Summary of Contents for Konlen KL-P103
-
Page 1: User Manual
GPS\GSM fleet management tracking system www.konlen.com GPS/GPRS/GSM vehicle tracker KL-P103 USER MANUAL ： ： ： ： KL091005 1-18... - Page 2 GPS\GSM fleet management tracking system www.konlen.com Ⅰ Ⅰ Ⅰ Ⅰ Instruction KL-P103 satellite positioning system combines with anti-theft, positioning, listen-in, monitoring, tracking, emergency help, vehicle scheduling, image capture and platform software management etc.functions. With the full-featured characteristics, it widely applies to vehicles and other mobile object location and tracking services, large-scale cluster monitoring, emergency scheduling, traffic safety management and many other fields.
-
Page 3: Specification
GPS\GSM fleet management tracking system www.konlen.com 1.2 Specification NAME PARAMETER Main device dimension 85mm × 55mm × 29mm Main device weight 0.18kgs Color Black Working voltage 12V -- 24V DC Working current 80mA, 200mA (12V/DC) Back-up battery 300mA / H Working temperature -35℃... - Page 4 GPS\GSM fleet management tracking system www.konlen.com Circuit Fuel-break/ power off 1PCS DC12v or DC24v (optional) beaker(relay) 1PCS Listen in Installation cable: match 6PIN cable 6PIN cables with 1PCS socket(B6B) with tracker 103A6A; the other end SOS button connecting with automobile circuit.
-
Page 5: Main Device Diagram
GPS\GSM fleet management tracking system www.konlen.com Ⅱ Ⅱ Ⅱ Ⅱ Main device installtion Note: This product is not waterproof. Please choose the dry location to install. 2.1 Main device diagram 1. Main device 2. SIM card slot 3. Rear cover of main device 4. - Page 6 GPS\GSM fleet management tracking system www.konlen.com c. The SIM card must support voice call function if need listen in the voice at site. d. Make sure to insert and take off SIM card in power off status, or it is easy to burn the SIM card and device.
- Page 7 GPS\GSM fleet management tracking system www.konlen.com wire(currect passing direction), and connect the other green wire with the other end. 2.5 103A3A installation diagram 103A3A with three wires, red (+), green(-), orange(signal wire). The green and red are user self-definiton alarm trigger wires, the green for user-defined 1 trigger alarm(anode trigger), the red for user-defined 2 trigger alarm(cathode trigger).
- Page 8 GPS\GSM fleet management tracking system www.konlen.com shielding material cover it within 60 degree range. Please don’t leave after installation until the GPS fleet management platform can receive location datas normally and stably for 5 minutes at least. The below is suggested GPS antenna installation locatation a.The junction of windscreen wiper and front cover: ①...
- Page 9 GPS\GSM fleet management tracking system www.konlen.com 3.2 SMS Setting IUSSE SEND COMMAND ANSWER COMMAND REMARK SET SERVER IP AND AS1234IPPO:119.147.23.108;7777 IPPO:119.147.23.108;7777,26339788;OK Response content is “IP””Port” “Current Device ID” ；# PORT Response Current Device “ID” SET TERMINAL ID AS1234IDDO:26339788# IDDO:26339788;OK Access Point Name AS1234APN:CMNET# APN:CMNET;OK...
- Page 10 GPS\GSM fleet management tracking system www.konlen.com AS1234EMPOWER:13590251897# EMPOWER:13590251897;OK Authorized Number Set AS1234EMPOWER:0# EMPOWER: CLEAR;OK Change Device Password AS1234PASSWORD:5678# PASSWORD:5678;OK TRACK:Latitude:+22.123456;Longtitude Track Once AS1234WHERE# Send once :+113.123456;speed:98;ACC:ON Track:3;OK Track:OFF;OK 1、Unit：“Minutes” SET TRACK Interval AS1234TRACK:3# Data upload format ： 2、type：“0” cancel ；...
- Page 11 GPS\GSM fleet management tracking system www.konlen.com a. SET SERVER IP AND PORT GPS trackers(GPRS version) transmit the data into internet through fixed path, IP and port so that trackers can link with software fleet management platform. User can set and modify the IP and port via above No.1 SMS format: AS1234IPPO:IP;PORT；...
- Page 12 GPS\GSM fleet management tracking system www.konlen.com 3.3.2 Modify APN APN means Access Point Name. It is a necessary setting for GPRS to link with internet and transmit GPS data to server. Due to different countries and districts, there are different APN for GPRS to LOG IN from different networks server agent.
-
Page 13: Mileage Statistics
GPS\GSM fleet management tracking system www.konlen.com immediately return vehicle location data in details to the center monitoring platform. Location information mainly include: time, longitude, latitude, speed, direction, address, GPS/GSM/ACC state, alarm etc. 3.3.7 Data upload by time interval. Monitoring center can set the interval time of tracker uploading data to center. Factory defaults is 30 seconds, adjustable range is 5-65535 seconds. -
Page 14: Image Capture
GPS\GSM fleet management tracking system www.konlen.com 3.3.11 Cut/recover the oil circuit Monitoring center can issue command to trackers to break the vehilce oil/power or restore it. To protect traffic and personnel safety, the oil will be cut by three times of oil off action, which is off for one second, then restore for 15 seconds repeatly. -
Page 15: Overspeed Alarm
GPS\GSM fleet management tracking system www.konlen.com 3.3.15 Overspeed alarm Overspeed alarm refers to the device in accordance with preset speed premitted value to constantly monitor the vehicle speed, and make an alarm to center when vehicle speed exceeds preset allowable value. - Page 16 GPS\GSM fleet management tracking system www.konlen.com 3.3.17 Fatigue drving alarm Fatigue driving alarm is also known as overtime driving warning. User can set an allowable time value of countinuous driving. When the dirving time exceeds the preset premitted value, the device send fatigue driving alarm to center immedialtely, which can control driving time and reduce the traffice accident caused due to continous overtime fatigue driving effectively.
- Page 17 GPS\GSM fleet management tracking system www.konlen.com Ⅳ Ⅳ Ⅳ Ⅳ appendix： ： ： ： Brief instruction of GPS fleet management platform 4.1 The diagram of working principle Satellite GPRS/SMS/CDMA Server installed with center software Vehicles Clients monitoring center 17-18...
