ASSEMBLY AND USER GUIDE
www.crystalscreens.com
Models: S80V2.5P, S92V2.5P, S100V2.5P, S106V2.5P, S80V2.5C, S92V2.5C,
S100V2.5C, S106V2.5C
Record the model and serial number of your Crystal Screen for future
reference. This information is located on the rear of the frame assembly.
Mode:#_______________________________________________________
Serial #:_______________________________________________________

Advertisement

loading
Need help?

Need help?

Do you have a question about the S80V2.5P and is the answer not in the manual?

Questions and answers

Summary of Contents for Crystal Screen S80V2.5P

  • Page 1 ASSEMBLY AND USER GUIDE www.crystalscreens.com Models: S80V2.5P, S92V2.5P, S100V2.5P, S106V2.5P, S80V2.5C, S92V2.5C, S100V2.5C, S106V2.5C Record the model and serial number of your Crystal Screen for future reference. This information is located on the rear of the frame assembly. Mode:#_______________________________________________________ Serial #:_______________________________________________________...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operation and maintenance (servicing) instructions in the literature accompanying the appliance. When using your projection screen, basic safety precautions should always be followed, including the following: 1.
  • Page 3 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE Warning: To avoid danger of choking or suffocation, keep any plastic bags contained with this product away from babies and children. 3D Warning! 1. Some viewers may experience various types of discomfort during or after viewing 3D visual images including symptoms like dizziness, disorientation, eye strain/fatigue, blurry vision, headaches and/or nausea.
  • Page 4 A. Bottom Tube x1 B. Side Support Tube x1 C. Top Tube x1 D. Top Tension Tube X1 E. Bottom Tension Tube x1 F. Guide Support x1 4 | Crystal Screens Assembly and User Guide...
  • Page 5 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE G. Center Post x2 H. Tension Support Tube x1 I. Center Bracket x8 J. Sliding Corner Bracket x4 K. Spring Guide Assembly x3 L. Compression Spring x3 Crystal Screens Assembly and User Guide | 5...
  • Page 6 M. Nylon Flat Washer x3 N. Adjustment Tube x3 O. Wing Nut, ¼”-20 x3 P. Phillips Flat-head Screws 10-32 x 3/8” Q. Pan Head Phillips Screws 10-32 x R. Button-head Socket Cap Screws 3/8” x3 ¼-20 x 3/8” 6 | Crystal Screens Assembly and User Guide...
  • Page 7 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE S. Pan Head Phillip Screws (small) x3 T. Pan Head Phillips Screws 8-32 x 3/8” U. Metal Washers x3 V. Two Screen Pressure Strips x3 Crystal Screens Assembly and User Guide | 7...
  • Page 8 FRAME ASSEMBLY INSTRUCTIONS 8 | Crystal Screens Assembly and User Guide...
  • Page 9 When handling the screen, wear the included gloves to minimize contact with the front side (gray, matted side) of the Crystal Screen. NOTE: When laying out the frame, take special care to face the tubes in the correct direction as noted by the diagrams.
  • Page 10 Insert Side Support Tube (B) into Bottom Tube (A) and fasten with 2 Phillips Flat Head Screws (P). NOTE: Side support tubes should be installed facing outward. These two tubes can be identified by the multiple screw holes on the outer side.
  • Page 11 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE Insert Top Tube (C) into Side Support Tube (B) and fasten it with 2 Phillips Flat Head Screws (P). Crystal Screens Assembly and User Guide | 11...
  • Page 12 Insert Top Tension Tube (D) into Top Tube (C) and fasten with 4 Phillips Flat Head Screw 12 | Crystal Screens Assembly and User Guide...
  • Page 13 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE Insert Bottom Tension Tube (E) into Bottom Tube (A) and fasten it with 4 Phillips Flat Head Screws (P). Crystal Screens Assembly and User Guide | 13...
  • Page 14 Fasten the Guide Support (F) to the top and bottom frames (D) and (E) using 2 Pan-head Phillips Screws (Q) on each end. 14 | Crystal Screens Assembly and User Guide...
  • Page 15 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE Attach the Center Posts (G) to the inside of the frame by fastening them with the Center Brackets (I) and Pan-head Phillips Screws (T) at each end. Include Metal Washers (U). Be sure that both center posts are installed with mounting holes facing the same direction as the side bars, see illustration above.
  • Page 16 Insert the short end of the Sliding Corner Brackets (J) to each end of the Tension Support Tube (H) and fasten each side with Phillips Flat Head Screws (P). 16 | Crystal Screens Assembly and User Guide...
  • Page 17 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE Screw the 3 Spring Guide Assemblies (K) into the Tension Support Tube (H). Tighten the Jam Nut completely to lock the 3 Spring Guide Assemblies into place – you may need to adjust the thumb screw in order to tighten the Jam Nuts.
  • Page 18 Place a Nylon Flat Washer (M) and a Compression Spring (L) onto each of the Spring Guide Assemblies (K). Carefully insert the assembly from step 8 into the frame from step 6 through the pre-inserted nylon flange bearings. 18 | Crystal Screens Assembly and User Guide...
  • Page 19 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE Place an Adjustment Tube (N) over each of the 3 Spring Guide Assemblies (K) and tighten each evenly with a Wing Nut (O) until the springs are COMPRESSED to prepare for Crystal Screen mounting. Crystal Screens Assembly and User Guide | 19...
  • Page 20 CRYSTAL SCREEN MOUNTING 20 | Crystal Screens Assembly and User Guide...
  • Page 21 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE NOTE: Handle the Crystal Screen carefully. To avoid fingerprints, wear gloves (Latex, nitrile, cloth, etc.) to minimize contact with the front side (gray, matted side) of the Crystal Screen. (Note: fingerprints will not affect the projected image.)
  • Page 22 Clean frame of debris. Lay the frame backside down (mounting holes faced down), then carefully lay the Crystal Screen material face up (glossy side down, grey-matted side up) on the front side of the frame. NOTE: The screen is folded on the...
  • Page 23 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE Line up the screen holes on the material with the threaded frame holes on the frame. Place a screen pressure strip (V) over the screen holes and fasten with Button-head Socket Cap Screws (R). Before fastening, make sure the holes on the folded sides of the screen line up with the top or bottom edges of...
  • Page 24 Repeat fastening on the opposite end of the frame as done in Step 2. Line up the screen holes with threaded frame holes. Place a pressure strip (V) over the screen holes and fasten with Button- head Socket Cap Screws (R). While fastening make sure the crease of the screen lines up with the top or bottom edges of the frame.
  • Page 25 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE Loosen the Wing Nuts to begin tensioning the Crystal Screen. Springs should decompress. Wing Nuts should be loosened as much as possible without falling off. Crystal Screens Assembly and User Guide | 25...
  • Page 26 Tighten the thumb screw until springs are fully compressed and the screen is fully tensioned and free of wrinkles. NOTE: If you still see creases or winkles, refer to the troubleshooting guide at the end of this manual. 26 | Crystal Screens Assembly and User Guide...
  • Page 27 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE The bezel fastens with 18 Pan Head Philip Screws Small (S). Ensure the front of the bezel hooks over the screen side first then aligns with the fastening holes on the back side of the frame. Note: The six bezel pieces are marked, 2 for each side, 2 for the top, and 2 for the bottom.
  • Page 28: Maintenance And Care

