Electronic Ignition System WARNING: If you do not follow these instructions exactly, a fire or explo- & 24V Standard Electronic Ignition System sion may result causing property damage, personal injury, or loss of life. 1.

  • Page 7: Warranty

    by the unit, as well as inconvenience expenses, material or labor charges incurred by and clear of any debris, dust, spider webs and loose particles from the media and logs. Once pilot assembly is clean, inspect to see flame that covers 3/8” to 1/2” of any service call, repair, removal or re-installation of any unit.
  • Page 8 Perform leak tests on all fittings before turning on ignition. 60K – 120K BTU System with FLKV12 Original Series: CFB60, CFB84, CFB120 | Linear Series: CFBL90, CFBL110 | H-Style Series: CFBH120 Any custom burners between 60K - 120K FOR PUSH BUTTON IGNITION INSTRUCTIONS: Follow Match Lit System installation instructions. When finished, turn to page 25 for Push Button Ignition installation instructions.
  • Page 9 STEP 2: Remove 1/2” flared fittings from each end of 1/2” flex line. Flex Line Flared Fitting STEP 3A: (FOR MATCH LIT SYSTEM) Connect one of your 1/2” flared fittings removed in Step 2 to the ½” coupling located on the bottom Coupling of the aluminum plate with flared end on bottom.
  • Page 10 STEP 4A: (MATCH LIT SYSTEM) Connect the 1/2” flex line to the fitting now located Coupling on the bottom of your aluminum plate. STEP 4B: (3 VOLT IGNITION) Plate Coupling Flared Fitting Plate 3 Volt Flared Flex Line Ignition Fitting Drip Leg Flex Line STEP 4C: (STANDARD 24 VOLT IGNITION)