    WALL MOUNT COMPATIBILITY Crystal Screen recommends mounting the frame with the included Z-brackets (2). Attach the two Z brackets to the visible holes on the support tubes using the Phillips screws included in the packaging. The frame is also compatible with UL-listed TV wall mounts wider than 28 inches.
  • Page 29 CRYSTAL SCREENS ASSEMBLY AND USER GUIDE SCREEN PLACEMENT & INSTALLATION GUIDE Care should be taken to ensure that you experience the best possible image quality. This includes maximizing the projector’s brightness with the placement of the screen, and placing the audience at a sufficient distance relative to the screen size. The light from the projector should reflect off the center of the screen at an angle that is equal to the angle created when that light reflects off the screen as shown in the image below.
  • Page 30 When installing the screen, position it so that the middle (or center) of the screen is located halfway vertically between the viewer and the projector, when the viewer and projector are equal distance to the screen. If viewers are closer than the projector, the screen will need to be lower; conversely, if viewers are farther than the projector, the screen will need to be higher.
  • Page 31: Projector Installation

    Crystal Screen. Adjust the height of the projector or height of the Crystal Screen until the top of the projector’s image is slightly below the top edge of the Crystal Screen. Once in position, the projector lens can be adjusted until the image is flush with the top edge of the screen.