  • Page 11: Final Setup

    FINAL SET UP Coupling STEP 6A: (MATCH LIT SYSTEM) Connect 1/2” flex line into the fitting connected in Step 5 to key valve. Tighten. Flared Fitting STEP 6B: (3 VOLT IGNITION) Coupling Plate 3 Volt Gas Valve Plate Flex Line Flared Drip Leg Fittings...
  • Page 12 121K - 249K BTU Systems with FLKV34 and FLKV34FIT180 Original Series: CFB180 | Linear Series: CFBL130, CFBL150, CFBL190, CFBL210 | H-Style Series: CFBH160, CFBH200, CFBH240 Any custom burners between 121K - 249K FOR PUSH BUTTON IGNITION INSTRUCTIONS: Follow Match Lit System installation instructions. When finished, turn to page 25 for Push Button Ignition installation instructions.
  • Page 13 STEP 4A: (MATCH LIT SYSTEM) Connect the new fitting created in Step 4 to the 1/2” coupling located on the bottom of the aluminum plate. Tighten. Coupling STEP 4B: (STANDARD 24 VOLT IGNITION) Coupling Standard 24 Volt Ignition Apply thread Apply thread sealant here 1/2"...
  • Page 14 STEP 5 STEP 6: Key Valve Locate the other 3/4” flared fitting Flared Fitting removed in Step 3 and connect into the 3/4” key valve. Tighten using crescent wrench. Apply thread sealant here FINAL SET UP STEP 7A: MATCH LIT SYSTEM Connect 3/4”...
  • Page 15 250K - 299K BTU Match Lit System with DFLKV34 and DFLKV34FIT250 Original Series: CFB250, CFB290 | Linear Series: CFBL250, CFBL270 Any custom burners between 250K - 299K NOTE : If using the Standard 24 Volt High Capacity Ignition, turn to page 25 for instruction on installation. Burners between 250K - 300K BTU's using a Standard 24 Volt Ignition will need to use the FIT300.
  • Page 16 STEP 2 STEP 2: Remove 3/4” flared fittings from each Flared Fitting end of 3/4” flex lines. Flared Fitting Flared Fitting Flared Fitting STEP 3A: Connect 1/2” x 3/4” reducing fitting to the ½” coupling located underneath the aluminum plate. Coupling STEP 3B: (STANDARD 24 VOLT HIGH CAPACITY IGNITION)
  • Page 17 STEP 4A: Connect one 3/4” tee fitting to the connection made in Step 3 (½” x 3/4” reducing fitting to the 1/2” coupling under aluminum pan.) Coupling STEP 4B: (STANDARD 24 VOLT HIGH CAPACITY IGNITION) 1/2" x 3/4" Reducing Fitting (FIT250) SEE PAGE 20 FOR INSTALLATION Apply thread sealant here...
  • Page 18 STEP 6A: Connect both 3/4” flex lines to the 3/4” flared fittings connected in Step 5. Tighten. STEP 6B: (STANDARD 24 VOLT HIGH CAPACITY IGNITION) Coupling 1/2" x 3/4" Reducing Fitting (FIT250) SEE PAGE 20 FOR INSTALLATION INSTRUCTION Flex Line Flex Line 3/4”...
  • Page 19 FINAL SET UP Coupling STEP 10A: Connect available ends of 3/4” flex lines (connected to 1/2" x 3/4" Reducing Fitting (FIT250) Plate aluminum plate in Step 6) to 3/4” flared fittings connected in Step 10. Flex Line Flex Line Flared 3/4”...
  • Page 20 300K+ BTU Match Lit System with DFLKV34 and DFLKV34FIT300 Original Series: CFB300, CFB350, CFB450 | H-Style Series: CFBH300, CFBH340 Any custom burners 300K and above FOR PUSH BUTTON IGNITION INSTRUCTIONS: Follow Match Lit System installation instructions. When finished, turn to page 25 for Push Button Ignition installation instructions. STEP 1: Locate DFLKV34 and FIT300 Parts include two 3/4”...
  • Page 21 STEP 2 STEP 2: Remove 3/4” flared fittings from each Flared Fitting end of 3/4” flex lines. Flared Fitting Flared Fitting Flared Fitting STEP 3A: Connect 3/4” x 3” pipe nipple fitting to the coupling located underneath Coupling the aluminum plate. Apply thread sealant here Plate 3/4"...
  • Page 22 STEP 4A: Connect one 3/4” tee fittings to the connection made in Step 3 (3/4” x 3” pipe nipple under aluminum pan.) Coupling 3/4" x 3" Nipple (FIT300) Apply thread Plate sealant here 3/4" Tee (FIT300) STEP 4B: (STANDARD 24 VOLT IGNITION) STEP 4C: (PREMIUM 24 VOLT IGNITION) 3/4"...
  • Page 23 Coupling STEP 6A: Connect both 3/4” flex lines to the 3/4” flared 3/4" x 3" fittings connected in Step 5. Tighten with crescent wrench. Nipple (FIT300) Plate Flared Fitting Flared Fitting Flex Line Flex Line 3/4" Tee (FIT300) STEP 6B: (STANDARD 24 VOLT IGNITION) STEP 6C: (PREMIUM 24 VOLT IGNITION) Flex Flex...
  • Page 24 FINAL SET UP Coupling STEP 10A: Connect Plate available ends of 3/4” flex lines (connected to 3/4” x 3” Pipe Nipple (FIT300) aluminum plate in Step 6) to 3/4” flared fittings connected in Step 10. Flared 3/4” Tee Flared Fittings (FIT300) Fittings 3/4”...
  • Page 25 Push Button Ignition Installation NOTE : If the burner being installed uses a titled jet, use the 3.0" Spark Igniter. If the burner uses a straight jet, use the 3.25" Spark Igniter. Use the 3.0" Spark Igniter Use the 3.25" Spark Igniter STEP 1: To place .125"...
  • Page 26 STEP 4: Install push button module into Key Valve mounting bracket. 1) Unscrew button cover. Push Button 2) Remove plastic nut. Module 3) Insert washer #1onto the button stem. 4) Insert push button stem through mounting Mounting bracket hole. Button Stem Bracket 5) Insert washer #2.

  • Page 27: Parts Glossary

    Parts Glossary 12” Key (KEY12) 4” Key (KV12 or KV34) Pressure Face Plate Key Valve (KV12 or KV34) (KV12 or KV34) Flex Line (FL3612 or FL3634) Flared Fitting Flared Fitting Push Button Module (PB-CM) Spark Igniter (PB-SI) Mounting Bracket (PBMBR)

  • Page 28: Replacement Parts

    Replacement Parts FLKV12 For use with any burner up to 120K BTU’s. Kit Includes: (1) 36” L x ½” Diameter Flex Line + ½” Key Valve + 4” and 12” Key FLKV34 For use with any 121K - 249K BTU Burner. Kit Includes: (1) 36” L x 3/4” Diameter Flex Line + 3/4” Key Valve + 4” and 12” Key For use with any 121K - 249K BTU Burner.
